X9: An Obfuscation Resilient Approach for Source Code Plagiarism

Detection in Virtual Learning Environments

Bruno Prado, Kalil Bispo and Raul Andrade

Department of Computing, Federal University of Sergipe, Marechal Rondon Avenue, S

ao Crist

ao, Brazil

Keywords:

Plagiarism Detection, Computer Programming, E-learning, Source Code Similarity, Re-factoring, Obfusca-

tion.

Abstract:

In computer programming courses programming assignments are almost mandatory, especially in a virtual

classroom environment. However, the source code plagiarism is a major issue in evaluation of students, since

it prevents a fair assessment of their programming skills. This paper proposes an obfuscation resilient approach

based on the static and dynamic source code analysis in order to detect and discourage plagiarized solutions.

Rather than focusing on the programming language syntax which is susceptible to lexical and structural re-

factoring, an instruction and an execution ﬂow semantic analysis is performed to compare the behavior of

source code. Experiments were based on case studies from real graduation projects and automatic obfuscation

methods, showing a high accuracy and robustness in plagiarism assessments.

1 INTRODUCTION

In computer science graduation, practical exercises

for programming language courses are essential to

improve the learning process (Kikuchi et al., 2014),

specially through e-teaching platforms, such as Moo-

dle (Moodle, 2017). Although, the effectiveness of

virtual learning environments consist on ensuring that

students would not to be able to plagiarize, that is, to

be evaluated by someone else’s programming compe-

tence. Source code plagiarism consists in the partial

or complete reuse of a third-party solution instead of

writing its own source code. Despite possible copy-

right infringements, plagiarism in programming exer-

cises prevents a fair evaluation of students and creates

the burden of proof to ensure similarity assessment

(Cosma and Joy, 2012; Joy and Luck, 1999).

Due to the long time spent in manual veriﬁcation

of source code, it is mandatory the use of automatic

source code plagiarism detection tools to verify sim-

ilarities between ﬁles. The major challenge for these

tools is the detection of false positive cases in sim-

ilar solutions of simple problems from introductory

courses (Modiba et al., 2016). To properly nullify pla-

giarized solutions, the similarity report selects imple-

mentations using a deﬁned threshold which must be

reviewed by instructor.

In this paper, we propose a plagiarism detec-

tion tool based on both static and dynamic analysis.

The use of multiple approaches, greatly reduces the

chances of false positive cases, while the false neg-

ative condition still can be properly detected, due to

multiple metrics analyzed. The main contributions of

proposed approach are:

• Currently multiple languages are supported, such

as Assembly, C/C++, Go, Java, Pascal and

Python. There is no limitation including another

languages, however, the target speciﬁc develop-

ment tools output must be parsed and analyzed;

• Static analysis relies on extraction of emitted ma-

chine instruction by compiler infrastructure. This

method greatly reduces the impact of code obfus-

cation and re-factoring, since compiler optimizes

the source code ignoring syntactic modiﬁcations;

• By collection of system, libraries and software

calls plus proﬁling traces, the dynamic analysis

can check execution ﬂow to focus in the behavior

of software. This approach identiﬁes the most rel-

evant parts of application, detecting unused code

(dead code) or advanced re-factoring techniques.

The paper is organized as follows: in section 2,

the related work approaches are brieﬂy described; in

section 3, the proposed plagiarism detection ﬂow is

shown; in sections 4 and 5, the static and dynamic

techniques employed to compare source codes are ex-

plained, respectively; in section 6, the methodology

and experimental case studies are deﬁned; and in sec-

Prado, B., Bispo, K. and Andrade, R.

X9: An Obfuscation Resilient Approach for Source Code Plagiarism Detection in Virtual Learning Environments.

DOI: 10.5220/0006668705170524

In Proceedings of the 20th International Conference on Enterprise Information Systems (ICEIS 2018), pages 517-524

ISBN: 978-989-758-298-1

517

tion 7, the proposed approach achievements and fu-

ture work are summarized.

2 RELATED WORK

Some software plagiarism tools are freely available

for evaluation, such as: JPlag (KIT, 2017; Prechelt

et al., 2002) which converts the source code in

string of tokens to compare them using RKR-GST

algorithm; MOSS (Measure Of Software Similarity)

(Aiken, 2017; Schleimer et al., 2003) is based on a

string matching algorithm which divides the software

in k-grams, a contiguous sub-string with length of k;

Sherlock (Joy and Luck, 2017; Joy and Luck, 1999)

that reduces the software to tokens, listing similar

pairs and their degree of similarities in a visual rep-

resentation of graph; and SIM (Grune, 2017; Gitchell

and Tran, 1999) measures the structural similarities

using a string alignment approach. These tools are

used in this paper to evaluate the proposed approach

by comparing the similarity results in different case

studies.

The token-based approaches (KIT, 2017; Aiken,

2017; Joy and Luck, 2017; Grune, 2017; Muddu

et al., 2013) convert provided source codes in se-

quence of tokens to be compared using RKR-GST or

ﬁngerprinting algorithms. These methods are gener-

ally more susceptible to code obfuscation methods,

such as identiﬁcation renaming or code merging, for

example, once they use source code text as input. Ab-

stract Syntax Tree (AST) methods (Zhao et al., 2015;

Kikuchi et al., 2014) convert AST in a hash code

and sequence alignment, respectively. AST structur-

ing improves tokenization effectiveness, providing a a

more robust source code analysis, despite error rates

in arithmetic operations and processing efﬁciency.

Semantic analysis veriﬁes the equivalence be-

tween basic blocks in binary level using fuzzy match-

ing (Luo et al., 2017; Luo et al., 2014) and a matrix

of term-by-ﬁle containing information about terms

frequency counts to ﬁnd the underlying relationships

(Cosma and Joy, 2012). Instead of checking for to-

kens or structure, the semantic approach is focused

on the retrieval of different codes fragments which de-

scribe the same function. The limitations of methods

are inherent to static analysis which can be impaired

by indirect branches and choosing of optimal param-

eter settings.

The employment of unsupervised learning ap-

proach from features extracted from intermediate rep-

resentation of a compiler infrastructure, such as GCC

(Yasaswi et al., 2017), represents the extracted fea-

tures in a n-dimensional space to compare them pair-

wise, using the Euclidean distance measurement. De-

spite the obfuscation resilience provided by inter-

mediate representation processing and the machine

learning techniques, the feature selection relies on the

code optimization selected by the user and includes

no dynamic information which can improve perfor-

mance.

Unlike previous work, the dynamic analysis strat-

egy checks run-time behavior of software in order

to verify usage patterns and ﬂow tracing. By the

analysis of dynamic stack usage patterns (Park et al.,

2015), this work claims that stack usage patterns are

invulnerable to syntactic modiﬁcations. To retrieve

stack information, the software is dynamically instru-

mented to capture function related instructions. An-

other method consists in check run-time semantic in-

formation (Choi et al., 2013) to investigate similari-

ties in binary codes. By the use of a memory tracer,

the region ﬁltering eliminates irrelevant or unneces-

sary variables to allow sequence alignment compari-

son of memory regions. Although the effectiveness of

run-time behavior analysis, these approaches do not

take advantage of static code information which could

improve the similarity measurement conﬁdence, spe-

cially in I/O intensive tasks, such as reading input

(problem) and write the output (answer) to ﬁles.

3 THE PROPOSED FLOW

An efﬁcient assessment ﬂow for practical program-

ming exercises relies on the automation of all pro-

cesses. In this automated environment, the forbidden

source code exchange or team collaboration is dis-

couraged due to high probability of penalties, even

in large class sizes. Besides the automated evaluation

processes, the key concept of proposed plagiarism de-

tection ﬂow is the semantic analysis of software. This

analysis is performed by the use of both static infor-

mation at instruction level and dynamic behavior at

function invocation patterns and traces.

The ability to detect plagiarism is useless if the on-

line submission system is unable to authenticate the

students. Once properly identiﬁed by their institu-

tional accounts, the students are more aware of the

risks of engaging in source code plagiarism and they

will balance the work to avoid detection versus the

effort to solve the problem by themselves. In order

to prove plagiarism, the source code similarity is the

major metric to determine how to classify a pair of

solutions. A similarity threshold must be deﬁned to

assess the plagiarism, but the instructor is able to vi-

sualize and to review the assessments. Even in the

situations where the detected similarity is below than

ICEIS 2018 - 20th International Conference on Enterprise Information Systems

518

deﬁned threshold, the instructor can deﬁne a suspi-

cious similarity range to verify by sampling if some

unnoticed approach is being used to avoid detection.

Online

Submission

Source

Codes

Source

Codes

Source

Codes

Compiler

Infrastructure

Proﬁler

and

Tracer

Software

Instructions

Software

Instructions

Software

Instructions

Flow/Trace

Data

Flow/Trace

Data

Flow/Trace

Data

Code

Parser

Pattern

Checker

Trace

Match

Semantic

Analyzer

Plagiarism

Assessment

YesNo

T hreshold < ≥ Threshold

Figure 1: Plagiarism detection ﬂowchart.

In Figure 1, a overview of proposed plagiarism de-

tection ﬂow can be summarized in the following pro-

cesses:

• Online Submission: the user is authenticated to

upload Source Codes which is compiled to check

for syntactic errors or forbidden built-in libraries

importation, such as algorithms and data struc-

tures;

• Compiler Infrastructure: to generate a set of Soft-

ware Instructions from Source Codes, the avail-

able compiler optimization options are used in de-

fault, code size and execution time levels;

• Proﬁler and Tracer: by the capture of proﬁling in-

formation, libraries and system calls, the software

execution ﬂow can be analyzed for invocation pat-

terns and tracing comparison;

• Code Parser: this step consists in the parsing of

assembly ﬁles generated to retrieve the semantic

behavior from source code functions;

• Pattern Checker: the software proﬁling identiﬁes

core functions of application, that is, the functions

with largest running time and number of calls;

• Trace Match: all the software requests to the dy-

namic libraries or to the operating system are

compared to determine system requests similari-

ties;

• Semantic Analyzer: by the analysis of parsed

codes, the invocation patterns and execution

traces, the semantic similarity of a set of Source

Codes is calculated;

• Plagiarism Assessment: in this phase, using the

deﬁned Threshold and Source Codes as input, the

plagiarism is discarded (No) or conﬁrmed (Yes)

for all pairs of solutions in a HTML report.

4 INSTRUCTION LEVEL

SEMANTIC ANALYSIS

A plagiarized source code could be deﬁned as the im-

proper reuse of software without changing the behav-

ior of a third-party solution. This source code ob-

fuscation to avoid the plagiarism detection is mostly

based on syntactic and structural modiﬁcations which

can be overcome by a resilient semantic analysis.

4.1 Behavior Assessment

Instead of checking for syntactic similarities, the pro-

posed semantic analysis is focused on the extraction

of software behavior from instructions emitted by

compiler.

int search1(int x, int* V, unsigned int n) {

unsigned int i = 0;

int index = -1;

while(i < n && index == -1) {

if(V[i] == x) index = i;

i++;

}

return index;

}

int search2(int* X, int v, int N) {

int pos = -1;

for(int a = 0; a < N && pos < 0; a = a + 1)

pos = (X[a] != v) ? (-1) : (a);

return pos;

}

Figure 2: Sequential search source code examples.

As can be seen in Figure 2, the two sequential

search examples provided have a quite distinct syntax,

but exactly the same behavior. This is a straightfor-

ward example of how difﬁcult is to assess the source

code plagiarism without checking underlying behav-

ior.

A side-by-side comparison of the functions

search1 and search2 is shown in Figure 3, where

X9: An Obfuscation Resilient Approach for Source Code Plagiarism Detection in Virtual Learning Environments

519

search1:

! jae

cmpl

! je

search2:

+ cltq

+ jmp

+ mov

! jge

cmpl

! js

Figure 3: Side-by-side instructions comparison.

− and + denote a missing or added instruction, re-

spectively, and ! highlights the difference between in-

structions. Applying Longest Common Subsequence

(LCS) algorithm (Bergroth et al., 2000), a similarity

of 92% between the functions is detected.

4.2 Similarity Score

All the functions of source codes are processed

as position-independent code which allows the re-

siliency against interchange of source code placement

and merging of sequentially called functions.

n−1

m−1

Figure 4: Position-independent similarity check.

Considering the source ﬁles X and Y , as shown

in Figure 4, the similarity score of each function X

versus Y

, where i ∈ [1, n] and j ∈ [1, m], consists in the

best match obtained from LCS algorithm. In Equation

1, the maximum similarity of comparison of function

with the functions of Y , that is, the best match of X

and Y

ρ(X

,Y ) = max

j=m

∑

j=1

LCS(X

) (1)

Once the function similarity is known, the next

step is to calculate the weight ω of this function in

whole source code. As detailed in Equation 2, the

function weight ω is obtained through the division of

size of function X

by all X functions.

ω(X

) =

∑

k=n

k=1

(2)

Finally, the similarity score between X and Y

source codes is deﬁned by the sum of weighted sim-

ilarities of X

functions against the Y source code, as

deﬁned in Equation 3.

σ(X,Y ) =

i=n

∑

i=1

× ρ(X

,Y ) (3)

5 EXECUTION FLOW TRACE

No matter how advanced static source code analysis

is, the plagiarist can include large amounts of unused

or rarely called functions (dead code), just to deceive

similarity comparison. Instead of checking software

statically, the source code proﬁling aims to retrieve

dynamic behavior by the analysis of execution ﬂow,

that is, by the fetching all function, libraries and sys-

tem calls, plus proﬁling traces.

Figure 5: A call-graph generated from the execution.

The execution ﬂow analysis consists in tracing of

function X

call history from software run, as illus-

trated in Figure 5. The dead code functions D

can

be easily detected due to null or very low inﬂuence in

overall function call tracing. Hence, the run-time se-

mantic information acquired from dynamic behavior

is much harder to be obfuscated by re-factoring tech-

niques.

5.1 Library and System Calls Capture

In a Linux environment, there are tracing tools to dy-

namically intercept the library calls and systems calls

ICEIS 2018 - 20th International Conference on Enterprise Information Systems

520

requested by a process, using ltrace (Cespedes, 2017)

and strace (strace project, 2017), respectively. This

information is quite useful because it provides a black

box view of how software interacts with the libraries

and system.

i+1

i+2

i+3

j+1

j+2

j+3

Figure 6: The library or system calls trace comparison.

Once the source code traces were retrieved from

applications X and Y , the LCS algorithm is applied to

compare the run-time calls, as shown in Figure 6. Ac-

quired information shows the sequence of calls per-

formed by each solution, providing a ﬁngerprint of

resource usage (e.g., memory allocation) and services

requested (e.g., I/O operations).

5.2 Software Proﬁling

Besides the trace capabilities, the most valuable met-

ric provided by software proﬁling tools, such as GNU

gprof (GNU, 2017) or Valgrind (Valgrind, 2017), is

the software invocation patterns. Instead of consid-

ering the size of source code, the application proﬁl-

ing allows the identiﬁcation of core functions by de-

termining the amount of calls performed and overall

time elapsed.

i+1

i+2

i+3

i+4

j+1

j+2

j+3

j+4

Figure 7: Example of X and Y invocation patterns.

By the comparison of most important functions,

sorted by descending order of time spent in execution,

the proposed approach focus in core codes (Park et al.,

2015) which run-time behavior are hard to be replaced

or removed. In Figure 7 it is shown an example of a

set of functions X

and Y

invocation patterns from X

and Y applications, respectively, which can be used to

determine the execution proﬁle.

6 EXPERIMENTAL RESULTS

To properly evaluate the proposed techniques, in

next three subsections the methodology of performed

experiments is detailed, the similarity comparison

scores from available tools is shown and a discussion

of experiments is held.

6.1 Methodology

The burden of proof (Cosma and Joy, 2012; Joy and

Luck, 1999) is certainly the major challenge in pla-

giarism assessment. Some source code modiﬁcations

can make it hard or impossible the demonstration of

similarities due to the complexity of changes made.

In order to avoid questions about applied effort in

source code re-factoring techniques, the obfuscation

tool Stunnix C/C++ (Stunnix, 2017) was used in at-

tempt to deceive plagiarism tools by: stripping spaces

and newlines; MD5 hashing of the identiﬁers; and

converting strings to hex escape codes.

Four different possibilities can occur while code

similarity is being performed. The intended scenario

occurs when innocent solutions are freed (true nega-

tive = T N) and plagiarism is correctly detected (true

positive = T P). On the other hand, there are unwanted

scenarios in which plagiarized code is not uncovered

(false negative = FN) and not guilty implementations

are wrongly accused of plagiarism (false positive =

FP). The accuracy of plagiarism detection, denoted

by α ∈ [0, 1] in Equation 4, can be deﬁned as the

sum of properly asserted solutions divided by the to-

tal number of solutions. A similarity threshold of 90%

was chosen to classify a solution as plagiarism.

α =

T N + T P

T N + FN + T P + FP

(4)

To accomplish a realistic tool comparison, three

sets of computer science graduation projects written

in C/C++ were selected from a solution database.

These exercises addresses the implementation of a

ship load sorting using Mergesort algorithm, labeled

as set A; a Knuth-Morris-Pratt (KMP) gene ﬁnder for

disease checking in DNA sequence, labeled as set B;

and a instruction set simulator for a hypothetical RISC

machine, labeled as set C. Considering only fully cor-

rect solutions to compare equivalent source codes, the

sets had their assessments by X9 shown in Table 1.

Table 1: The assessments for sets A, B and C.

Set T N T P FN FP

A 23 1 0 1

B 24 1 0 1

C 4 0 0 1

X9: An Obfuscation Resilient Approach for Source Code Plagiarism Detection in Virtual Learning Environments

521

1 2 3 4

5 6

7 8 9 10 11 12 13 14

15 16

17 18 19 20 21 22 23 24

100

Similarity %

JPlag MOSS Sherlock SIM X9

(a) 25 solutions of A

1 2 3 4

5 6

7 8 9 10 11 12 13 14

15 16

17 18 19 20 21 22 23 24

25 26

100

Similarity %

JPlag MOSS Sherlock SIM X9

(b) 26 solutions of B

1 2 3 4

100

Similarity %

JPlag MOSS Sherlock SIM X9

Figure 8: The similarity analysis of sets A, B and C.

All the assessments in Table 1 were performed by

human source code inspection for each pair of solu-

tions. The false positive cases are closely related to

reuse of source code fragments from lectures or ref-

erences. Also, the low complexity of problems with

lines of code ranging from 146 to 462 in set A and

from 115 to 240 in set B could lead to this misclassi-

ﬁcation. In set C, a pair of implementations had 90%

similarity level, although no strong evidence of pla-

giarism were found in investigation.

6.2 Tool Comparison

As described in methodology, the evaluation of pla-

giarism approaches is based on its accuracy, denoted

by α, that is, the measurement of how distant is clas-

siﬁcation from correct assessment stated for sets A, B

and C.

In Table 2, the tools accuracy for proposed case

studies A, B and C are shown. None of the compared

tools were capable to detect TP in sets A and B, while

SIM tool was the only one to wrongly classify three

solutions of set A as plagiarism.

For set A, in the T P cases which similarities were

Table 2: The accuracy of tools in sets A, B and C.

Tool A B C

JPlag 0.9600 0.9615 1.0000

MOSS 0.9600 0.9615 1.0000

Sherlock 0.9600 0.9615 1.0000

SIM 0.8400 1.0000 1.0000

X9 0.9600 0.9615 0.8000

above of 10% (Figure 8a), JPlag and SIM achieved,

respectively, 57.7% and 82% similarities, while X9

reported a 98% similarity. Considering set B, Sher-

lock was the only to report a low similarity of 1% for

a T P solution, assessed by X9 with a 98% similarity,

although JPlag, MOSS and SIM showed 80.9%, 81%

and 90% similarities (Figure 8b), respectively. No T P

solution was detected in set C by any tool (Figure 8c),

just a FP case from X9 approach with a 90% similar-

ity.

To verify the resilience of plagiarism tools to

source code obfuscation, the sets A

, B

and C

were

generated by Stunnix C/C++ (Stunnix, 2017) from

plain sets A, B and C, respectively. In this case study,

the plagiarism tool evaluation focuses on the ability to

detect an automated source code obfuscation, that is,

ICEIS 2018 - 20th International Conference on Enterprise Information Systems

522

1 2 3 4

5 6

7 8 9 10 11 12 13 14

15 16

17 18 19 20 21 22 23 24

100

Similarity %

JPlag MOSS Sherlock SIM X9

(a) A versus A

1 2 3 4

5 6

7 8 9 10 11 12 13 14

15 16

17 18 19 20 21 22 23 24

25 26

100

Similarity %

JPlag MOSS Sherlock SIM X9

(b) B versus B

1 2 3 4

100

Similarity %

JPlag MOSS Sherlock SIM X9

Figure 9: The similarity between plain and obfuscated sets.

the evaluation of A ≡ A

(Figure 9a), B ≡ B

(Figure

9b) and C ≡ C

(Figure 9c) statements.

Table 3: The accuracy checking for sets A

, B

and C

Tool A

JPlag 1.0000 1.0000 0.8000

MOSS 0.0000 0.0000 0.0000

Sherlock 0.0000 0.0000 0.0000

SIM 0.0000 0.0000 0.0000

X9 1.0000 1.0000 1.0000

The accuracy of tools used to detect plagiarism

from obfuscated source codes is shown in Table 3.

In all sets, X9 detected plagiarized code with at least

99% of similarity, thus, achieving a perfect accuracy.

Considering both sets A

and B

, JPlag was the only

tool to identify the obfuscated solution with a 94%

similarity at least. In set C

, JPlag was the only tool

to detect plagiarism in 4 T P solutions with a 100%

similarity, while 1 FN case achieved a 78.2% level.

6.3 Discussion

None of the plagiarism analysis performed by related

tools contradicted the assessments shown in Table 1,

except for a clear classiﬁcation issue from SIM, while

analyzing the set A. These results can conﬁrm the

human assertions made about sets A, B and C, but

the case study performed using automated obfusca-

tion sets A

, B

and C

avoided questions about the

proof or the refutation of the plagiarism evaluations.

Undesired FN cases are critical for plagiarism as-

sessment, since they deﬁne the reliability of auto-

mated checking. JPlag had the best performance,

missing only 1 FN in obfuscated sets A

, B

and C

while Sherlock achieved worst results, detecting none

of plagiarized solutions. Despite good results, JPlag

was unable to identify 2 TP cases in sets A and B

which have been detected by X9 approach with a 98%

similarity.

The token-based algorithm of JPlag was success-

ful due to the fact of ignoring most of syntactic infor-

mation of source code to generate tokens from dec-

larations and operations performed. The 2 T P unde-

tected cases conﬁrm that JPlag is vulnerable to tar-

geted source code level attacks, such as statement re-

placement or reordering, which can be highly suc-

cessful with low effort. In order to deceive X9, it

would be necessary a source code re-factoring to dra-

X9: An Obfuscation Resilient Approach for Source Code Plagiarism Detection in Virtual Learning Environments

523

matically change the generated operations and the ex-

ecution proﬁle, thus, as hard as implementing a solu-

tion from scratch.

7 CONCLUSION

This paper has proposed a robust approach for source

code plagiarism detection, combining static informa-

tion from software instructions and dynamic behavior

from acquired proﬁle and traces. The semantic analy-

sis techniques were effective in detecting plagiarized

solutions in a real case study scenario. Despite minor

false positive cases, the X9 was able to detect all pla-

giarized solutions, even when they were heavily ob-

fuscated with a perfect accuracy level.

The source code similarity comparison is a chal-

lenging task and the proposed approach has plenty

space for improvements, such as: the deﬁnition of a

larger number of labeled solutions in experiments, in-

cluding interpreted and script based languages, which

can improve X9 evaluation; in semantic analysis, the

results can be improved by ignoring known algo-

rithms from lectures or mandatory library/system call

requests, which would avoid FP cases; and the release

of X9 tool for public usage as web service, allowing

further feedback to enhance the development.

REFERENCES

Aiken, A. (2017). Moss - measure of software similarity.

Bergroth, L., Hakonen, H., and Raita, T. (2000). A survey

of longest common subsequence algorithms. In Pro-

ceedings Seventh International Symposium on String

Processing and Information Retrieval. SPIRE 2000,

pages 39–48.

Cespedes, J. (2017). ltrace - a library call tracer.

Choi, Y., Park, Y., Choi, J., Cho, S.-j., and Han, H. (2013).

Ramc: Runtime abstract memory context based pla-

giarism detection in binary code. In Proceedings of the

7th International Conference on Ubiquitous Informa-

tion Management and Communication, ICUIMC ’13,

pages 67:1–67:7, New York, NY, USA. ACM.

Cosma, G. and Joy, M. (2012). An approach to source-code

plagiarism detection and investigation using latent se-

mantic analysis. IEEE Transactions on Computers,

61(3):379–394.

Gitchell, D. and Tran, N. (1999). Sim: A utility for detect-

ing similarity in computer programs. SIGCSE Bull.,

31(1):266–270.

GNU (2017). Gnu proﬁler.

Grune, D. (2017). The software and text similarity tester

sim.

Joy, M. and Luck, M. (1999). Plagiarism in program-

ming assignments. IEEE Transactions on Education,

42(2):129–133.

Joy, M. and Luck, M. (2017). The sherlock plagiarism de-

tector.

Kikuchi, H., Goto, T., Wakatsuki, M., and Nishino, T.

(2014). A source code plagiarism detecting method

using alignment with abstract syntax tree elements.

In 15th IEEE/ACIS International Conference on Soft-

ware Engineering, Artiﬁcial Intelligence, Networking

and Parallel/Distributed Computing (SNPD), pages

1–6.

KIT, K. I. o. T. (2017). Jplag - detecting software plagia-

rism.

Luo, L., Ming, J., Wu, D., Liu, P., and Zhu, S.

(2014). Semantics-based obfuscation-resilient binary

code similarity comparison with applications to soft-

ware plagiarism detection. In Proceedings of the 22Nd

ACM SIGSOFT International Symposium on Founda-

tions of Software Engineering, FSE 2014, pages 389–

400, New York, NY, USA. ACM.

Luo, L., Ming, J., Wu, D., Liu, P., and Zhu, S.

(2017). Semantics-based obfuscation-resilient binary

code similarity comparison with applications to soft-

ware and algorithm plagiarism detection. IEEE Trans-

actions on Software Engineering, PP(99):1–1.

Modiba, P., Pieterse, V., and Haskins, B. (2016). Evaluating

plagiarism detection software for introductory pro-

gramming assignments. In Proceedings of the Com-

puter Science Education Research Conference 2016,

CSERC ’16, pages 37–46, New York, NY, USA.

ACM.

Moodle (2017). Moodle - open-source learning platform.

Muddu, B., Asadullah, A., and Bhat, V. (2013). Cpdp:

A robust technique for plagiarism detection in source

code. In Proceedings of the 7th International Work-

shop on Software Clones, IWSC ’13, pages 39–45,

Piscataway, NJ, USA. IEEE Press.

Park, J., Son, D., Kang, D., Choi, J., and Jeon, G. (2015).

Software similarity analysis based on dynamic stack

usage patterns. In Proceedings of the 2015 Confer-

ence on Research in Adaptive and Convergent Sys-

tems, RACS, pages 285–290, New York, NY, USA.

ACM.

Prechelt, L., Malpohl, G., and Philippsen, M. (2002). Find-

ing plagiarisms among a set of programs with jplag.

j-jucs, 8(11):1016–1038.

Schleimer, S., Wilkerson, D. S., and Aiken, A. (2003). Win-

nowing: Local algorithms for document ﬁngerprint-

ing. In Proceedings of the 2003 ACM SIGMOD Inter-

national Conference on Management of Data, SIG-

MOD ’03, pages 76–85, New York, NY, USA. ACM.

strace project (2017). strace - trace system calls and signals.

Stunnix (2017). Cxx-obfus: Stunnix c/c++ obfuscator.

Valgrind (2017). Valgrind: Instrumentation framework.

Yasaswi, J., Kailash, S., Chilupuri, A., Purini, S., and Jawa-

har, C. V. (2017). Unsupervised learning based ap-

proach for plagiarism detection in programming as-

signments. In Proceedings of the 10th Innovations

in Software Engineering Conference, ISEC ’17, pages

117–121, New York, NY, USA. ACM.

Zhao, J., Xia, K., Fu, Y., and Cui, B. (2015). An

ast-based code plagiarism detection algorithm. In

2015 10th International Conference on Broadband

and Wireless Computing, Communication and Appli-

cations (BWCCA), pages 178–182.

ICEIS 2018 - 20th International Conference on Enterprise Information Systems

524
