On Reducing the Number of Visual Words in the Bag-of-Features

Representation

Giuseppe Amato, Fabrizio Falchi and Claudio Gennaro

Institute of Information Science and Technologies, CNR, via Moruzzi, 1, Pisa, Italy

Keywords:

Bag of Features, Bag of Words, Local Features, Content based Image Retrieval, Landmark Recognition.

Abstract:

A new class of applications based on visual search engines are emerging, especially on smart-phones that

have evolved into powerful tools for processing images and videos. The state-of-the-art algorithms for large

visual content recognition and content based similarity search today use the “Bag of Features” (BoF) or “Bag

of Words” (BoW) approach. The idea, borrowed from text retrieval, enables the use of inverted ﬁles. A very

well known issue with this approach is that the query images, as well as the stored data, are described with

thousands of words. This poses obvious efﬁciency problems when using inverted ﬁles to perform efﬁcient

image matching. In this paper, we propose and compare various techniques to reduce the number of words de-

scribing an image to improve efﬁciency and we study the effects of this reduction on effectiveness in landmark

recognition and retrieval scenarios. We show that very relevant improvement in performance are achievable

still preserving the advantages of the BoF base approach.

1 INTRODUCTION

The use of local features, as for instance SIFT (Lowe,

2004), has obtained an increasing appreciation during

the last decade, for its good performance in tasks like

image matching, object recognition, landmark recog-

nition, and image classiﬁcation. Brieﬂy, with these

techniques an image visual content is described by

identifying a set of (interest) points and by describing

the region around them with histograms (the local fea-

ture), as for instance histograms of brightness gradi-

ents. The image match task is executed by ﬁrst match-

ing the local features, and then by checking if there is

some (geometric) consistency between matched pairs

of interest point, to decide if images, or objects in im-

ages, match as well.

The total number of local features extracted from

an image depends on various setting of the feature

extraction tools. However, typically it is of the or-

der of some thousands. As a consequence, match-

ing an image against a database of images becomes

a very challenging task from the efﬁciency point of

view. For instance, if the database contains one mil-

lion images and on average every image has one thou-

sand local features, matching a query image against

this database requires matching 1,000 different local

features, extracted from the query, against one billion

local features, extracted from the database.

In order to mitigate this problem, some years ago

the Bag of Feature approach (BoF) was proposed

in (Sivic and Zisserman, 2003). The BoF approach

quantizes local features extracted from images rep-

resenting them with the closest local feature chosen

from a ﬁxed visual vocabulary of local features (vi-

sual words). In this way, images are no longer repre-

sented by a set of identiﬁers of visual words from the

visual vocabulary that is used to replace the original

local features. Matching of images represented with

the BoF approach is performed with traditional text

retrieval techniques and by verifying their (geomet-

ric) consistency. This process can be executed more

efﬁciently, than linearly scanning the entire database,

by using inverted ﬁles (Salton and McGill, 1986) and

search algorithms on inverted ﬁles.

However, even if inverted ﬁles offer a signiﬁcant

improvement of efﬁciency, with respect to a trivial se-

quential scan search algorithm, in many cases, efﬁ-

ciency is not yet satisfactory. A query image is asso-

ciated with thousands of visual words. Therefore, the

search algorithm on inverted ﬁle has to access thou-

sands of different posting lists of the inverted ﬁle. As

mentioned in (Zhang et al., 2009), ”a fundamental dif-

ference between an image query (e.g. 1500 visual

terms) and a text query (e.g. 3 terms) is largely ig-

nored in existing index design. This difference makes

the inverted list inappropriate to index images”. From

657

Amato G., Falchi F. and Gennaro C..

On Reducing the Number of Visual Words in the Bag-of-Features Representation.

DOI: 10.5220/0004290506570662

In Proceedings of the International Conference on Computer Vision Theory and Applications (VISAPP-2013), pages 657-662

ISBN: 978-989-8565-47-1

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

the very beginning (Sivic and Zisserman, 2003) some

words reduction techniques were used (e.g. remov-

ing 10% of the more frequent images). However, as

far as we know, no experiments have been reported

on the impact of the reduction on both efﬁciency and

efﬁcacy.

To improve efﬁciency, many different approaches

have been considered including GIST descriptos

(Douze et al., 2009), Fisher Kernel (Zhang et al.,

2009) and Vector of Locally Aggregated Descriptors

(VLAD) (J

egou et al., 2010). However, their usage

does not allow the use of traditional text search en-

gine which has actually been another beneﬁt of the

BoF approach.

In order to mitigate the above problems, this pa-

per proposes, discusses, and evaluates some meth-

ods to reduce the number of visual words assigned

to images. We will see that it is possible to signiﬁ-

cantly reduce their number with a very minor degra-

dation of the accuracy, and with a signiﬁcant efﬁ-

ciency improvement. Speciﬁcally, we propose and

discuss methods based on the use of the scale of the

local features that can be applied before the visual

words have been assigned and also methods based on

statistics of the usage of visual words in images (using

the term frequency tf ), across the database (relying

on the inverse document frequency (idf ), and on the

tf*idf combination (Salton and McGill, 1986)). We

also perform experiments using random reduction as

a baseline. The tf*idf approach was also presented

in (Thomee et al., 2010) using the SURF descriptor.

However, in their work the authors did not present

any comparison with other approaches. The effective-

ness of the approaches is measured on landmark re-

trieval and recognition tasks for which local features

and in particular the BoF approach is today consid-

ered the state-of-the-art. Experiments were conducted

on three dataset for testing both retrieval and recogni-

tion scenarios.

2 SELECTION CRITERIA

The goal of the BoF approach is to substitute each de-

scription of the region around an interest points (i.e.,

each local feature) of the images with visual words

obtained from a predeﬁned vocabulary in order to

apply traditional text retrieval techniques to content-

based image retrieval.

The ﬁrst step to describe images using visual

words is to select some visual words creating a vocab-

ulary. The visual vocabulary is typically built group-

ing local descriptors of the dataset using a clustering

algorithm such as k-means. The second step is to as-

sign each local feature of the image to the identiﬁer of

the ﬁrst nearest word in the vocabulary. At the end of

the process, each image is described as a set of visual

words. The retrieval phase is then performed using

text retrieval techniques considering a query image as

disjunctive text-query. Typically, the cosine similarity

measure in conjunction with a term weighting scheme

is adopted for evaluating the similarity between any

two images.

In this section we present ﬁve criteria for local fea-

tures and visual words reduction. Each proposed cri-

terion is based on the deﬁnition of a score that allows

us to assign each local feature or word, describing an

image, an estimate of its importance. Thus, local fea-

tures or words can be ordered and only the most im-

portant ones can be retained. The percentage of infor-

mation to discard is conﬁgurable through the deﬁni-

tion of a score threshold, allowing trade-off between

efﬁciency and effectiveness.

The criteria we tested are:

• random – A very naive method to reduce the num-

ber of words assigned to an image is to randomly

remove a speciﬁc percentage of local features in

the image description. This method is used as a

baseline in our experiments.

• scale – Most of the local features deﬁned in the

last years (e.g., SIFT and SURF) report the scale

at which the feature was extracted for each key-

point. The fact that extraction is not performed

at the original resolution is actually the main rea-

son for the scale invariant. Descriptions and in-

terest points detected at higher scale should be

also present at lower resolution versions of the

same images or of the same object. The intuition

is that the bigger the scale the higher the impor-

tance. This approach can be performed before the

words assignment phase increasing performance

also during the words assignment, since the cost

of assigning words to images is linear with the

number of local features. Please note that the

scale threshold is not deﬁned a priori but it de-

pends on the number of local features actually ex-

tracted from the image.

• tf – During the BoF words assignment phase, each

local feature is substituted with the identiﬁer of

the nearest word in the visual vocabulary. Thus,

after this step every image is described with a set

of visual words. Typically a word appears more

than once in an image description because dis-

tinct but similar local features in the original de-

scription were substituted by the very same visual

word. A possible approach for words reduction

is to remove the words having the lowest number

of occurrences. In this case we are ordering the

VISAPP2013-InternationalConferenceonComputerVisionTheoryandApplications

658

words with respect to their term frequency (tf ) in

the image. (Salton and McGill, 1986).

• idf – When words have been assigned to all the

images in the dataset, it is possible to evaluate

the inverse document frequency (idf ) (Salton and

McGill, 1986) of all the features in the vocabu-

lary. In Information Retrieval words with highest

idf are considered more important than the others

(Salton and McGill, 1986). Note that depending

on the relative idf values of the words describing

an image, the same word could be discarded for a

given image and retained in another.

• tf*idf – In information retrieval a very popular

strategy to assign relevance to words is the tf*idf

approach (Salton and McGill, 1986). This strat-

egy states that the relevance of a word in a docu-

ment is obtained by multiplying its tf in the given

document by its idf. We can use the same strategy

to order the visual words in an image and discard

ﬁrst the words with smaller tf*idf.

3 EXPERIMENTS

The effectiveness of the approaches is measured on

both a image retrieval and a landmark recognition

tasks using two distinct datasets. Efﬁciency is also

tested on a larger professional dataset intended for

similarity search. In the following we describe the

recognition system, the performance measures, the

datasets and we discuss the experimental results ob-

tained.

The retrieval engine used in the experiments is

built as following:

1. For each image in the dataset the SIFT local

features are extracted for the identiﬁed regions

around interest points.

2. A vocabulary of words is selected among all the

local features using the k-means algorithm.

3. The Random or Scale reduction technique is per-

formed (if requested).

4. Each image is described following the BoF ap-

proach, i.e., with the ID of the nearest word in the

vocabulary to each local feature.

5. The tf, idf, or tf*idf reduction technique are per-

formed (if requested).

6. Each image of the test set is used as a query for

searching in the training set. The similarity mea-

sure adopted for comparing two images is the Co-

sine between the query vector and the image vec-

tors corresponding to the set of words assigned to

the images. The weight assigned to each word of

the vectors are calculated using tf*idf measure.

7. In case the system is requested to identify the con-

tent of the image, the landmark of the most similar

image in the dataset (which is labeled) is assigned

to the query image.

Typically, the result obtained with the tf*idf

weighting and cosine similarity measure using in-

verted index is reordered considering geometric

checks based on RANSAC (Random Sample Consen-

sus). However, in this paper we focus on optimiz-

ing the number of words to improve efﬁciency of the

search performed through the inverted ﬁles and thus

we do not leverage on geometric consistency checks,

which are typically performed on a preliminary set of

candidate results or by customized search indexes.

The quality of the retrieved images is typically

evaluated by means of precision and recall measures.

As in many other papers (Philbin et al., 2007; Jegou

et al., 2009; Perronnin et al., 2010; J

egou et al., 2012),

we combined this information by means of the mean

Average Precision (mAP), which represents the area

below the precision and recall curve.

For evaluating the effectiveness of the recogni-

tion, which is basically a classiﬁcation task, we use

the micro-averaged accuracy and macro-averaged F

(i.e., the harmonic mean of precision and recall).

Macro-averaged scores are calculated by ﬁrst evalu-

ating each measure for each category and then taking

the average of these values. Note that for a recog-

nition task (i.e., single label classiﬁcation), micro-

averaged accuracy is deﬁned as the number of docu-

ments correctly classiﬁed divided by the total number

of documents of the same label in the test set and it is

equivalent to the micro-averaged precision, recall and

scores.

For evaluating the performance of the various re-

duction techniques approaches, we make use of three

datasets. The ﬁrst is the largely used Oxford Building

datasets that was presented in (Philbin et al., 2007)

and in many other papers. The dataset consists of

5,062 images of 55 buildings in Oxford. The ground

truth consists of 55 queries and related sets of results

divided in best, correct, ambiguous and not relevant.

The dataset is intended for evaluating the effective-

ness of a content based image retrieval systems that is

expected to put the images related to the very same

building at the top of the results list. In fact, the

measure of performance used for the evaluation is the

mean Average Precision (mAP). The authors of the

datasets also made available the words assigned to the

images using the BoF approach. The vocabulary used

has one million words.

We decided to use a second dataset to better eval-

OnReducingtheNumberofVisualWordsintheBag-of-Features

Representation

659

uate the performance of a systems intended for rec-

ognizing the landmark in photos. In this scenario it

is not important to retrieve most of the related im-

ages in the dataset but to correctly classify the im-

age. The Pisa dataset consists of 1,227 photos of 12

landmarks located in Pisa (also used in (Amato and

Falchi, 2011) and (Amato et al., 2011)). The pho-

tos were crawled from Flickr. The dataset is divided

in a training set (Tr) consisting of 226 photos (20%

of the dataset) and a test set (Te) consisting of 921

photos (80% of the dataset). The size of the vocabu-

lary used for the experiments with the BoF approach

is 10k. In this context the performance measures used

are typically accuracy, precision, recall and micro and

macro-averaged F

Finally, a larger dataset of about 400k images from

the professional Alinari

archive was used for efﬁ-

ciency evaluation. All the images were resized to have

a maximum between width and height equal to 500

pixels before the feature extraction process.

3.1 Evaluation

We ﬁrst report the results obtained in a content based

image retrieval scenario using the Oxford Building

dataset using the ground truth given by the authors

(Philbin et al., 2007). In Figure 1 we report the

mAP obtained. On the x-axis we reported the aver-

age words per image obtained after after the reduc-

tion. Note that the x-axis is logarithmic. We ﬁrst note

that all the reduction techniques signiﬁcantly outper-

form naive random approach and that both the idf and

scale approaches are able to achieve very good mAP

results (about 0.5) while reducing the average number

of words per image from 3,200 to 800. Thus, just tak-

ing the 25% of the most relevant words, we achieve

the 80% of the effectiveness. The comparison be-

tween the idf and scale approaches reveals that scale

is preferable for reduction up to 500 words per image.

Please note that it is almost impossible to only slightly

reduce the number of words with the tf approach be-

cause there is a large number of words (about 75%)

per image that have just one occurrence. Using the tf

approach they have the same quality score and can be

only ﬁltered as a whole.

While the average number of words is useful to

describe the length of the image description, it is actu-

ally the number of distinct words per image that have

more impact on the efﬁciency of searching using in-

verted index. Thus, in Figure 2, we report mAP with

respect to the average number of distinct words. In

this case the results obtained by tf*idf and tf are very

similar to the ones obtained by idf.

http://www.alinari.it

0.1

0.2

0.3

0.4

0.5

0.6

100 1000

mAP

Avg Words per Image

tf*idf

idf

scale

random

Figure 1: Mean average precision of the various selection

criteria obtained on the Oxford Buildings 5k dataset.

0.1

0.2

0.3

0.4

0.5

0.6

100 1000

mAP

Avg Distinct Words per Image

tf*idf

idf

scale

random

Figure 2: Mean average precision of the various selection

criteria obtained on the Oxford Buildings 5k dataset.

A second set of experiments was conducted on a

landmark recognition task using the Pisa dataset (see

Section 3). For this dataset we used a smaller vocab-

ulary of 10k words and features were extracted from

a lower size images (maximum 512 pixels per side).

Figure 3 reports the accuracy obtained by the various

approaches. On the x-axis we reported the average

words per image obtained after the reduction. All the

approaches, as expected, signiﬁcantly outperform the

random selection used as a baseline. The best results

are obtained by the idf approach. It is also interesting

to notice that the scale approach performs very well

for reduction up to 25%.

In Figure 4 we report the accuracy obtained with

respect to the average number of distinct words per

image by the various reduction approaches. The re-

sults signiﬁcantly differ from the previous ones. In

particular, the tf*idf and tf approaches exhibit better

results. It is worth to say that while the tf*idf ap-

proach relies on information about the training set for

VISAPP2013-InternationalConferenceonComputerVisionTheoryandApplications

660

0.5

0.55

0.6

0.65

0.7

0.75

0.8

0.85

0.9

10 100 1000

Accuracy

Avg Words per Image

tf*idf

idf

scale

random

Figure 3: Accuracy of the various selection criteria with

respect to the average number of words per image on the

Pisa dataset.

0.5

0.55

0.6

0.65

0.7

0.75

0.8

0.85

0.9

10 100 1000

Accuracy

Avg Distinct Words per Image

tf*idf

idf

scale

random

Figure 4: Accuracy of the various selection criteria with

respect to the average number of distinct words per image

on the Pisa dataset.

evaluating the idf values, the tf approach performs

almost as better as tf*idf can be applied not consider-

ing the dataset but only the image for which the words

have to be reduced. The scale approach exhibits good

results for average number of distinct words down

to 300 (i.e., a 25% reduction). Note that the scale

technique can be applied before the words assignment

thus reducing not only the search cost but also the cost

for the words assignment.

The accuracy measure captures the overall effec-

tiveness of the algorithm with respect to the expected

distribution of query between the classes. In order

to also evaluate the effectiveness across the various

classes (e.g., landmarks) we use the macro-averaged

measure. Macro-averaged values are calculated by

ﬁrst averaging the measures obtained for each cate-

gory. In Figure 5 we report the F

obtained by the

various approaches in terms of the average number

of distinct words per image. The most important dif-

0.5

0.55

0.6

0.65

0.7

0.75

0.8

0.85

0.9

10 100 1000

Macro

Avg Distinct Words per Image

tf*idf

idf

scale

random

Figure 5: Macro-averaged F

of the various selection crite-

ria with respect to the average number of distinct words per

image on the Pisa dataset.

ferences between these results and the one obtained

considering accuracy are related to the idf and Scale

approaches. While the scale approach reveals better

performances for small reduction even increasing the

overall efﬁcacy, the idf results becomes worse than

both the tf and idf ones. The intuition is that idf re-

lies on information related to the dataset and thus is

inﬂuenced by the different number of training images

per class. On the other hand, the scale approach is in-

dependent from the dataset, given that it does not rely

on the words, thus not even on the vocabulary.

In Figure 6 we report the average query execution

time obtained on the 400k image dataset with respect

to the average distinct words. Results are shown for

reducing the visual words on query only and on query

and dataset. While results are shown for the tf*idf

approach, similar performance are achieved with the

other approaches. In fact, for efﬁciency, it is actually

important only the average number of distinct words.

The results reveal, as expected, that high efﬁciency

gains can be obtained reducing the number of distinct

visual words. Note that the x-axis is logarithmic.

4 CONCLUSIONS

In this work, we have investigated visual words re-

duction approaches in order to improve efﬁciency of

the BoF approach minimizing the lost in effective-

ness. The gain in efﬁciency was tested on a similarity

search scenario of about 400k images, while effec-

tiveness was tested on two smaller datasets intended

for content based image retrieval and landmark recog-

nition.

We proposed methods that can be applied before

the visual words have been assigned and also methods

OnReducingtheNumberofVisualWordsintheBag-of-Features

Representation

661

0.1

0.2

0.3

0.4

0.5

10 100 1000

Average Seconds per Query

Avg Distinct Words per Image

query

query&data

Figure 6: Average search time with respect to the average

number of distinct words per image obtained reducing the

visual words on the query and on query and dataset.

based on statistics of the usage of visual words in im-

ages (tf ), across the database (idf ), and on the tf*idf

combination.

In the content based image retrieval scenario the

scale approach performed best and even better than

using all the words. However, for reduction over

an order of magnitude effectiveness signiﬁcantly de-

crease. In the landmark recognition task, the most in-

teresting results were obtained considering the macro-

averaged F

effectiveness measure with respect to the

average number of distinct words per image. The

tf*idf obtained the best results, but it is interesting

to see that the tf approach, which does not rely on

dataset information, obtained very similar results. It

is worth to note that the recognition task is more ro-

bust than the retrieval to words reduction. Moreover,

for small local features reductions scale was the over-

all best.

We plan to deﬁne new approaches and compare

with the ones proposed in this work on larger dataset

in the near future.

REFERENCES

Amato, G. and Falchi, F. (2011). Local feature based im-

age similarity functions for kNN classﬁcation. In

Proceedings of the 3rd International Conference on

Agents and Artiﬁcial Intelligence (ICAART 2011),

pages 157–166. SciTePress. Vol. 1.

Amato, G., Falchi, F., and Gennaro, C. (2011). Geometric

consistency checks for knn based image classiﬁcation

relying on local features. In SISAP ’11: Fourth In-

ternational Conference on Similarity Search and Ap-

plications, SISAP 2011, Lipari Island, Italy, June 30 -

July 01, 2011, pages 81–88. ACM.

Douze, M., J

egou, H., Sandhawalia, H., Amsaleg, L., and

Schmid, C. (2009). Evaluation of gist descriptors

for web-scale image search. In Proceedings of the

ACM International Conference on Image and Video

Retrieval, CIVR ’09, pages 19:1–19:8, New York, NY,

USA. ACM.

Jegou, H., Douze, M., and Schmid, C. (2009). Packing bag-

of-features. In Computer Vision, 2009 IEEE 12th In-

ternational Conference on, pages 2357 –2364.

egou, H., Douze, M., and Schmid, C. (2010). Improving

bag-of-features for large scale image search. Int. J.

Comput. Vision, 87:316–336.

egou, H., Perronnin, F., Douze, M., S

anchez, J., P

erez,

P., and Schmid, C. (2012). Aggregating local im-

age descriptors into compact codes. IEEE Transac-

tions on Pattern Analysis and Machine Intelligence.

QUAERO.

Lowe, D. G. (2004). Distinctive image features from scale-

invariant keypoints. International Journal of Com-

puter Vision, 60(2):91–110.

Perronnin, F., Liu, Y., Sanchez, J., and Poirier, H. (2010).

Large-scale image retrieval with compressed ﬁsher

vectors. In Computer Vision and Pattern Recogni-

tion (CVPR), 2010 IEEE Conference on, pages 3384

–3391.

Philbin, J., Chum, O., Isard, M., Sivic, J., and Zisserman,

A. (2007). Object retrieval with large vocabularies

and fast spatial matching. In Proceedings of the IEEE

Conference on Computer Vision and Pattern Recogni-

tion.

Salton, G. and McGill, M. J. (1986). Introduction to Mod-

ern Information Retrieval. McGraw-Hill, Inc., New

York, NY, USA.

Sivic, J. and Zisserman, A. (2003). Video google: A text

retrieval approach to object matching in videos. In

Proceedings of the Ninth IEEE International Confer-

ence on Computer Vision - Volume 2, ICCV ’03, pages

1470–, Washington, DC, USA. IEEE Computer Soci-

ety.

Thomee, B., Bakker, E. M., and Lew, M. S. (2010). Top-

surf: a visual words toolkit. In Proceedings of the in-

ternational conference on Multimedia, MM ’10, pages

1473–1476, New York, NY, USA. ACM.

Zhang, X., Li, Z., Zhang, L., Ma, W.-Y., and Shum, H.-

Y. (2009). Efﬁcient indexing for large scale visual

search. In Computer Vision, 2009 IEEE 12th Inter-

national Conference on, pages 1103 –1110.

VISAPP2013-InternationalConferenceonComputerVisionTheoryandApplications

662
