Performance Prediction for Unseen Virtual Machines

John O’Loughlin and Lee Gillam

Department of Computing, University of Surrey, Guildford, GU2 7XH Surrey, U.K.

Keywords: Cloud Computing, Performance Prediction, Virtualisation, Scheduling.

Abstract: Various papers have reported on the differential performance of virtual machine instances of the same type,

and same supposed performance rating, in Public Infrastructure Clouds. It has been established that instance

performance is determined in large part by the underlying hardware, and performance variation is due to the

heterogeneous nature of large and growing Clouds. Currently, customers have limited ability to request

performance levels, and can only identify the physical CPU backing an instance, and so associate CPU

models with expected performance levels, once resources have been obtained. Little progress has been made

to predict likely performance for instances on such Public Clouds. In this paper, we demonstrate how such

performance predictions could be provided for, predicated on knowledge derived empirically from one

common Public Infrastructure Cloud.

1 INTRODUCTION

Infrastructure as a Service (IaaS) Clouds offer

resources such as object storage, attachable storage,

configurable networks and virtual machines (VMs)

to customers over the internet, and are available to

anybody with an internet connection and a credit

card. Resources are provided on-demand, meaning

they are provisioned at the time of the request, and

can be ‘terminated’ when no longer needed.

Together with an ‘illusion of infinite capacity’

(Armbrust et al., 2009) publically available

computing environments allow customers to grow

and shrink their usage as required and when

required, and customers can be charged, typically,

on a per-hour basis for resources used. The

provider’s ability to support this is referred to as

elasticity; it is this that differentiates Clouds from

dedicated hosting environments where servers can

take up to a day to provision, are charged on a per-

month basis, and require customers to enter into

contracts for a pre-specified period of time

irrespective of usage.

Infrastructure Clouds are the first successful

attempt at public delivery of compute resources, and

naturally there are concerns about migrating on-

premise systems to them. Such concerns include:

security, availability, vendor lock-in and

performance; this latter concern of performance, in

particular compute performance, is the focus of this

paper.

As the largest, and arguably the de facto

standard, of Infrastructure Clouds, performance of

instances on EC2 has been widely studied, although

mainly for its suitability for HPC and scientific

computing. Consequently, differential performance

of instances of the same type has been reported on

by a number of authors, (Phillips, Engen, and Papay,

2011, and Ou et al., 2012) and it is now established

that performance variation is due to the

heterogeneous nature of large and growing Clouds.

Although EC2 acknowledges heterogeneity,

claiming that instances of the same type should

deliver a ‘consistent and predictable’ level of

compute (Amazon EC2 FAQS, no date) – despite

the published evidence to the contrary– is certainly

not ideal.

As users scale their infrastructure, knowing how

many instances they should start in order to meet

their needs requires an understanding of the

deliverable performance. At present users are,

potentially, in the unsatisfactory position of either

(1) having to guess how many instances to start in

order to obtain the desired number of satisfactory

ones, with obvious cost implications, or (2)

obtaining a number of instances that might not

deliver the required performance. EC2 customers

who are building services for their own customers

on top of these instances may run the risk of failing

any SLAs they provide unless they undertake

rigorous performance evaluations themselves.

O’Loughlin J. and Gillam L..

Performance Prediction for Unseen Virtual Machines.

DOI: 10.5220/0004840900700077

In Proceedings of the 4th International Conference on Cloud Computing and Services Science (CLOSER-2014), pages 70-77

ISBN: 978-989-758-019-2

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

In this paper, we consider the problem of

determining the expected performance of a set of

instances before they are provisioned. The rest of

this paper is structured as follows: Section 2

provides background information on Cloud

structure, and in section 3 we discuss CPU model

distribution in a number of AZs as is relevant to the

discussions in this paper. In section 4 we describe

our AZ model, and Sections 5-7 discusses

simulations of VM offerings. In section 8 we

compare our simulated data with real data from

Amazon’s “us-west-1c” zone. In section 9 we

discuss assumptions made in our simulations and

how this relates to other scheduling algorithms one

could use. In section 10 we review related work, and

section 11 concludes and discusses future work.

2 CLOUD INFRASTRUCTURE

EC2, Google Compute Engine (GCE), HP Public

Cloud and Rackspace OpenCloud (AWS Global

Infrastructure, no date, Google Cloud Platform, no

date, HP Public Cloud, no date and Rackspace

Global Infrastructure, no date) structure their Clouds

into Regions and Zones; and all define these terms in

essentially the same manner: Regions are dispersed

into geographic areas consisting of Zones, and each

Zone is presented as an isolated location. Zones have

separate power and network connections and are tied

together with high speed interconnects.

Consequently, failure of one Zone should not, in

theory, disrupt operations in another. EC2 refer to

Zones as AZs and we will use these terms

interchangeably.

There exist some operational differences

between Regions/Zones in different Clouds. For

example, EC2 will not automatically replicate any

resources placed in one Region into another, whilst

GCE state that they make ‘no guarantee that project

data at rest is kept only in that Region’. However,

for the purposes of our present discussion these

operational differences are not important.

Clouds offer VMs in a range of sizes known as

instance types, with similar types grouped into

instance classes. Instances types within the same

class typically have the same ratio of quantity of

CPU cores to RAM.

Providers give their instance types a performance

rating, which expresses the compute power an

instance’s vCPUs should deliver, with a vCPU

rating multiplied by the number of vCPUs offered to

provide an overall rating for the type. On Amazon’s

Elastic Compute Cloud (EC2), this is called the EC2

Compute Unit (ECU), whilst Google Compute

Engine has the Google Compute Engine Unit

(GCEU). Such ratings should guarantee, if not

identical, then certainly very similar, levels of

performance of instances of the same type.

However, we have previously shown (Author1

and Author2, 2013) that m1.small instances on EC2

backed by a Xeon E5430 will run a bzip2

compression benchmark on average in 445s, whilst

instances backed by a Xeon E5507 will take on

average 621s to run the same benchmark. This is a

39% increase in time taken for instances backed by

Xeon E5507 compared to the Xeon E5430. These

instances are ‘rated’ the same and the user is charged

the same price for each, but a performance-based

pricing would clearly be expected to distinguish

these.

By a heterogeneous Cloud we mean one where

instances of the same type may run a variety of

underlying hardware (which we refer to as hosts). Of

the providers considered, EC2 is the only one which

acknowledges a heterogeneous infrastructure,

stating: ‘EC2 is built on commodity hardware, over

time there may be several different types of physical

hardware underlying EC2 instances’ (Amazon EC2

FAQs, no date). In such an environment

performance variation is to be expected. As Amazon

adds new Regions into EC2, and new Availability

Zones (AZ) into existing Regions performs

hardware refreshes, and as CPU models are retired

by manufacturers, heterogeneity is seemingly

inevitable. One would assume that, over time, any

successful Cloud provider is will end up with a

heterogeneous environment.

We have however found a stable association

between hardware, as identified by CPU model, and

instance classes. That is, an instance of a given class

only runs on particular set of hardware. For

example, First Generation Standard (FGS) instances

run on hardware with Intel Xeon E5430, E5-2650,

E5645 and E5507 CPUs. Over the 6 month period,

in which we have been running various performance

experiments on EC2 (April to September 2013),

these sets and associations have not changed.

We would of course expect change over time, for

the reasons discussed above. Indeed, in Ou, et al.

(2012), the authors find Intel Xeon E5430, E5645,

E5507 and AMD Opteron 270 backing FGS

instances. They note that the AMD model is present

less often in 2012 than compared to results they

obtain in 2011. We also find that the hardware

associated to different instance classes is distinct

from each other. We would assume that hardware

associated to different classes has either different

PerformancePredictionforUnseenVirtualMachines

performance characteristics, or a different ratio of

CPU cores to RAM. This allows instances from

different classes to be differentiated along these

lines. Thus, in addition to FGS instance class we

have High CPU, High Memory and Second

Generation Standard Instance classes. We may

logically view AZs as being partitioned into

hardware platforms associated with instance classes

that are available there.

Amazon is currently the only provider to publish

specific CPU model information associated with

certain instance types. Generally these are

specialised high-performance instance types such as

Cluster Compute with 10Gb networking, or GPU

instances. These types are only available, at the time

of writing, in a limited number of Regions. The

recently introduced High Memory class (m3.xlarge

and m3.2xlarge) is the only general purpose class of

instances globally available on EC2 whereby the

CPU model is provided as part of the instance

description. Whether EC2 will continue this trend;

and specify CPU model for all new, and possibly

existing, types, or find that heterogeneity is also

inevitable for these new instance types and remove

specific information, remains to be seen.

Dividing a Region into AZs, and encouraging

their use for load balancing and high availability,

tends to suggest that the resources available in the

various AZs are likely to be broadly similar.

However, we have experimentally determined that

the proportions of CPU models backing instances

are quite different in different AZs. Indeed, with

heterogeneous hardware in the same Zone, even

Zone-specific load balancing, and related scalability

matters, may necessitate further thought.

In the next section, we present some

experimental results showing the distribution of

CPU models found in a number of AZs.

3 CPU PERFORMANCE AND

DISTRIBUTION IN EC2

In April 2013 (Author1 and Author2 2013), we

benchmarked the compute capacity of close to 1300

instances on EC2, across 14 AZs in 6 (out of the 8)

Regions. We included 11 (non-specialised) instance

types across 4 instance classes: First Generation

Standard, High CPU, High Memory and Second

Generation Standard. The image id backing the

instances was ami-a73264ce which is a para-

virtualised image. As such the cpuid instruction

(used by the Linux kernel to populate /proc/cpuinfo)

does not trap to the hypervisor. Through cpuid we

identify the CPU model underlying an instance. And

so can determine CPU model to instance class

associations, and also the proportions of CPU

models found in a given AZ.

We measure an instance’s compute capacity by

timing the compression of an Ubuntu 10.04 desktop

image ISO with bzip2, a compression tool found on

Linux systems. Bzip2 is a compute bound

application and forms part of the SPECint 2006 CPU

benchmark suite. In Table 1 below we record the

benchmark times of 540 m1.small instance, broken

down by CPU model backing them.

Table 1: Bzip2 compression times on m1.small instances.

Statistic E5430 E5-2650 E5645 E5507

Mean(s) 445 470 510 621

Sd(s) 14 13 11 28

Min(s) 425 443 488 578

Max(s) 482 519 543 716

From Table 1 we see that, for this particular task, it

is clearly preferable to obtain an E5430 than a

E5507. These results concur with related work

(reviewed in Section 9), which shows that an

instance’s (compute) performance is primarily

determined by the CPU model backing it, and that

variation between instances backed by the same

CPU is much smaller than the variation between

instances backed by different CPUs. As such,

determining the expected performance of a set of

instances depends, in part, on being able to predict

which CPU models will back them. Since, in this

paper, we seek to elaborate a capability to undertake

such predictions, we consider the following

problem: In a request for a number of instances of a

given type (from a given AZ), what is the expected

number of each CPU model backing the instances?

We begin with the observation that it will depend

(at a minimum) upon (1) the proportions of CPU

models found in a given AZ, and (2) the scheduling

algorithm being used to place instances onto hosts.

In September 2013 an updated survey was

conducted focusing on the AZs us-east-1a and us-

east-1c in the Region US East. We ran 150 instances

of types m1.small, m1.medium and m1.large in both

us-east-1a and us-east-1c, that is 900 instances in

total. Table 2 shows the percentages of each model

found backing our instances in the 2 AZs. We

abbreviate us-east-1a and us-east-1c by 1a and 1c.

CLOSER2014-4thInternationalConferenceonCloudComputingandServicesScience

Table 2: Proportion of CPU models for FGS instances is

us-east-1a and us-east-1c.

Type AZ E5430 E5-2650 E5645 E5507

m1.small 1a 0 0 98% 2%

m1.medium 1a 0 85% 15% 0

m1.large 1a 0 67% 33% 0

m1.small 1c 25% 0 26% 49%

m1.medium 1c 24% 1% 39% 36%

m1.large 1c 14% 0 7% 79%

We do not interpret the above percentages as an

estimate for the actual proportions of hosts with a

given CPU type in the Zone, rather as an estimate of

the probability of obtaining a particular model.

Clearly, one would assume the percentages found to

be reflective of actual host proportions in the AZ.

From Table 2 we see that in us-east-1a we have very

high probability of an m1.small obtaining an E5645,

whilst the m1.medium has a much smaller chance.

However, we do expect probabilities to change over

time, and perhaps even frequently. We discuss this

further in section 7.

We also note that without much further

consideration a customer (given knowledge of Table

2) may well choose us-east-1a over us-east-1c for

certain instance types. However, we also note that

us-east-1c may offer better price/performance

compared to us-east-1a due to it having a larger

proportion of the E5430 model.

4 MODELLING AN AZ

In this section we develop a simple model of an AZ

that will allow us to simulate requests and responses.

Public Clouds are generally opaque - few

architectural details are made available. And so we

are guided by knowledge derived from the

OpenStack reference architectures (OpenStack, no

date), experiments on EC2, and our experiences of

running both Eucalyptus and OpenStack Private

Clouds at our institution.

To simplify matters we model requests only for

FGS instances, the m1.small, m1.medium, m1.large

and m1.xlarge instances. As discussed earlier, this

class is backed by Intel Xeon E5430, E5-2650,

E5645 and E5507 CPUs.

By VM density we refer to the ratio of vCPUs to

physical cores that a host presents. For example, a

host with 8 cores and VM density = 1 presents 8

vCPU. In this case the host could run, for example, 1

m1.xlarge (requiring 4 vCPU) and 4 m1.small

instances (1 vCPU each). However, if the VM

density is increased to 1.5 we now have 12 vCPUs

presented, and so the host may now run (for

example) an additional 2 m1.large instances. Of

course, running a Cloud at a higher VM Density will

lead to greater resource contention amongst the

VMs, resulting in larger performance variation. We

set the VM Density = 1.

The scheduler in our model (in common with the

OpenStack scheduler) is capable of filtering

instances types onto associated hardware. We

therefore avoid considering hardware not associated

with FGS instance class.

In our model, a host for a given class can run a

mix of its instance types. For example, a FGS host

with sufficient vCPUs could have an m1.small,

m1.medium, m1.large and an m1.xlarge running on

it at the same time. There is no obvious reason why

this should not also be true on EC2.

We have chosen to use the chance scheduling

algorithm. This chooses hosts at random and, if there

are available resources, will allocate the VM to the

host.

Hence our AZ consists of:

 A number of host machines running a

hypervisor in order to host VM instances.

 Heterogeneous hosts (hosts may have

different hardware).

 Each host presents a number of vCPUs which

are allocated to instances running on it.

 One scheduler, responsible for placement of

VM instances onto hosts.

o The scheduler can be configured to

implement a number of scheduling

algorithms. We use chance scheduling.

o The scheduler also filters instance types

onto hosts of a given type.

 VM Density = 1.

5 SIMULATING USER

REQUESTS

We restate the problem of interest: In a request for a

number of instances of a given type, what is the

expected number of each CPU model backing the

instances?

By state of the Zone, we mean the total number

of available vCPUs and their arrangement over the

host machines. Clearly, the state of the Zone will

change over time, potentially for a number of

different reasons including demand fluctuation,

capacity management, short-term unplanned

outages, planned maintenance and hardware

replacement and refreshes. Some of these are merely

transient, whilst other will change the composition

of the Zone.

PerformancePredictionforUnseenVirtualMachines

To generate a state, we need to make an

assumption about data centre loading, which we

consider to be the number of in use vCPUs. Whilst

we have no reliable data for actual VM loadings in

data centres, and providers do not release such

information, it is generally claimed to be high.

Indeed, one of the positive arguments for Cloud

adoption is high utilisation. Further, providers claim

they can maintain high rates and that whilst an

individual customer’s demand fluctuates; aggregate

demand (over all customers) remains fairly constant.

This has been referred to as one of the ‘Laws’ of

Cloudonomics (Weinman, 2008). From the

discussion above, we believe that scenario 2 would

be a reasonable assumption on data centre loading.

Our algorithm for generating a Zone state

depends on size of the Zone, the load and the

instances we wish to run in it. Assuming 1000 hosts

each with 8 cores (without load), so 8000 vCPUs in

total, able to run m1.medium, m1.large and

m1.xlarge instance, we do as follows:

LOADING = randomint(0.7*8000,0.9*8000)

while ( LOADING > 0 ) do

k = random-select(1, 2, 4)

schedule(20 instances of k vCPUs)

LOADING = LOADING - 20*k

With all hosts, and so all vCPUs, free, we

generate a random loading of 70% to 90% of the

vCPU count. Next, we randomly select (random

numbers drawn from the uniform distribution) a

vCPU size (1, 2, 4 to reflect the vCPU requirement

of m1.medium, m1.large and m1.large, respectively)

and schedule 20 instances of this type into the Zone.

This is repeated until we have the required load.

This gives a mix of types running on hosts. In our

code the schedule function ensures that a VM is only

placed on a host which has a sufficient number of

free vCPUs. The schedule function updates the host

and VM state after allocation.

We choose a static (Monte Carlo) simulation of

user requests, proceeding as follows: We first

generate a Zone State as described above, we then

simulate a request (over this state) to the scheduler,

which allocates the required number of instances

onto hosts. We then count the number of CPU

models in the hosts backing our instances. An

example output of a request for 20 m1.small

instances, in a Zone containing CPU models E5430,

E5645 and E5507 would be: (5 E5430, 4 E5645, 11

E5507).

For each iteration in the simulation, the requested

instance type is constant, the request size is 20 (the

maximum on EC2), and Zone state is generated

anew so if we are interested in m1.small types then

the simulation asks for 20 m1.small instances 50,000

times (each time over a new Zone state). By

repeatedly sampling over Zone states a sufficiently

large number of times (50,000 in this case) we

generate a distribution for the CPU models from

which we calculate estimates of the expected

number of CPU models per request. In practice there

will be some request failures, however for simplicity

we assume that all instances are successfully placed

in each request.

We investigate two scenarios:

Scenario 1: Zero loading in the data centre.

Scenario 2: 70% to 90% of the cores in the data

centre already in use.

To run a simulation, we need to specify the

proportions of the CPUs in the Zone. Whilst we

have data from our survey of us-east-1c, we are

faced with 2 immediate problems. Firstly, as already

discussed, the percentages are estimates of the

probability of obtaining a model and not estimates of

the actual host proportions. Clearly though they are

likely to be indicative of them and as there is no

obvious way to more accurately determine host

proportions we take the percentages as estimates for

our model. Next, instance types share common

platforms, and yet from Table 2 are not being

allocated to them in the same fashion. And so, if we

wish to model m1.small requests should we use 49%

as the percentage? Or should we average over 49%,

36% and 79%, which would give 55%? When

modelling a given type we take the percentage found

for the type and not the average.

6 SCENARIO 1

We are requesting 20 FGS instances from the pool

of all available hosts. We start by considering the

m1.medium instance type which has 1 vCPUs, and

so requires 1 physical core by our assumptions. We

are using a chance scheduler, which chooses hosts

randomly and allocates a VM to it, if it has sufficient

resources (if not choose a new host). Thus we are

sampling over the set of cores without replacement.

In this case the joint probability density function is

described by the multivariate hyper-geometric

distribution. The marginal distributions are also

hyper-geometric, however when the sample size is

small compared to the population, as in this case, the

hyper-geometric tends to binomial distribution. And,

so we have, for example E5430 ~ B(n,p) where n =

20 and p is proportion of E5430 cores expressed as a

decimal for m1.medium instance. We also note that,

whilst this request is for m1.medium instances, the

CLOSER2014-4thInternationalConferenceonCloudComputingandServicesScience

argument above, with slight modifications, applies

to all FGS instance sizes.

7 SCENARIO 2

The AZ is assumed to have a loading such that 70%

to 90% of the cores are already in use. That means

the total available core count is between 800 and

2400. The first simulation is with m1.small requests

in us-east-1c with CPUs in the following

proportions: 25% E5430, 26% E5645 and 49%

E5507. We then simulate m1.medium and m1.large

using data from Table 2.

We calculate the marginal distributions for our

random variables by simply counting the number of

times a particular output occurs. To calculate the

marginal probability distributions we simply divide

the number of occurrences by the 50,000, from this

we calculate the expected number of each CPU. In

Table 3 below we present the calculated

expectations for all CPU models in each simulation,

and in Figure 1 we present the frequency distribution

for the discrete random variable defined by the

number of E5430 models returned in response to a

request for 20 m1.large instances.

Table 3: Expected Value of CPU Returns.

E5430 E5645 E5507

m1.small 5.00 5.197 9.795

m1.mediu

5.0114 5.195 9.793

m1.lar

e 5.008 5.192 9.799

1234567891011121314151617181920

2000

4000

6000

8000

10000

12000

E5430 for m1.large Instances

Nunber of E5430 Returned

Frequency

Figure 1: E5430 for m1.large Instances.

We suspect that the distributions are binomial. For

the distribution depicted in Figure 1 we perform a

Chi-Squared Goodness of Fit Test, where the null

hypothesis is E5430 ~ B(20,0.25), and E5430

denotes the discrete random variable as defined in

the paragraph above. For the test we generate

expected output from B(20,0.25) and then calculate

the chi squared statistic as 17.99. With 20 degrees of

freedom, at a 5% significance level, we fail to reject

the null hypothesis. Similarly, our simulations for

m1.small and m1.medium instance types also

produce marginal distributions which are binomial.

8 COMPARISONS WITH POST

SIMULATION DATA FROM

US-EAST-1C

From the above simulation E5430 ~ B(20,0.25).

By a direct calculation P(E5430 <=7) – P(E5430

<=2) = 0.673. And so in 2 out of 3 samples of 20

instances we would expect the number of E5430

models obtained to be between 3 and 7.

In a follow on experiment to the one described in

section 3, paragraph 6, and with results in Table 2;

we requested 3 samples of 20 m1.large instances,

with a 10 minute interval between requests and no

resources were released until we had concluded the

experiment. In Table 4 below we record the results.

Table 4: CPU models returned in request in us-east-1c for

20 m1.large.

Sample E5430 E5645 E5507

1 3 0 17

2 5 1 14

3 2 0 18

In a final experiment, we launched 100 m1.small

instances. Assuming a binomial distribution, and

using our data in Table 2 as an estimate for p, the

expected numbers (100*p) of each CPU model

would be (25,24,49). We obtained (21,29,50).

It is not yet clear to us why instance types within

the same class obtained the same CPUs in different

proportions. It may well be the case that instances

types within the same class do not run on the same

host at the same time. That is, a host may run 2

m1.xlarge machines, and if one is terminated will

only host another m1.xlarge. However, if both

m1.xlarge instances are terminated then the host is

available again to all instance types in the class.

Over time such a scheme may lead to the

distributions we have seen. We intend to pursue this

idea further.

9 SCHEDULERS AND AZ STATE

We chose the chance scheduler as our staring point

as it is was previously the default scheduling

algorithm in OpenStack. There are a number of

algorithms that schedule more intelligently than

PerformancePredictionforUnseenVirtualMachines

chance, and reflect the priorities of a site. As an

example, minimise the number of hosts in use;

whilst keeping the hosts not in use in a low energy

state. Others algorithms attempt to make efficient

use of resources; and these are generally variations

on the bin packing problem, as described in Wilcox,

et al. (2010), with the scheduler employing a

heuristic to solve the problem. The AZ states and

the CPU distributions generated by this scheduler

are potentially quite different from those that a

chance scheduler would generate. Similarly,

schedulers that seek to take advantage of co-locating

VMs, for either deduplication of base images or

page sharing amongst VMs may also generate AZ

states different from both the chance scheduler and

bin packing.

10 RELATED WORK

In Armbrust, et al. (2009), the authors describe EC2

Cloud performance as unpredictable. Similarly,

Osterman, et al. (2010), describe performance in the

Cloud as unreliable. The Magellan Report on Cloud

Computing for Science (Yelick, et al., 2011) found

that ‘applications in the Cloud…experience

significant performance variations’ and noted that

this is in part caused by the heterogeneous nature of

EC2. However, EC2 was the only Public Cloud they

considered. Similarly, in Phillips, Engen, and Papay,

(2011), also discovered differential performance in

instances of the same type on EC2 when attempting

to predict application performance.

Iosup, et al. (2011), demonstrate that

performance variation exists in a range of AWS

services, including S3, SDB and SQS, and so

performance variation of applications using these

services is not solely dependent upon instance

compute capability.

Schad, et al. (2010), show that the compute

performance of instances sampled from US East N.

California and the EU West Dublin Region falls into

two distinct performance bands. Upon further

investigation they detect two different CPU models

backing their instances and speculate that previous

results are explained by differences in CPU model.

They also found a difference in the amount

performance variation in two out of the four AZs

used (us-east-1c and us-east-1d).

Ou, et al. (2012), suggest that the heterogeneous

nature of Clouds can be exploited by estimating the

probability of obtaining a particular CPU model

backing an instance. Their method assumes that

instances will be randomly sampled from all AZ

available in US East N. California, which, as noted

by the authors in Schad, et al. (2010) is not

necessarily the case. To fully exploit heterogeneity,

requests must be made per AZ, and this requires an

analysis of the CPU distributions per AZ in the

Region of interest. Additionally, they assume that

the CPU model obtained in a particular request is

independent of the one previously obtained. There is

no guarantee of this; and VM placement algorithms

need to be considered.

There is a large literature base for VM

scheduling; for example Bazarbayev, et al. (no date),

consider scheduling of VMs with identical or similar

base images onto the same hosts. Reig, Alonso and

Guitart, (2010), add machine learning capabilities to

the scheduler in order for it to be able to predict

resources required for a given execution time.

However, as far as we aware, there are no papers

looking specifically at how scheduling may affect

the probability of obtaining particular resources.

11 CONCLUSIONS AND FUTURE

WORK

The compute performance of an instance is primarily

determined by the CPU model backing it. Currently

customers cannot request either a desired level of

performance, or, failing that, a particular CPU

model. Being able to predict the performance of a

set of instances before provisioning them, is

therefore an important issue for Cloud users. Being

able predict the range of CPU models that may be

obtained in response to a request will go someway

towards answering this question.

In this paper we therefore address the following

problem: In a request for a number of instances of a

given type, what is the expected number of each

CPU model backing the instances?

By create a simple AZ model we showed that in

the case of an empty (but sufficiently large) AZ

then the number of models of a given type in a

request is binomially distributed B(20,p), where p is

the proportion of CPU models in the zone.

We then modelled an AZ and under a load of

70% to 90% capacity used, this describes the

number of vCPUs in use. We used the uniform

distribution to generate the AZ state, and then used a

chance scheduling algorithm to allocate FGS

instances into our AZ. The simulation samples over

the set of possible states, so we estimate a joint

probability distribution for our random variables

E5430, E5645 and E5507 (denoting the CPU models

CLOSER2014-4thInternationalConferenceonCloudComputingandServicesScience

found in AZ respectively). From this joint

distribution we calculated the marginal distributions

and using a chi-squared goodness of fit test we

showed that these are drawn from a Binomial

distribution.

Therefore, in both scenarios the answer to our

original question is this: the expected number of

CPUs of a given type is the request size multiplied

by the probability of obtaining a CPU (in a request

for one instance). Comparing with a (small) set of

samples drawn from us-east-1c we find that n*p

appears to be reasonably good estimate of the

number of models we may obtain.

We intend to investigate commonly found

scheduling algorithms and incorporate them into

future models, and compare the distributions our

models generate with instance sampled from

providers.

We recognise that the work involved in

implementing such a model, and estimating possibly

frequently changing probabilities, may make it

impractical for certain users. However, we believe

that this is feasible for Infrastructure Cloud brokers;

and indeed they are ideally placed to do so.

More generally, we believe this will enable

brokers to make performance related pricing offers

to customers of the following form: Offer 1: We are

95% sure that at least 15 of the 20 VMs will run the

workload in less than or equal to T seconds. Our

future work is aimed at advancing this.

REFERENCES

Phillips, S., Engen, V., & Papay, J., 2011. Snow white

clouds and the seven dwarfs, in Proc. of the IEEE

International Conference and Workshops on Cloud

Computing Technology and Science, pp738-745, Nov.

2011.

Ou, Z., Zhuang, H., Nurminem, J.K., Yla-Jaaski, A., &

Hui, P., 2012. Exploiting Hardware Heterogeneity

within the same instance type of Amazon EC2,

presented at 4

USENIX Workshop on Hot Topics in

Cloud Computing, Boston, MA. Jun. 2012.

Reig, G., Alonso, J., & Guitart, J., 2010. Prediction of Job

Resource Requirement for Deadline Schedulers to

Manage High-Level SLAs on the Cloud, in 2012 Ninth

IEEE International Symposium on Networking

Computing and Applications, pp 162-167, July 2010.

Amazon EC2 FAQs, no date. Aws.amazon.com. [Online].

Available at: < http://aws.amazon.com/ec2/faqs>

[Accessed: 30 September 2013].

Google Cloud Platform, no date. cloud.google.com.

[Online]. Available at:https://cloud.google.com

[Accessed: 30

September 2013].

HP Public Cloud, no date. www.hpcloud.com. [Online].

Available at: <https://www.hpcloud.com/> [Accessed:

2nd July 2013].

Rackspace Global Infrastructure, no date.

www.rackspace.com [Online]. Available at: http://

www.rackspace.com/information/aboutus/datacenters/

[Accessed: 30

September 2013].

AWS Global Infrastructure, no date. aws.amazon.com.

[Online]. Available:<http://aws.amazon.com/about-

aws/globalinfrastructure/> [Accessed: 30

September

2013].

Armbrust, M., et al, 2009. Above the clouds: a Berkely

view of cloud computing, Technical Report EECS-

2008-28, EECS Department, University of California,

Berkeley.

OpenStack Scheduling, no date. Docs.openstack.org

[Online]. Available at: < http://docs.openstack.org/

grizzly/openstack-compute/admin/content/ch_schedu

ling.html> [Accessed: 30

September]

Weinman, J., 07/09/2008, 10 laws of Cloudonmics.

Giga.com. [Online]. Available at http://gigaom.com

/2008/09/07/the-10-laws-of-cloudonomics/ [Accessed:

September

Bazarbayev et al., no date. Content based scheduling of

Virtual Machines in the Cloud. [Online]. Available at

https://www.perform.csl.illinois.edu/Papers/USAN_pa

pers/12BAZ01.pdf > [Accessed: 30th September]

Wilcox, D., McNabb, A., Seppi, K., & Flanagan, K., 2010.

Probabilistic Virtual Machine Assignment, Cloud

Computing 2010: First International Conference on

Cloud Computing, Grids and Virtualisation, Lisbon,

November 21-16, 2010.

S. Osterman et al, A performance analysis of EC2 cloud

computing services for scientific computing, Cloud

Computing, Lecture Notes of the Institute for

Computer Sciences, Social-Informatics and

Telecommunications Engineering, vol 34, 2010, pp

115-131.

Iosup, A., Nezih, Y., and Dick, E., 2011. On the

performance variability of production cloud services.

In Cluster, Cloud and Grid Computing (CCGrid), 2011

Yelick, K., et al, 2011. The Magellan Report on Cloud

Computing for Science. [Online]. Available at:

http://www/alcf.anl.gov/magellan [Accessed at: 2nd

January 2014].

OpenStack, no date. www.openstack.org [Online].

Available at: http://www.openstack.org [Accessed: 1

January 2014].

PerformancePredictionforUnseenVirtualMachines
