Evaluation of Paradigms Enabling Flexibility
BPMSs Comparative Study
Asma Mejri
1
and Sonia Ayachi Ghanouchi
2
1
Laboratory RIADI-GDL, ENSI, Mannouba 2010, Tunisia
2
High Institute on Mangament of Sousse, Sousse, Tunisia
Keywords: Comparative Study, Constraint, Rule, Case Handling, Adaptive Process Support, Taxonomy, Flexibility,
BPMS.
Abstract: In this paper, we make a comparative study between several paradigms that provide flexibility: constraint
based, rule based, case handling and adaptive process support paradigms. We evaluate existing Business
Process Management Systems (BPMSs) using the taxonomy of Regev et al. in order to assign a flexibility
score to each of the corresponding paradigms.
1 INTRODUCTION
In the past decades, flexibility has gained a strong
foothold in various fields, notably in the business
management and information systems disciplines.
Flexibility is important, because continuously
changing conditions force organizations to rapidly
and flexibly adapt their processes. Flexibility is
defined as a key consideration of effective
processes. It is their ability to deal with both
foreseen and unforeseen changes in the context or
environment in which they operate (Schonenberg et
al., 2008).
Thus the real challenge for business process
models consists in providing information systems
with adequate information to deal with the often
conflicting requirements of flexibility.
To overcome the limitations caused by
traditional business process management paradigms,
several paradigms have emerged. The most popular
ones are: rule-based, constraint based, case handling
and adaptive process support paradigms.
In this paper we deal with these four paradigms.
We aim at comparing them using the taxonomy of
flexibility in business process, which was suggested
by Regev et al. in their paper (Regev et al., 2006).
Regev et al. define business process flexibility as the
capability of implementing changes in business
process type and instances by changing only those
parts that need to be changed and keeping other parts
stable. Regev et al. (Regev et al., 2006) consider in
his taxonomy.
The aim of this paper is to answer the following
questions:
 How to compare the flexibility of
existing BPMS?
 How to precise the weight of the
different criteria?
 How to measure the ability of existing
paradigms to deal with process change?
The remainder of this chapter is structured as
follows: A review of BPMS is first presented in
section 2 to provide insights into current BPMS. In
section 3, we present the taxonomy of Regev et al..
Based on this taxonomy, we performed a
comparison between BPMS, under several criteria.
Then we compare the different paradigms. We
conclude with a summary and outlook on future
work.
2 A REVIEW OF EXISTING BPMS
In this section we present different BPMS that have
a great impact in the business process management
field. We provide a brief description of each of these
BPMS. These BPMSs were selected because they
are some of the most famous ones in the studied
field of flexibility enabling BPMSs. Moreover,
experts involved in the development/use of these
BPMSs filled the proposed questionnaire which will
be presented in section 4. Our study is in fact based
291
Mejri A. and Ayachi Ghanouchi S..
Evaluation of Paradigms Enabling Flexibility - BPMSs Comparative Study.
DOI: 10.5220/0005379102910298
In Proceedings of the 17th International Conference on Enterprise Information Systems (ICEIS-2015), pages 291-298
ISBN: 978-989-758-098-7
Copyright
c
 2015 SCITEPRESS (Science and Technology Publications, Lda.)

on the analysis of the answers given by these experts
to this questionnaire.
2.1 Declare
DECLARE system provides a broad range of
functionalities ranging from design, enactment and
dynamic change to verification, discovery and
recommendation (Pesic et al., 2009).
DECLARE illustrates how declarative
approaches can indeed be used to realize more
flexible BPM solutions, while providing various
types of support (Pesic et al., 2009).
The main functionalities of DECLARE system
are creating the constraint templates, creating,
executing and verifying constraint models and
dynamically changing instances of constraint
models.
Declare system is based on a declarative
language “declare” that combines a formal semantic
grounded in Linear Temporal Logic (LTL) on finite
traces, with a graphical representation (Maggi et al.,
2013).
2.2 ESProNA
ESProNa (Engine for Semantic Process Navigation)
is a declarative business process modelling system.
ESProNa supports the definition of functional,
behavioral, organizational, data and operational
process perspectives, resulting in an expressive and
flexible modeling language. It uses constraints for
representing inter-process dependencies and
constraint propagation for finding which processes
are executable in user selected scenarios or given
ones (Igler et al., 2010).
It has been developed using declarative
programming, namely Prolog and Logtalk, to
implement the different functionalities (Igler et al.,
2010).
EsProNa was implemented using a Log talk
application running on SWI-Prolog extended with
the CLP (FD) constraint library and the N3 parser
Henry (Igler et al., 2010).
2.3 JRules (IBM WebSphere ILOG
JRules)
Jrules/JSolver is a business rule management system
(BRMS). JRules offers an important set of
components and capabilities to enable business users
and developers to manage business rules directly
with various levels of implication, from limited
review to complete control over the specification,
creation, testing, and deployment of business rules
(Boyer and Mili, 2011).
JRules was initially developed by ILOG Corp, a
software vendor founded in 1987, and acquired by
IBM in 2009 (Boyer and Mili, 2011).
The JRules BRMS platform is a collection of
modules that operate in different environments while
working together to provide a comprehensive
Business Rule Management System (BRMS). A
BRMS helps to manage business rule independently
of the business application. A BRMS enables
business and IT to collaborate, author, manage, and
execute business rules (Boyer and Mili, 2011).
JRules enables us to create different types of rule
artifacts, depending on the complexity of the
business logic, on the regularity of its structure, and
on its specific use (Boyer and Mili, 2011).
2.4 Adept2
Based on a conceptual framework for dynamic
process changes, on novel process support functions,
and on advanced implementation concepts, the
developed system enables the realization of adaptive
process-aware information systems (Reichert et al.,
2005)
The ADEPT2 system enables support for a broad
spectrum of processes, ranging from simple
document-centered workflows to complex
production workflows, which integrate
heterogeneous, distributed application components
(Dadam et al., 2007). Thus it can be used in a variety
of application domains.
The ADEPT2 technology has been transferred
into an industrial-strength product and forms the
technological base of the AristaFlow BPM Suite.
The most important goals of the ADEPT2 system
were to provide the full spectrum of change
operation for updating a process model, and to be
able to migrate process instances (including those
that were individually modified) to a new model
version (Martinho, 2010).
2.5 PHILharmonicFlows
The PHILharmonicFlows framework (Process,
Humans and Information Linkage for harmonic
Business Flows) is a framework targeting on
comprehensive support of object-aware processes.
It comprises both modeling and runtime
environment enabling full lifecycle support for
object-aware processes (Chiao et al., 2013). In fact,
the framework comprises modules for the modeling,
execution and monitoring of object-aware processes.
ICEIS2015-17thInternationalConferenceonEnterpriseInformationSystems
292

In this framework, object behavior is captured
through micro processes. In turn, object interactions
are captured by a macro process.
In PHILharmonicFlows framework, data is
modeled separately for micro and macro processes
(Chiao et al., 2014). A micro process captures the
behavior of an object, while the macro process
realizes the objects interactions (Chiao et al., 2013).
2.6 ProdProc
Product and Production Process Modeling and
Configuration (ProdProc) is a developed system in a
research project in (Campagna, 2012). It’s a
declarative constraint-based framework for defining
models of both configurable products and their
production processes. It allows a user to easily create
product and process structures.
ProdProc allows the user to model a configurable
product and takes into consideration models aspects
of the production process for a product that may
affect product configuration.
Also it allows the user to couple a product and a
process description, in order to avoid or reduce
planning impossibilities due to product
configuration, and configuration impossibilities due
to production planning.
Constraint Programming techniques were
exploited in the development of ProdProc in order to
guide the configuration of a product and its
production process given the respective ProdProc
model (Campagna, 2012). A ProdProc model
consists of a description of a product, a description
of a process, and a set of constraints coupling the
two (Campagna, 2012).
3 THE TAXONOMY OF REGEV
ET AL.
In this paper, we adopt the taxonomy of business
process flexibility proposed by Regev et al. (Regev
et al., 2006). In fact this taxonomy provides a means
for classifying flexibility with respect to the types of
changes it enables.
We find the taxonomy generic enough to allow
choosing the flexibility criteria of our approach.
These flexibility criteria will be specified in the next
section.
Regev et al. presented in (Regev et al., 2006) a
taxonomy of flexibility in business process. The
taxonomy includes three orthogonal dimensions:
 the abstraction level of change
 the subject of change
 the properties of change
The abstraction level of change concerns the
changes in the business process type or in business
process instances.
Regev et al. suggest that the subject of change in
business processes can be traced to five
perspectives: the functional, the organizational, the
behavioural, the informational and the operational
perspective (Regev et al., 2006).
The functional perspective describes the process
itself. In particular, it describes the number of times
that a process must or can be executed. Complex
processes can be decomposed into a set of steps or
sub-processes. The behavioural perspective
describes the order in which the process steps have
to be executed. The organizational perspective
defines persons that are responsible for the execution
of a given step. The data perspective describes the
data consumed and produced by a process step.
Taken together, the data input and output of each
process define the data flow of a process model. The
operational perspective defines tools and systems
that support the execution of a process step
respectively generating data (Igler et al., 2010).
Regev et al. consider four properties of change:
the extent, the duration, the swiftness and the
anticipation of change.
The extent of a change can be incremental or
revolutionary. Incremental changes start from an
existing process type and only introduce changes to
the already existing process type. Revolutionary
changes abolish the existing process type and create
a completely new one.
The duration of change can be either temporary
or permanent.
4 EVALUATION OF BPMSs
We proposed the use of the taxonomy of Regev et al.
as the starting point for evaluating BPMSs. In this
section we evaluate the different BPMS using a
questionnaire that was sent to the most senior
personnel responsible for the development of the
different BPMSs.
4.1 The Flexibility Criteria
In this section we identify a set of criteria that
flexible BPMSs should be evaluated against. Using
the taxonomy of Regev et al., we have specified
eleven Flexibility Criteria (FC).
EvaluationofParadigmsEnablingFlexibility-BPMSsComparativeStudy
293

The different flexibility criteria concern the
following questions:
 FC1: Does the BPMS support changes to
process models which will affect all new
process instances?
 FC2: Does the BPMS support changes at the
instance level, and that will only affect
certain selected instances, in order to
accommodate exceptional situations?
 FC3: To which extent does the BPMS
modellers have to describe the process
control flow?
 FC4: To which extent does the BPMS
support descriptive modelling and
execution of process activities?
 FC5: To which extent does the BPMS
support descriptive modelling and
execution of the preconditions of the
activities?
 FC6: To which extent does the BPMS
support descriptive modelling and
execution of data/information exchanged
between process activities?
 FC7: To which extent does the BPMS
support descriptive modeling and execution
of roles associated to process activities?
 FC8: Can the BPMS support incremental
change and/or revolutionary change?
 FC9: How would the duration of change that
the BPMS support be characterized:
temporary and/or permanent?
 FC10: Is the BPms able to deal with
immediate and/or deferred change?
 FC11: Can the BPMS support planned / ad-
hoc changes?
FC1 refers to the criteria of change in the
business process type. FC2 refers to the criteria of
change in the business process instance.
FC3, FC4, FC5, FC6 and FC7 concern
respectively functional, organizational, behavioural,
informational and operational perspective.
FC8 refers to the extent of change. FC9 refers to
the duration of change. The swiftness of change is
presented in FC10. Finally FC11 is the criterion of
the anticipation of change.
4.2 Determination of the Flexibility
Scores
We have developed a questionnaire using the
taxonomy of Regev et al. The questionnaire was
specifically designed to seek responses from the
most senior personnel responsible for the
development of the different BPMSs. Using the
responses to this questionnaire, we calculated the
derived flexibility score (FS) for each BPMS.
It’s important to mention that the FCs have the
same weight. We have specified for the FCs a scale
in order to get consistent results. The table 1
presents the FCs’ scales.
Table 1: The FC scales.
FC SCALE
FC1, FC2
yes : 1
no : 0
FC3, FC4, FC5,
FC6,FC7
0 (not descriptive)
to
5 (very descriptive)
FC8, FC9, FC10, FC11
1: only one of the values,
2 : both,
0: none
Using theses scales, we have calculated a Flexibility
Score (FS) for each of the BPMSs.
The ProdProc system supports only changes
caused by modification of the process definition.
While ESProNa and DECLARE support changes
at the instance level. In ADEPT2,
PHIharminicFlows and JRules BPMS, process
changes can take place at the type as well as the
instance level. The ADEPT2 interviewee said “Our
system is very flexible in this respect. It allows for
changes of single instances (e.g. to deal with
exceptions) as well as changes of a process model at
the type level and the propagation of these changes
to all or selected process instances of this type”.
According to the PHILharmonicFlows interviewee,
“Changes in the PHILharmonicFlows are less
required compared to ADEPT2; instead
PHILharmonicFlows inherently allows for more
execution paths that may be flexibly chosen by
users”.
The different perspectives, defined in the Regev
et al. taxonomy, were considered in the different
BPMSs, with verifying extents.
By combining the different perspectives with a
medium extent, a comprehensive description of a
process can be accomplished in the ESProNa
system. The ESPRoNa interviewee said when
explaining the behavioural perspective : “In
ESPRoNa only the default-path through a process
model is modelled and the preconditions are
modelled inside the process-perspectives, the user
sometimes cannot see this when only
looking/concentrating to the flow as it is implicit in
that situation”.
ADEPT2 offers powerful concepts for
supporting the five perspectives which allow a
ICEIS2015-17thInternationalConferenceonEnterpriseInformationSystems
294

comprehensive description of the business
processes. It’s the most successful BPMS supporting
all the subjects of change defined in the taxonomy of
Regev et al..
In PHILharmonicFlows BPMS, the behavioral
perspective (FC5) of the software system is
represented in two different levels of granularity:
micro and macro process types. A micro process
type defines the behaviour of a particular object
type. A macro process type, in turn, defines how
object instances interact with other objects instances.
Also, by modeling the object types and their
relations, fundamental insights into information
perspective (FC6) can be obtained using
PHILharmonicFlows BPMS (Chiao et al., 2013b).
Additionally, the organizational perspective (FC7)
of the software system is represented using user
roles and types.
The functional (FC3) and operational (FC4)
perspectives are well defined in JRules, unlike the
informational (FC6) and organizational perspectives
(FC7).
For Declare, the major efforts have been put in
the development and improvement of the description
of the activities executed during the process (FC4).
ProdProc provides a basic support to the
definition of the information which shall be
exchanged between activities and to describe the
different roles (FC6 and FC7), while the functional
perspective is limited (FC3). In addition, A MART
model in ProdProc does not simply represent a
single production process. Instead, it represents a
configurable production process, whose
configuration can lead to the definition of different
executable processes (FC4) (Campagna, 2012).
In Jrules, the policy manager makes incremental
change. The revolutionary change is identified by
DECLARE, ESProNa and PHILharmonicFlows
BPMS. Both the incremental and revolutionary
changes are only provided in ADEPT2. In ProdProc,
no specific support is provided for explicitly
representing the extent of change (FC8).
Concerning the duration of change (FC9), the
permanent change is supported by all evaluated
BPMS. However, ADEPT2 allows also for the
temporary change.
In the context of the swiftness of change (FC10),
the deferred change is supported by all evaluated
BPMS. However, ADEPT2 allow also for the
immediate change. In fact, ADEPT2 applies
immediately to all family-related process models
and instances, even the running ones (includes
runtime migration strategies).
For the anticipation of the change (FC11), in
Declare, Jrules and PHILharminicFlows BPMS,
explicit support for planned changes is provided.
Nevertheless, to deal with exceptions BPMSs must
support unplanned changes. For instance, the
ADEPT2 and ESProNa BPMS provide also some
form of ad-hoc changes. The ad-hoc changes which
are based on adaptation patterns are possible in
ADEPT2. The anticipation of the change, either
planned or ad-hoc, are not considered in ProdProc.
The score for the output analysis of flexibility
criteria for each of the tools is presented in table 2.
Table 2: Calculated flexibility scores for each BPMS.
DECLARE
ESProNa
JRules/
JSolver
ADEPT 2 / AristaFlow
BPM Suite
PHIharmonic
Flows
PordProc
FC1
0 0 1 1 1 1
FC2
1 1 1 1 1 0
FC3
2 3 4 4 2 2
FC4
5 3 4 5 3 4
FC5
2 4 3 3 5 4
FC6
2 3 1 5 5 3
FC7
2 3 2 5 4 3
FC8
1 1 1 2 1 0
FC9
1 1 1 2 1 1
FC1
0
1 1 1 2 1 1
FC1
1
1 2 1 2 1 0
We calculated then the FS for the different BPMSs
(table 3). To do that, we sum the different FC taking
into account the scales. The calculated FS is
calculated as follows:
Calculated FS = FC1 + FC2+ FC3/5 +
FC4/5 + FC5/5 + FC6/5 + FC7/2 + FC8/2+
FC9/2+ FC10/2
(1)
Table 3: Calculated FS for the different BPMS.
BPMS Calculated FS
DECLARE 5,6
ESProNa 6,7
JRules/JSolver 6,8
ADEPT 2 / AristaFlow
BPM Suite
9,9
PHILharminicFlows 7,8
ProdProc
5
The different BPMSs are evaluated according to the
taxonomy of Regev et al. defined in the previous
section. We conclude that the different BPMSs
provide flexibility with different degrees.
EvaluationofParadigmsEnablingFlexibility-BPMSsComparativeStudy
295

5 COMPARISON OF
FLEXIBILITY DEGREE FOR
DIFFERENT PARADIGMS
5.1 Existing Paradigms
Literature provides various process modelling
paradigms that we classify into: constraint-based,
rule-based, case handling and adaptive process
support paradigms. Each category has its underlying
approach that may be examined in terms of its
appropriateness to flexible process modelling.
Constraint-based paradigm focuses on
constraints as rules that have to be followed during
the process execution. Possible executions of
constraint-based models are specified implicitly as
all executions that satisfy the model constraints,
which make it not necessary to explicitly predict all
possible executions in advance.
The central concept, for the case handling
paradigm, is the case and not the activities or the
routing. The case is the ‘‘product’’ which is
manufactured, and at any time workers should be
aware of this context. Case Handling is a paradigm
for supporting flexible and knowledge-intensive
processes by strongly integrating them with data
(Chiao et al., 2013a). Case Handling follows a
revolutionary approach, departing from traditional
workflow processes and their strict separation of
data and control flow.
A paradigm is called rule-based if the logic of its
control flow, data flow and resource allocation is
declaratively expressed by means of business rules.
Business rules are recognized as powerful
representation forms that can potentially define the
semantics of business process models and business
vocabulary.
The adaptive Process Management can be seen
as an evolutionary technique, solidly based on
traditional workflow, while extending it with
features to dynamically and safely adapt the process
definition at any point in time (Martinho, 2010).
5.2 Classification of the BPMSs
According to the questionnaire’s results, the table 4
resume the answer to the following question:
“Which BPMS underlies modelling or execution
paradigm?”
DECLARE is based on rule-paradigms and
constraint-based paradigms. In fact, DECLARE is a
constraint-based system that is focused on modelling
constraints between processes. DECLARE uses the
ConDec modelling language. Modelled constraints
in ConDec are translated to a Linear Temporal Logic
(LTL) formula. An automaton is generated for every
specific constraint in order to verify it. Furthermore,
a second automaton is generated over all constraints.
Also, DECLARE allows for customized
specification of relation types which are constraint
templates. The DECLARE interviewee said
“DECLARE is rule based because it is driven by
Declare rules that are, at the end, LTL rules”.
JRules, which is a business rule management
system, is based on a rule-based approach. A rule-
driven BPMS is a superset of rule management
systems and BPMS, which provides rich
development options for many aspects of BPMS
development, of both procedural (graph) and
declarative rule approach (Lu and Sadiq, 2007). In
addition, Jrules uses another tool, which is JSolver,
which is a constraint solver.
The Case handling paradigm meets the needs and
requirements of object aware processes (Chiao,
Künzle and Reichert,2013a). Thus,
PHILharmonicFlows is based on case handling.
The ProdProc was implemented using constraint
logic programming of such product/process
configuration system. A ProdProc model consists of
a description of a product, a description of a process,
and a set of constraints coupling the two. A product
is modeled as a multi-graph, called product model
graph, and a set of constraints (Campagna, 2012).
The basic design rationale of ESProNa is the
separation of process model, process state and
reasoner. The process model, which represents the
constraints on all processes, is loaded into EsProNa.
The table 4 presents a classification of the
considered BPMSs depending on the paradigms.
Table 4: BPMS classification.
Approach
BPMS
Constraint
based
Rule
based
Case
handling
Adaptive
Process
Support
DECLARE
✔ ✔
ESProNa
✔
JRules/
JSolver
✔ ✔
ADEPT 2 /
AristaFlow
BPM Suite
✔
PHILharminic-
Flows
✔
ProdProc
✔
5.3 Paradigms’ Flexibility
Measurement Score
In this paper, we aim at comparing the flexibility of
ICEIS2015-17thInternationalConferenceonEnterpriseInformationSystems
296

the paradigms using the taxonomy of Regev et al.
We have the calculated FS of the different BPMSs
and we have classified the BPMSs depending on the
paradigms: constraint-based, rule-based, case
handling and adaptive process support. Then we
calculated the average of these FS for each
paradigm. The table 5 presents the PFMS
(paradigms’ flexibility measurement score). This
score is calculated using this formula:
PFMS of (paradigm)= SUM (Calculated FS
of each BMPS that support the paradigm) /
(sum of the BPMS that support the
paradigm)
(2)
For instance, to calculate the rule based paradigm’s
flexibility measurement score, we calculate: PFMS
of (rule-based) = SUM (Calculated FS of
(Declare,JRules/JSolver) / 2 = (5,6 + 6,8)/2 = 6,2
Table 5: Paradigms’ flexibility measurement score.
Paradigm PFMS
Constraint-based 6,03
Rule-based 6,2
Case handling 7,8
Adaptive Process Support 9,9
The results of the evaluation (table 5) underline that
the paradigms, that we have analysed, are able to
provide a support to the requirements of the Regev
et al. taxonomy.
On the other hand, the Adaptive Process Support
paradigm provides a more complete support for
process flexibility. It provides evolution in case of
unanticipated exceptions, both at process schema
and instance level. The strategy used for devising a
recovery procedure is manual, though, and requires
the human intervention at run-time.
The three remaining paradigms, constraint-based,
rule-based and case handling, all three qualify for
business process management. These paradigms
have different principles that determine the
flexibility of the process for different dimensions.
6 RELATED WORKS
Evaluation of flexibility in the business process
domain has a rich research background. Günther et
al. focus on the two paradigms: adaptive process
management and case handling. The authors
compare both approaches with respect to their strong
and weak points (Martinho, 2010).
In (Vullers and Netjes, 2006) authors considered
a number of software tools and examined their
suitability for BPS. The tools have been evaluated
on their modelling capabilities, simulation
capabilities and possibilities for output analysis.
In (Vanderfeesten, Reijers and Aalst, 2007), the
research work investigates to which degree current
case handling systems (FLOWer and Activity
Manager) are able to support Product Based
Workflow Design.
In (Di Ciccio, Marrella and Russo, 2014), they
present a critical analysis of a number of existing
process-oriented approaches by discussing their
efficiency against the knowledge-intensive processes
requirements.
In (Weber, Rinderle-Ma and Reichert, 2007),
they evaluated selected approaches and systems
regarding their ability to deal with process change.
7 CONCLUSIONS
This paper has presented the result of a critical and
comprehensive analysis of the four prominent
paradigms, with the focus on flexibility. The
presented survey gives an overview of BPMSs and
an analysis of the BPMSs’ strengths and weaknesses
in terms of flexibility considering the taxonomy of
Regev et al. The BPMSs were selected because of
their frequent usage in business process management
field.
In future work, using the comparison between
the considered BPMSs, we will adopt a user
guidance generic framework which will provide a
methodological guidance for users to choose the
most appropriate paradigm in order to model their
processes.
ACKNOWLEDGEMENTS
We are very grateful to Pr Ricardo Martinho for his
help, time and consideration.
REFERENCES
Boyer, Jerome and Hafedh Mili. 2011. Agile Business
Rule Development - Process, Architecture, and JRules
Examples. Springer.
Campagna, Dario. 2012. Product and Production Process
Modeling and Configuration PhD thesis Università
Degli Studi Di Perugia.
Chiao, Carolina Ming, Vera Künzle and Manfred Reichert.
2013a. Enhancing the Case Handling Paradigm to
Support Object-aware Processes. in Rafael Accorsi;
EvaluationofParadigmsEnablingFlexibility-BPMSsComparativeStudy
297

Paolo Ceravolo & Philippe Cudré-Mauroux, ed.,
'SIMPDA' , CEUR-WS.org, , pp. 89-103.
Chiao, Carolina Ming, Vera Künzle and Manfred Reichert.
2013b. Integrated Modeling of Process- and Data-
Centric Software Systems with PHILharmonicFlows.
In 1st IEEE Int'l Workshop on Communicating
Business Process and Software Models, Workshop
held in conjunction with the 29th Int'l Conf on
Software Maintenance. IEEE Computer Societey Press
pp. 1-10.
Chiao, Carolina Ming, Vera Künzle and Manfred Reichert.
2014. Towards Schema Evolution in Object-aware
Process Management Systems. In International
Workshop on the Evolution of Information Systems
and their Design Methods (EMISA 2014). Lecture
Notes in Informatics (LNI) Koellen-Verlag.
Dadam, Peter, Manfred Reichert, Stefanie Rinderle-Ma,
Hilmar Acker, Martin Jurisch, Ulrich Kreher, Kevin
Göser and Markus Lauer. 2007. ADEPT2 - Next
Generation Process Management Technology. In
Proceedings Fourth Heidelberg Innovation Forum
(Invited Paper).
Di Ciccio, Claudio, Andrea Marrella and Alessandro
Russo. 2014. Knowledge Intensive Processes:
Characteristics, Requirements and Analysis of
Contemporary Approaches. Journal on Data Semantics
pp. 1-29.
Igler, Michael, Paulo Moura, Michael Zeising and Stefan
Jablonski. 2010. ESProNa: Constraint-Based
Declarative Business Process Modeling. In EDOCW.
IEEE Computer Society pp. 91-98.
Lu, Ruopeng and Shazia Sadiq. 2007. A Survey of
Comparative Business Process Modeling Approaches.
In In Proceedings 10th International Conference on
Business Information Systems (BIS), number 4439 in
LNCS. Springer pp. 82-94.
Maggi, Fabrizio Maria, Marlon Dumas, Luciano García-
Bañuelos and Marco Montali. 2013. Discovering
Data-Aware Declarative Process Models from Event
Logs. In Business Process Management - 11th
International Conference, BPM 2013, Beijing, China,
August 26-30, 2013. Proceedings. pp. 81-96.
Martinho, R. (2010). ConFlex4SP - A Framework for
Controlling Flexibility in Software Processes. PhD
thesis, University of Trás-os-Montes e Alto Douro.
Pesic, M., H.M. Schonenberg and W.M.P. van der Aalst.
2009. DECLARE Demo: A Constraint-based
Workflow Management System. In Business Process
Management Demonstration Track (BPMDemos 2009),
ed. A.K.A. de Medeiros and B. Weber. Vol. 489 of
CEUR Workshop Proceedings CEURWS.org pp. 1-4.
Regev, Gil, Pnina Soffer and Rainer Schmidt. 2006.
Taxonomy of Flexibility in Business Processes. In
Proceedings of the CAISE*06 Workshop on Business
Process Modelling, Development, and Support
BPMDS '06, Luxemburg, June 5-9, 2006.
Reichert, Manfred, Stefanie Rinderle, Ulrich Kreher and
Peter Dadam. 2005. Adaptive Process Management
with ADEPT2. In ICDE. IEEE Computer Society pp.
1113-1114.
Schonenberg, Helen, Ronny Mans, Nick Russell, Nataliya
Mulyar and Wil M. P. van der Aalst. 2008. Towards a
Taxonomy of Process Flexibility. In CAiSE Forum,
ed. Zohra Bellahsène, Carson Woo, Ela Hunt, Xavier
Franch and Remi Coletta. Vol. 344 of CEUR
Workshop Proceedings pp. 81-84.
Vanderfeesten, I., H.A. Reijers and W.M.P. van der Aalst.
2007. An Evaluation of Case Handling Systems for
Product Based Workflow Design. In Proceedings of
the 9th International Conference on Enterprise
Information Systems (ICEIS 2007), Volume on
Information Systems Analysis and Specication, ed. J.
Cardoso, J. Cordeiro and J. Filipe. Institute for
Systems and Technologies of Information, Control and
Communication, INSTICC, Medeira, Portugal pp. 39-
46.
Vullers, M. H. Jansen and M. Netjes. 2006. Business
process simulation a tool survey. In In Workshop and
Tutorial on Practical Use of Coloured Petri Nets and
the CPN.
Weber, Barbara, Stefanie Rinderle-Ma and Manfred
Reichert. 2007. Change Support in Process-Aware
Information Systems - A Pattern-Based Analysis.
Technical Report TR-CTIT-07-76 University of
Twente Enschede, The Netherland.
ICEIS2015-17thInternationalConferenceonEnterpriseInformationSystems
298
