Keystroke Authentication on Mobile Devices with a Capacitive Display

Matthias Trojahn

and Frank Ortmeier

Volkswagen AG, Wolfsburg, Germany

Computer Systems in Engineering, Otto-von-Guericke University, Magdeburg, Germany

Keywords:

Security, Keystroke Authentication, Pressure, Mobile Devices, Capacitive Display.

Abstract:

Nowadays, it is common to address security problems in the newspaper. Losing or stealing of mobile devices

(smartphones and tablets) is in particular an important topic. A lot of information can be stored and accessed

via these devices. The one reason why this problem exists, is because the mobile devices are not secured prop-

erly. In our work we present an authentication method for these mobile devices.We are using the keystroke

dynamics during typing a PIN (four or six numbers) or password. With this the security of the devices gets im-

proved. Keystroke dynamics are already used for authentication on PCs and on mobile phones with hardware

keys on a 12-key layout.

1 INTRODUCTION

Biometric user authentication (something-you-are)

is an established authentication method beside the

something-you-know (PIN and password) and the

something- you-have factor (smart card or one-time-

password). The advantage with biometric methods

is that this factor cannot be stolen or lost like smart

cards. The user himself is the factor. Two groups of

biometric authentication methods are known. One is

the passive methods (e.g. ﬁngerprint or face recog-

nition), the other are active or behavior methods like

voice or signature recognition. One disadvantage is

that biometric authentication is differing each time

(Ross et al., 2006). These changes can occur because

of different aspects (e.g. temporary illnesses or espe-

cially behavior methods have every time small differ-

ences).

That is why two different error rates are known.

These are called FAR (False Acceptance Rate) and

FRR (False Rejection Rate). FAR describes the per-

centage between the false accepted people divided by

all authentication attempts (Vielhauer, 2006). FRR

deﬁnes how much people cannot authenticate himself

even if they are the person how they claim to be (Viel-

hauer, 2006). Both rates are used to compare authen-

tication methods.

Figure 1: Digraph between letter N and O (e.g. time be-

tween pressing and releasing one key or time(Cranor and

Garﬁnkel, 2005).

2 BACKGROUND

The authentication via keystroke dynamics started

with ﬁrst studies for the keyboard of computer. Today,

some companies are already selling keystroke authen-

tication with a special keyboard. Important for each

method is to choose a good set of features and clas-

siﬁers. Well known features for keystroke are the di-

graph (time between two events - see Figure 1) (Maio-

rana et al., 2011) and the error rate (times the user

erases a letter) (Buchoux and Clarke, 2008).

The research of Monrose et al. (Monrose and

Rubin, 2000) where they used a Bayesian classi-

ﬁer showed good results with an accuracy of around

92,1% which represents EER of 7,9%. These meth-

637

Trojahn M. and Ortmeier F..

Keystroke Authentication on Mobile Devices with a Capacitive Display.

DOI: 10.5220/0004344806370640

In Proceedings of the 2nd International Conference on Pattern Recognition Applications and Methods (BTSA-2013), pages 637-640

ISBN: 978-989-8565-41-9

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

ods were adapted to the mobile phones with a 12-

key layout with physical keys by different researches

(Clarke and Furnell, 2006; Maiorana et al., 2011).

Common classiﬁers are neural networks, Bayesian

classiﬁer or stastistical classiﬁer (Alsulaiman et al.,

2008; Monrose and Rubin, 2000). With these the er-

ror rates were lowered over the years and today FAR

and FRR can be lower than 5% (as described in the

survey of Shanmugapriya (Shanmugapriya and Pad-

mavathi, 2009)). Because of the technology changes

in the last years smartphones use a different input

method. The physical keys are replaced by a capaci-

tive display and no 12-key layout is used anymore. In-

stead, we are using a full featured QWERTY-layout.

3 KEYSTROKE USING THE

CAPACITIVE DISPLAY

A new layout creates different challenges. Limited

physical feedback and smaller keys will lead to not so

good results during authentication (Trojahn and Ort-

meier, 2012). The capacitive display can give a feed-

back with a vibration signal but like before it is not

possible to recognize whether one key was pressed in

the middle or at the edge. Previously, it was possible

for the user to recognize if two keys were pressed at

the same time. To compensate these challenges new

features have to be added to the authentication pro-

cess. In addition, different features could be added

to the digraph (time between two events) and error

count:

• phyisical pressure during typing of the ﬁngertip

• size of the ﬁngertip which is pressing on the de-

vice researchs

• exact location (X/Y-coordinates)

• angle in which the user holds the device

In other researchs (Luca et al., 2012) pressure and

size were used but only for a 3x3 point matrix where

the user had to draw a ﬁgure connecting these points.

The FAR in this scenario was 21% and the FRR was

19%.

4 EXPERIMENT

A ﬁrst experiment with 18 user allowed to obtain pre-

liminary results for an keystroke authentication with

a capacitive display. In Figure 2 ﬁrst differences are

shown with the digraph and the pressure during typ-

ing. Five samples of different user are shown in the

ﬁgures which shows the differences between the user.

Figure 2: (top) digraph of ﬁve user; (bottom) pressure dur-

ing typing (same users).

11 letters had to be written by each user ten times.

The third and fourth were the same so the digraph for

the difference is smaller than the most of the rest of

the digraphs.

This experiment had a FAR of 2% and a FRR

of 2.7% with an J48 classiﬁer (using the weka en-

vironment (Hall et al., 2009)). Additional tests with

other classiﬁer (neuronal networks or baysian clas-

siﬁer) showed that both fault error rates are under

10%. The result for a statistical classiﬁcation algo-

rithm (cluster analysis) was that for this set of user the

FAR and FRR is lower than 1%. During the enroll-

ment seven samples were used for creating the model

of a person where the two outlier values were ex-

tracted as error extraction. The other three samples

were used for the evaluation of this method using the

distance measure.

5 DISCUSSION

In addition, several different scenarios exist which can

inﬂuence the input behavior of a person and can result

ICPRAM2013-InternationalConferenceonPatternRecognitionApplicationsandMethods

638

Figure 3: Different scenarios for changing the input behavior.

to a rejection. Some of these scenarios are shown in

Figure 3. These have to be tested whether they inﬂu-

ence the keystroke behavior or not.

Some scenarios are the result of physical changes

of the device and other are inﬂuenced by the environ-

ment. In the darkness or if the light is glaring, the user

may not see the keys really good. This can result in a

slower input behavior than normal (Fitts, 1992; Funk

et al., 2012).

Furthermore, physical conditions are important.

Especially, if the user is in motion e.g. going or run-

ning somewhere (Owens, 1984) or whether the user is

tired (Pan et al., 1994). In some situation a person has

time pressure during typing (stress) which inﬂuence

the behavior (Vizer et al., 2009).

6 CONCLUSIONS AND FUTURE

WORK

The ﬁrst results show that an authentication with this

method on smartphones is possible. In the future,

more experimental tests have to be done with more

people. In addition, it has to be tested how the

keystroke dynamic is affected by stress, for exam-

ple time pressure and other scenarios which were pre-

sented. Moreover, possible attacks have to be tested

to show the security and robustness of this method.

With the usage of neuronal networks a solution have

to be generated how negative examples are created in

a real scenario to train the neuronal network. In test

case negative examples are generated by other user

when they using the same password. In a real sce-

nario the password should be unique that means no

negative examples exists.

Also other forms of input methods are possible.

One is to use the swype (www.swype.com) method

where the user has a normal keyboard on the touch

pad. There the user is drawing / swyping a continu-

ous line where the user starts at the ﬁrst letter and is

drawing a line to the next letter and so on. One word

is represented by one line.

REFERENCES

Alsulaiman, F. A., Cha, J., and Saddik, A. (2008). User

identiﬁcation based on handwritten signatures with

haptic information. In Proceedings of the 6th in-

ternational conference on Haptics: Perception, De-

vices and Scenarios, EuroHaptics ’08, pages 114–121,

Berlin and Heidelberg. Springer-Verlag.

Buchoux, A. and Clarke, N. L. (2008). Deployment of

keystroke analysis on a smartphone. In Proceedings

of the 6th Australian Information Security & Manage-

ment Conference.

Clarke, N. L. and Furnell, S. M. (2006). Authenticating mo-

bile phone users using keystroke analysis. In Int. J. Inf.

KeystrokeAuthenticationonMobileDeviceswithaCapacitiveDisplay

639

Secur, volume 6, pages 1–14, Berlin and Heidelberg.

Springer-Verlag.

Cranor, L. F. and Garﬁnkel, S. (2005). Security and Usabil-

ity: Designing Secure Systems That People Can Use.

O’Reilly Media, illustrated edition.

Fitts, P. M. (1992). The information capacity of the human

motor system in controlling the amplitude of move-

ment. 1954. J EXP PSYCHOL GEN, 121(3):262–269.

Funk, R. E., Taylor, M. L., Creekmur, C. C., Ohlinger,

C. M., Cox, R. H., and Berg, W. P. (2012). Effect

of walking speed on typing performance using an ac-

tive workstation 1,2. Perceptual and Motor Skills,

115(1):309–318.

Hall, M., Frank, E., Holmes, G., Pfahringer, B., Reutemann,

P., and Witten, I. H. (2009). The weka data mining

software: An update. In SIGKDD Explorations, vol-

ume 11.

Luca, A. d., Hang, A., Brudy, F., Lindner, C., and Huss-

mann, H. (2012). Touch me once and i know it’s you!:

implicit authentication based on touch screen patterns.

In CHI’12, pages 987–996.

Maiorana, E., Campisi, P., Gonz

alez-Carballo, N., and Neri,

A. (2011). Keystroke dynamics authentication for mo-

bile phones. In Proceedings of the 2011 ACM Sympo-

sium on Applied Computing, SAC ’11, pages 21–26,

New York and NY and USA. ACM.

Monrose, F. and Rubin, A. D. (2000). Keystroke dynamics

as a biometric for authentication. In Future Genera-

tion Computer Systems, volume 16, pages 351–359.

Elsevier Science Publishers B. V.

Owens, D. A. (1984). The resting state of the eyes: Our

ability to see under adverse conditions depends on the

involuntary focus and convergence of our eyes at rest.

In Sigma Xi, T. S. R. S., editor, American Scientist,

pages 378–387.

Pan, C. S., Shell, R. L., and Schleifer, L. M. (1994). Perfor-

mance variability as an indicator of fatigue and bore-

dom effects in a vdt data–entry task. International

Journal of Human-Computer Interaction, 6(1):37–45.

Ross, A. A., Nandakumar, K., and Jain, A. K. (2006). Hand-

book of Multibiometrics (International Series on Bio-

metrics). Springer-Verlag New York, Inc, Secaucus

and NJ and USA.

Shanmugapriya, D. and Padmavathi, G. (2009). A sur-

vey of biometric keystroke dynamics: Approaches,

security and challenges. In International Journal of

Computer Science and Information Security, volume

abs/0910.0817 of Vol. 5, No. 1.

Trojahn, M. and Ortmeier, F. (2012). Biometric authenti-

cation through a virtual keyboard for smartphones. In

International Journal of Computer Science & Infor-

mation Technology (IJCSIT).

Vielhauer, C. (2006). Biometric User Authentication for IT

Security: From Fundamentals to Handwriting. Ad-

vances in information security. Springer-Verlag.

Vizer, L. M., Zhou, L., and Sears, A. (2009). Automated

stress detection using keystroke and linguistic fea-

tures: An exploratory study. International Journal of

Human-Computer Studies, 67(10):870–886.

ICPRAM2013-InternationalConferenceonPatternRecognitionApplicationsandMethods

640
