Towards a Security SLA-based Cloud Monitoring Service

Dana Petcu and Ciprian Cr˘aciun

Computer Science Department, West University of Timis¸oara, Timis¸oara, Romania

Keywords:

Cloud Monitoring, Security Monitoring, SLA Management.

Abstract:

Following the community concerns related to security and trust in cloud services, services level agreements

(SLAs) are nowadays revised to include security requirements. In order to speedup their take-up by the service

providers and consumers, security SLAs monitoring at run-time should be ensured. Several tools for SLA

management are available, but most of them are dealing with performance parameters, and not referring to

security. Other tools are available for cloud security monitoring, but not currently related or mapped to security

SLAs. Aiming to design and develop a security SLA-based cloud monitoring service, which can be deployed

or hosted, we identify in this paper the concepts, mechanism and available tools which can lead to a proper

design of such a service, as well as the main barriers to overcome.

1 INTRODUCTION

The monitoring process is a key element to be en-

hanced for upgrading the quality level of the current

cloud services. The monitoring of the cloud and of

its service level agreements (SLAs) in simple terms

like workload, performanceor availability, offers both

to the providers and the consumers the information

necessary to implement mechanisms to prevent or

recover from agreement violations. However there

are only a few SLA management systems which are

hosted or deployable in clouds.

Security monitoring is less developed than op-

erational performance monitoring in cloud environ-

ments. Moreover, it is laging behind other security

features at cloud providers. Security obligations asso-

ciated with a service should be speciﬁed at request in a

SLA (in security SLA, or, shortly, Sec-SLA). The ab-

sence of security aspects in the currently used SLAs,

combined with the lack of methods for making objec-

tive comparisons between different service offerings,

makes it impossible for providers to offer trustworthy

services to their customers (Bernsmed et al., 2011).

Moreover, according (Wagner et al., 2012), cloud ser-

vices provider contracts will not provide detailed and

substantive security SLAs before 2016.

In order to address these problems, we are

interested in developing an open-source SLA-based

Cloud security monitoring system that can act as

monitoring-as-a-service or can be deployed in con-

junction with the open-source mOSAIC PaaS (Petcu

et al., ) which offers a certain degree of portability of

applications consuming IaaSs. An incipient form of

SLA-based monitoring system with no security pa-

rameters was designed, prototyped and reported in

(Rak et al., 2011). The role of a new SLA-based cloud

security monitoring service, in the SPECS framework

based on mOSAIC PaaS, under design and devel-

opment, was exposed in (Rak et al., 2013): a Sec-

SLA that is negotiated will be monitored for compli-

ance, and alerts will be generated in case of security

changes or in case of Sec-SLA violations, leading to

its enforcement. In this paper we discuss the avail-

ability or lack of adequate concepts, mechanisms and

tools to be reused when such a service is designed.

The next section identiﬁes the state-of-art, while its

following section evaluates the appropriateness of the

existing solutions for the new service.

2 RELATED WORK

We have recently collected data and reports about the

current tools and prototypes that are availablefor SLA

monitoring or security monitoring in clouds. Tables

1-2 are pointing towards the most signiﬁcant ones (not

exhaustive lists). Here the tools and frameworks are

organized in three categories: open-source, commer-

cial or research prototypes.

Surprisingly, there is no report until now of any

effort for developing a Sec-SLA based Cloud moni-

toring service. In what follows we point to some of

598

Petcu D. and Cr

aciun C..

Towards a Security SLA-based Cloud Monitoring Service.

DOI: 10.5220/0004957305980603

In Proceedings of the 4th International Conference on Cloud Computing and Services Science (CLOSER-2014), pages 598-603

ISBN: 978-989-758-019-2

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

Table 1: Open-source and Commercial Cloud monitoring tools which are SLA-based or security-oriented.

Acronym Short description

Open-source SLA-oriented Cloud monitor tools

CloudCompass

SLA-aware PaaS featuring an extension of the SLA speciﬁcation WS-Agreement for cloud. The

monitor module performs dynamic assessment of the QoS rules from active SLAs.

Sandpiper

Automates the process of monitoring, detecting hotspots and reconﬁguring VMs whenever ne-

cessary. The monitoring system uses thresholds to check whether SLAs can be violated.

SLA@SOI

SLA management platform that includes at monitoring layer EVEREST, a general-purpose en-

gine for monitoring the behavioural and quality properties of distributed systems based on events

Open-source Cloud security monitor tools

FBCrypt

Prevents information leakage; it encrypts the I/O between a client and a user VM using a virtual

machine monitor -VMM: intercepts reads of virtual devices by a user VM and decrypts inputs.

Snorby

Application for network/host security monitoring; integrates with intrusion detection systs (IDS)

Commercial SLA-oriented Cloud monitor tools

NMS

‘NimSoft Monitoring Solution’ is a uniﬁed monitoring dashboard able to monitor data centers

of both private and public Clouds; it can be used for monitoring SLAs.

Site24x7

Online website monitoring service continuously checking the availability of web-sites/apps; it

includes application performance monitoring, SLA management, uptime reporting.

Commercial Cloud security monitor tools

CipherCloud

Service and virtual appliance delivering a set of protection controls including encryption, toke-

nization, activity monitoring, data loss prevention, malware detection.

CloudFlare

Protects websites (optimize delivery, blocks threats, limit abusive bots and crawlers): after the

enrolement of the website in the community, its web trafﬁc is re-routed.

CloudPassage

Automate security and compliance: integrated into platforms like OpenStack or by providers

like AWS, it features a cloud-agnostic architecture, continuous security monitoring/control, and

REST APIs for integration with automation tools like Puppet and security systs like Splunk

MARS

Cisco’s ‘Monitoring, Analysis & Response System’ designed to monitor logs and threats

SPAE

‘Security Performance Availability Engine’ is a network monitoring tool supporting a various

protocols and using SNMP; enables consumers to monitor networked Cloud resources.

Splunk’ Storm

Cloud-based service for analyzing machine data generated by web sites, applications, servers,

networks, mobile device.

ThreatStack

Deployable, proﬁling for normal behaviour, real-time monitoring: user loggings, network con-

nections, data send to ThreatStack analyzer servers, ﬁrewall policies, forensics, audit alerts

the issues that have led to this current status, with ac-

cent on complexity and novelty.

Cloud monitoring is done at high or low level

(Aceto et al., 2013). A high-level monitoring is re-

lated to information on the status of the virtual plat-

github.com/angarg12/cloudcompaas-common

lass.cs.umass.edu/projects/virtualization/sandpiper

sourceforge.net/apps/trac/sla-at-soi/

ksl.ci.kyutech.ac.jp/oss/fbcrypt

github.com/snorby/snorby

www.nimsoft.com/solutions/cloud-monitoring

www.site24x7.com

www.ciphercloud.com

www.cloudﬂare.com/overview

cloudpassage.com

www.cisco.com/en/US/products/ps6241/

shalb.com/en/spae/spae

features/

www.splunkstorm.com

www.threatstack.com

form, collected at the middleware, application and

user layers by service providers or consumers through

platforms and services operated by themselves or by

third parties. A low-level monitoring is related to in-

formation collected by the service provider and usu-

ally not exposed to the consumer, and is concerned

with the status of the physical infrastructure.

The security monitoring is falling mostly in the

category of high-level monitoring. For low-level

monitoring speciﬁc utilities for collecting information

about security are referring to software vulnerabilities

or bugs(at OS and middlewarelayer), IDS or ﬁrewalls

(at network layer), authentication systems or surveil-

lance (at facility layer), workload, voltage or temper-

ature, memory or CPU (at hardware level).

The deﬁnition of a security that can be quantiﬁ-

able and can be expressed in a service level is a very

complex task (de Chaves et al., 2010). In particular

the deﬁnition of the security metric is challenging and

TowardsaSecuritySLA-basedCloudMonitoringService

599

Table 2: Research prototypes of Cloud monitoring tools which are SLA-based or security-oriented.

Acronym Short description

SLA-oriented Cloud monitoring tools

CASViD ‘Cloud application SLA violation detection’ aims at SNMP-based monitoring and detecting SLA

violations at application layer; it includes tools for resource allocation (Emeakaroha et al., 2012).

LoM2HiS ‘Low-level Metrics to High-level SLA monitoring and mapping’ monitors resource metrics and

maps the metric values to high-level SLA parameter objectives (Emeakaroha et al., 2010).

QoS-MONaaS‘Quality of Service MONitoring as a Service’ allows to describe in a formal SLA the key perfor-

mance indicators of interest and the alerts in case of SLA violation (Adinolﬁ et al., 2012).

Cloud security monitoring tools

Aftersight Can be used to analyze the behavior of a VM; it decouples execution of the VMs from this analysis

of the execution; it records non-deterministic events, inputs to a VM (Chow et al., 2008).

CloudSec Provides active, transparent and real-time security monitoring for multiple concurrent VMs hosted

on a cloud platform in an IaaS setting (Ibrahim et al., 2011).

CloudWatcher Security monitoring as a service automatically detouring network packets to be inspected by pre-

installed network security devices (Shin and Gu, 2012).

HyperWall A hypervisor that is not be able to snoop on, or modify, the data (or code) that is exchanged

between the VM and the resource, or on computation done in the VM (Szefer, 2013).

K-Tracer Dynamically analyzes Windows kernel-level code and extracts malicious behavior from rootkits,

based on QEMU virtualization technology (Lanzi et al., 2009).

KVMSec Extension to the KVM to check the integrity of guest VMs by adding modules in host & guest

side: guest OS sends information to the host about the VM status (Lombardi and Di Pietro, 2009).

Lares Based on two VMs: an untrusted monitored VM and a security VM. The last monitors the ﬁrst

and can see into the state of the monitored VM using an introspection API (Payne et al., 2008).

Livewire An IDS which uses the VMM to pull the intrusion detection logic out of a monitored VM; the IDS

VM runs on the same server as the VM being monitored (Garﬁnkel and Rosenblum, 2003).

Lycosid Detects hidden process in VMs comparing guest view with a VMM image (Jones et al., 2008).

MAVMM A VMM for malware analysis extracts features of the applications running inside a guest OS:

execution trace, memory pages, system calls, disk accesses, network (Nguyen et al., 2009).

MISURE ‘Monitoring Infrastructure using Streams on an Ultra-scalable, near-Realtime Engine’ is a

monitoring-as-a-servicefor data analysis; uses stream processors like S4, Storm (Smit et al., 2013)

NICKLE A VMM based on memory shadowing: the trusted VMM maintains a shadow physical memory

for a running guest VM & performs real-time authentication of the kernel code (Riley et al., 2008).

Overshadow Protects the privacy and integrity of application data in a guest VM even if the guest OS is com-

promised (the VMM provides guest physical memory pages accordingly) (Chen et al., 2008).

PoKeR ‘Proﬁler of Kernel Rootkits’ proﬁles four rootkit characteristics: hooking behavior, kernel object

modiﬁcations, impact on user applications, code injection (Riley et al., 2009).

Revirt Ensure secure logging and logs information: real-time clock, keyboard, mouse events, user inputs,

system calls, enabling admin to replay the execution of VM/ analyze attacks (Dunlap et al., 2002).

Rkproﬁler Sandbox-based malware tracking using QEMU virtualization for Windows (Xuan et al., 2009).

SecMon Secure introspection framework using a VMM for Windows OS (Wu et al., 2013).

SecVisor Hypervisor supporting one guest VM to protect it from rootkits (Seshadri et al., 2007).

SIM ‘Secure-in-vm monitoring’: monitoring code in the VM with monitored code (Sharif et al., 2009).

VMWatcher An out-of-the-box malware detection mechanism addressing the gap between observed events at

the VMM level and guest OS context; ensures strong tamper-resistance (Jiang et al., 2007).

TrustVisor Hypervisor which protects pieces of application logic to be execute in isolation: the programmer

speciﬁes these pieces as well as valid entry and exit points (McCune et al., 2010).

numbers are not appropriate as the security is related

to a variety of properties, varying from a service per-

formance to process maturity.

Fortunately, security parameters for a security

monitoring framework were deﬁned and classiﬁed re-

cently in (Hogben and Dekker, 2012). Beyond the pa-

rameter deﬁnition, methods and techniques for mea-

suring parameters in practice were deﬁned. Moreover,

thresholds were established to indicate when to trig-

ger an event (how to determine the ranges of parame-

ters that would trigger an incident report, or response

and remediation based on real-time or regular service

CLOSER2014-4thInternationalConferenceonCloudComputingandServicesScience

600

level reports). However security indicators were not

provided (a security indicator is an observable char-

acteristic that correlates with a desired security prop-

erty; the set of feasible indicator values is expected to

form a nominal scale).

To overcome this problem, a step forward was

made in (Pannetrat et al., 2013) by providing an

attribute-based security property vocabulary and by

developing security properties in abstract terms and

as a properties with a set of deﬁned attributes.

Cloud security monitoring is currently done on-

premises, on the monitored infrastructure, or via a

SaaS. In the case of monitoring on-premises, a se-

curity tool is able to make use of speciﬁc APIs as

well to collect logs from cloud services. In the sec-

ond case, of monitoring on monitored IaaS, a secu-

rity tool is loaded directly into an IaaS (no high band-

width requirement, possible some high storage costs,

but currently there is a lack of a uniﬁed view on the

approach). In the third case, monitoring data is ob-

tained from the cloud service (if available), and hand

it to a managed security service provider.

Looking at the available tools for Cloud security

monitoring systems displayed in Tables 1-2, we see

that most of them are low level. Their approach is

either to take a complete VM as the monitoring gran-

ularity, such that they cannot capture the security in-

cidents within individual VMs, or to focus on speciﬁc

monitoring function that cannot be used for heteroge-

neous VMs concurrently running on one cloud node

(Zou et al., 2013).

The few SLA management systems that are in-

cluding monitoring features are comprehensive in

terms of covering various cloud services. In particular

several domain speciﬁc languages were developed to

describe the monitored properties present in the SLA

as well as the alert or SLA violation thresholds(e.g. in

SLA@SOI and QoS-MONaaS, the ﬁrst being re-used

in various follow-up research projects). LoM2HiS is

the ﬁrst try to map high-level parameters objectives

to low-level metrics. Despite the degree of granular-

ity of those tools, most of their reported use-cases are

concerned with performance monitoring. The secu-

rity parameters have not been taken into consideration

by them.

3 POTENTIAL COVERAGE FOR

SEC-SLA MONITORING

We assume in what follows that the Sec-SLA to be

adopted by the cloud service providers and consumers

follows the vocabulary reported in (Pannetrat et al.,

2013), including also its security indicators. We are

interested in mapping the available mechanisms and

tools to the various security properties from this vo-

cabulary and in ﬁlling the gaps where this mapping

is not possible. As targeting an open-source service,

we are referring here only to the open-source (exten-

sible) tools described in the previous section, as well

as to other open-source general monitoring tools, like

collectl

, CloudCmp

, Cloudstone

, Ganglia

Groundwork

, Hyperic-HQ

, JasMINe

, MonAL-

ISA

, Nagios

, PCMons

, SIGAR

, Zabbix

We have build a matrix of coverage visible in Ta-

bles 3 and 4. We considered ﬁve levels for indicate

if a monitor feature is provided by a service provider

or a consumer software (0 – not possible; 1 – there

are some serious issues with the proposed property;

2 – although technically conceivable it is less likely

to be implemented due to cost & effort; 3 – not usu-

ally provided, or it is complicated to provide; 4 – usu-

ally happens) according to three categories, IaaS (I),

P/SaaS (P: provider oriented) and App (A: consumer

oriented, i.e. a VM in case of IaaS, or a software ser-

vice in case of a PaaS/SaaS). S stands for a deployable

service, while L refers to a programming library. We

then considered in the last two columns the case of

a deployable service and a programming library; we

reﬁned further the expectation levels in eleven levels

(a – possible with the current tools to monitor and en-

force; b – possible with the current tools to monitor;

c – if tools are build to monitor/enforce; d – if tools

are build to monitor; e – if tools are build to monitor

but not straightforward; f – if tools are build to mon-

itor/enforce but it is complex issue; g – if tools are

build to monitor but it is complex issue; h – if tools

are build to enforce but it is complex issue; i – al-

though technically conceivable it is less likely to be

implemented due to cost & effort; j – less likely to be

implemented; k – not possible).

Such a matrix indicates not only the hot-spots in

developing a Sec-SLA monitoring system (the ones

near to zero, or near k), but also the probability that

a service provider will comply with the Sec-SLA. For

example, as ‘4’ indicates ‘easy to comply with’, the

collectl.sourceforge.net

github.com/angl/cloudcmp

radlab.cs.berkeley.edu/wiki/Projects/Cloudstone

ganglia.sourceforge.net

sourceforge.net/projects/gwmos

sourceforge.net/projects/hyperic-hq

maven.ow2.org/maven2/org/ow2/jasmine

monalisa.caltech.edu/monalisa

Download.htm

nagios.sourceforge.net

code.google.com/p/pcmons

sourceforge.net/projects/sigar

www.zabbix.com/download.php

TowardsaSecuritySLA-basedCloudMonitoringService

601

Table 3: Matrix of coverage for Sec-SLA monitoring by

current mechanisms and tools.

Security property I P A S L

Software integrity protection 3 3 2 g i

Software integrity detection 0 3 2 i h

Malware protection 0 3 3 k i

Data alteration prevention 2 0 0 k k

Data alteration detection 4 4 3 d d

Data access level 4 4 4 c c

External data exchange conﬁdentiality 3 4 4 c c

Authentication of data origin 3 3 3 c c

Network authenticated server access 4 4 4 c c

Network mutually authenticated channel 3 3 3 c c

Non repudiation of origin 3 3 3 e e

Non repudiation of receipt 2 2 2 i i

Information ﬂow control: blacklist 4 3 4 a a

Information ﬂow control: whitelist 4 3 4 a a

% of systems with time synchronization 2 2 2 g g

User traceability 2 3 4 i d

Security event storage integrity level 3 3 3 h h

Tenant isolation level 4 4 4 h k

Collocation indistinguishability 3 3 2 k k

Data portability 3 3 3 c c

Mean time between incidents 4 4 4 b b

% of timely incident reports 4 4 4 b b

% of timely incident resolutions 4 4 4 b b

User authentication & identity assurance level 4 4 4 a a

Password storage protection level 4 4 4 a a

% of timely suspension of unused accounts 4 4 4 b b

Limitation of failed user authentications 4 4 4 a a

Inactive session blocking 4 4 4 a a

Limitation parallel active sessions 4 4 4 a a

Cryptographic brute force resistance 4 4 4 i i

Key generation quality 4 1 1 k k

Key access control level 4 4 4 i i

Cryptographic module protection level 3 3 2 f f

% of systems with formal risk assessment 3 3 3 j j

% of systems with tested controls 3 3 3 j j

Country level anchoring 3 3 3 a a

Personal data: consultation ability 2 2 2 k k

Personal data: modiﬁcation ability 2 2 2 k k

Personal data: deletion ability 2 2 2 k k

Personal data: timely access 2 2 2 k k

Vulnerability exposure level 3 3 3 h h

% of timely vulnerability corrections 4 4 4 b b

% of timely vulnerability reports 4 4 4 b b

Data deletion quality level 4 1 1 k k

% of timely effective deletions 4 4 4 k k

Data leakage detection 2 2 2 f f

Data leakage prevention 2 2 2 f f

Storage freshness 4 4 4 g g

Storage retrievability 2 2 2 g g

% durability 4 4 4 g g

Authentication feature count 2 3 3 k k

Tamper evidence 2 2 2 k k

Tamper resistance 2 2 2 k k

% of uptime 4 4 4 b b

% of processed requests 4 4 4 b b

% of timely recoveries 4 4 4 b b

Mean time between failure 4 4 4 b b

Recovery point objective 4 4 4 j j

Recovery time actual 4 4 4 j j

Recovery success ratio 4 4 4 j j

Table 4: Continuation of Table 3.

Security property I P A S L

Elasticity reserved capacity 3 3 3 k k

% of timely provisioning requests 4 4 4 b b

Allocation limitation 4 4 4 b b

Denial of service attack resistance 4 4 4 k k

% of compliant devices 4 4 4 b b

% of compliant software 4 4 4 b b

% of timely conﬁguration change notiﬁcations 4 4 4 b b

Conﬁguration change reporting capability 4 4 4 b b

38 appearances of ’4’s in 68 security properties means

an expectation of 56% for an IaaS provider to easily

comply. This percentage can reﬂect partially a lack

of knowledge about some tools availability or a cer-

tain subjectivityin deﬁning implementation difﬁculty.

However, such uncertainty can generate a certain de-

viation from the above percentage, but not leading it

to 100%. With this percentange we can explain why

Sec-SLA monitoring systems are not yet in place.

4 CONCLUSIONS

Multiple conceptual and technical barriers must be

overcome in order to implement a Sec-SLA monito-

ring service. Some of them were underlined in this pa-

per: lack of acceptance and maturity of the SLA man-

agement systems, difﬁculty of mapping high level se-

curity properties to low level monitoring parameters,

lack of deployment-layer agnosticism, extra comple-

xity introduced by the virtualization, and so on. The

identiﬁcation of the available concepts, methods and

available tools is only the ﬁrst step for the implemen-

tation of the SPECS’s Sec-SLA monitoring system in

its two intended versions, deployable or hosted ser-

vice. The ﬁrst stable version of the open-source code

is expected to be available in one year.

ACKNOWLEDGEMENTS

This research is partially supported by the Roma-

nian grant PN-II-ID-PCE-2011-3-0260 (AMICAS),

as preliminary study for the grant FP7-ICT-2013-10-

610795 (SPECS).

REFERENCES

Aceto, G., Botta, A., De Donato, W., and Pescap`e, A.

(2013). Survey cloud monitoring: A survey. Com-

puter Networks, 57(9):2093–2115.

Adinolﬁ, O., Cristaldi, R., Coppolino, L., and Romano, L.

CLOSER2014-4thInternationalConferenceonCloudComputingandServicesScience

602

(2012). Qos-monaas: A portable architecture for qos

monitoring in the cloud. SITIS ’12, pages 527–532.

Bernsmed, K., Jaatun, M. G., Meland, P. H., and Undheim,

A. (2011). Security slas for federated cloud services.

ARES ’11, pages 202–209.

Chen, X., Garﬁnkel, T., Lewis, E. C., Subrahmanyam, P.,

Waldspurger, C. A., Boneh, D., Dwoskin, J., and

Ports, D. R. (2008). Overshadow: A virtualization-

based approach to retroﬁtting protection in commod-

ity operating systems. SIGOPS Oper. Syst. Rev.,

42(2):2–13.

Chow, J., Garﬁnkel, T., and Chen, P. M. (2008). Decoupling

dynamic program analysis from execution in virtual

environments. ATC ’08, pages 1–14.

de Chaves, S., Westphall, C., and Lamin, F. (2010). Sla per-

spective in security management for cloud computing.

ICNS ’10, pages 212–217.

Dunlap, G. W., King, S. T., Cinar, S., Basrai, M. A.,

and Chen, P. M. (2002). Revirt: Enabling intrusion

analysis through virtual-machine logging and replay.

SIGOPS Oper. Syst. Rev., 36(SI):211–224.

Emeakaroha, V., Brandic, I., Maurer, M., and Dustdar, S.

(2010). Low level metrics to high level slas - lom2his

framework: Bridging the gap between monitored met-

rics and sla parameters in cloud environments. HPCS

’10, pages 48–54.

Emeakaroha, V., Ferreto, T., Netto, M., Brandic, I., and

De Rose, C. (2012). Casvid: Application level mon-

itoring for sla violation detection in clouds. COMP-

SAC ’12, pages 499–508.

Garﬁnkel, T. and Rosenblum, M. (2003). A virtual machine

introspection based architecture for intrusion detec-

tion. NDSS’03, pages 191–206.

Hogben, G. and Dekker, M. (2012). Procure secure. a guide

to monitoring of security service levels in cloud con-

tracts. Technical report, European Network and Infor-

mation Security Agency (ENISA).

Ibrahim, A., Hamlyn-Harris, J., Grundy, J., and Almorsy,

M. (2011). Cloudsec: A security monitoring appliance

for virtual machines in the iaas cloud model. NSS ’11,

pages 113–120.

Jiang, X., Wang, X., and Xu, D. (2007). Stealthy mal-

ware detection through vmm-based ”out-of-the-box”

semantic view reconstruction. CCS ’07, pages 128–

138.

Jones, S. T., Arpaci-Dusseau, A. C., and Arpaci-Dusseau,

R. H. (2008). Vmm-based hidden process detection

and identiﬁcation using lycosid. VEE ’08, pages 91–

100.

Lanzi, A., Sharif, M. I., and Lee, W. (2009). K-tracer:

A system for extracting kernel malware behavior.

NDSS’09.

Lombardi, F. and Di Pietro, R. (2009). Kvmsec: A security

extension for linux kernel virtual machines. SAC ’09,

pages 2029–2034.

McCune, J., Li, Y., Qu, N., Zhou, Z., Datta, A., Gligor,

V., and Perrig, A. (2010). Trustvisor: Efﬁcient tcb

reduction and attestation. SP ’10, pages 143–158.

Nguyen, A., Schear, N., Jung, H., Godiyal, A., King, S.,

and Nguyen, H. (2009). Mavmm: Lightweight and

purpose built vmm for malware analysis. ACSAC ’09,

pages 441–450.

Pannetrat, A., Hogben, G., Katopodis, S., Spanoudakis, G.,

and Cazorla, C. S. (2013). D2.1: Security-aware sla

speciﬁcation language and cloud security dependency

model. Technical report, Certiﬁcation infrastrUcture

for MUlti-Layer cloUd Services (CUMULUS).

Payne, B., Carbone, M., Sharif, M., and Lee, W. (2008).

Lares: An architecture for secure active monitoring

using virtualization. SP ’08, pages 233–247.

Petcu, D., Di Martino, B., Venticinque, S., Rak, M., M´ahr,

T., Esnal Lopez, G., Brito, F., Cossu, R., Stopar, M.,

Sperka, S., and Stankovski, V. Experiences in build-

ing a mosaic of clouds. Journal of Cloud Computing:

Advances, Systems and Applications, 2:12.

Rak, M., Luna, J., Petcu, D., Casola, V., Suri, N., and Vil-

lano, U. (2013). Security as a service using an sla-

based approach via specs. CloudCom ’ 13.

Rak, M., Venticinque, S., M´ahr, T., Echevarria, G., and Es-

nal, G. (2011). Cloud application monitoring: The

mosaic approach. CloudCom ’11, pages 758–763.

Riley, R., Jiang, X., and Xu, D. (2008). Guest-transparent

prevention of kernel rootkits with vmm-based mem-

ory shadowing. RAID ’08, pages 1–20.

Riley, R., Jiang, X., and Xu, D. (2009). Multi-aspect pro-

ﬁling of kernel rootkit behavior. EuroSys ’09, pages

47–60.

Seshadri, A., Luk, M., Qu, N., and Perrig, A. (2007). Secvi-

sor: A tiny hypervisor to provide lifetime kernel code

integrity for commodity oses. SOSP ’07, pages 335–

350.

Sharif, M. I., Lee, W., Cui, W., and Lanzi, A. (2009). Secure

in-vm monitoring using hardware virtualization. CCS

’09, pages 477–487.

Shin, S. and Gu, G. (2012). Cloudwatcher: Network secu-

rity monitoring using openﬂow in dynamic cloud net-

works (or: How to provide security monitoring as a

service in clouds?). ICNP ’12, pages 1–6.

Smit, M., Simmons, B., and Litoiu, M. (2013). Distributed,

application-level monitoring for heterogeneous clouds

using stream processing. Future Generation Com-

puter Systems, 29(8):2103–2114.

Szefer, J. M. (2013). Architectures for Secure Cloud Com-

puting Servers. PhD thesis, University of Princeton.

Wagner, R., Heiser, J., Perkins, E., Nicolett, M., Kavanagh,

K. M., Chuvakin, A., and Young, G. (2012). Predicts

2013: Cloud and services security. Technical report,

Gartner ID:G00245775.

Wu, X., Gao, Y., Tian, X., Song, Y., Guo, B., Feng, B.,

and Sun, Y. (2013). Secmon: A secure introspec-

tion framework for hardware virtualization. PDP ’13,

pages 282–286.

Xuan, C., Copeland, J., and Beyah, R. (2009). Toward re-

vealing kernel malware behavior in virtual execution

environments. RAID ’09, pages 304–325.

Zou, D., Zhang, W., Qiang, W., Xiang, G., Yang, L. T., Jin,

H., and Hu, K. (2013). Design and implementation of

a trusted monitoring framework for cloud platforms.

Future Generation Computer Systems, 29(8):2092 –

2102.

TowardsaSecuritySLA-basedCloudMonitoringService

603
