Speed Up Learning based Descriptor for Face Veriﬁcation

Hai Wang, Bongnam Kang, Jongmin Yoon and Daijin Kim

Department of Computer Science and Engineering, Pohang University of Science and Technology,

Pohang, Kyungbuk, 790-784, Republic of Korea

Keywords:

Face Recognition, Feature Extraction, LE Descriptor, LBP.

Abstract:

Many state of the art face recognition algorithms use local feature descriptors known as Local Binary Pattern

(LBP). Many extensions of LBP exist, but the performance is still limited. Recently Learning Based De-

scriptor was introduced for face veriﬁcation, it showed high discrimination power, but compared with LBP,

it’s expensive to compute. In this paper, we propose a novel coding approach for Learning Based Descriptor

(LE) descriptor which can keep the most discriminative LBP like feature as well as signiﬁcantly shorten the

feature extraction time. Since the proposed method speed up the LE descriptor’s feature extraction time, we

call it Speeded Up Learning Descriptor or SULE for short. Tests on LFW standard benchmark show the su-

periority of SULE with respect of several state of the art feature descriptors regularly used in face veriﬁcation

applications.

1 INTRODUCTION

Face Recognition is a very traditional research topic

in computer vision community. In the past twenty

years, a large number of approaches that tackled the

face recognition were proposed, such as the sub-

space analysis of PCA(Turk and Pentland, 1991),

ICA(Bartlett, 2002) and their extensions. While

these face recognition approaches commonly assume

that face images are well aligned and have a simi-

lar pose, in many practical applications it is impos-

sible to meet these conditions. To this end, face

recognition algorithms based on textures of small

pathes of face images, known as local appearance

descriptors, have shown excellent performance on

standard face recognition datasets. Such as Gabor

feature(Zheng, 2007), HOG(Alps and Montbonnot,

2005), SIFT(Lowe, 2004), SURF(Bay, 2008) and his-

togram of Local Binary Pattern(LBP)(Ahonen and

Pietikinen, 2006). A comparison of various local

descriptor based face recognition algorithms may be

found in (Mikolajczyk and Schmid, 2005) and (Cao

and Yin, 2010).

Among all the current popular local descriptors in

the literature, histogram of ULBP has become pop-

ular for face recognition task due to their simplicity,

computational efﬁciency, and robustness to change in

illumination. The success of LBP has inspired several

variations. These include local ternary pattern(Tan

and Triggs, 2010), high order derived LBP(Ahonen

and Pietikainen, 2007), multi scale LBP(Liao and Lei,

2007), patch based LBP(Wolf and Taigman, 2008),

LBP on Gabor magnitude images(Zhang and Zhang,

2005) and Decision Tree based LBP(Solar and Cor-

rea, 2009), to cite a few. However, these methods have

some drawbacks, either too complicated to compute

such as LBP on Gabor magnitude images, or show

better performance on certain database but has poor

performance on some other databases. Among all of

these LBP variations, decision tree based LBP corpo-

rate the LBP with the supervised learning, however,

it has several disadvantages such as the feature size

is too large for practical usage and the performance

greatly depends on the supervised learning procedure.

Inspired by Decision Tree based LBP, (Huang and

Miller, 2007) proposed a learning based descriptor

with unsupervised learning. Compared with other lo-

cal features, it has showed a better performance on

several challenging databases. But until now, no lit-

erature focus on the computation complexity of LE

descriptor.

In this paper, our main contribution is to propose

a coding method that explicitly learns discriminative

descriptor from the training data the same as that in

original Learning based descriptor (LE). Our learn-

ing method is based on K-d tree approach. As a test-

ing scenario, we ﬁnd that our approach is much faster

and efﬁcient than the original LE descriptor while can

maintain almost the same recognition performance in

the same experiment setting.

762

Wang H., Kang B., Yoon J. and Kim D..

Speed Up Learning based Descriptor for Face Veriﬁcation.

DOI: 10.5220/0004278007620767

In Proceedings of the International Conference on Computer Vision Theory and Applications (VISAPP-2013), pages 762-767

ISBN: 978-989-8565-47-1

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

The rest of this paper is organized as follows. Sec-

tion 2 introduces some basic related work in the ﬁeld

of local descriptor, Section 3 presents the LE descrip-

tor. Section 4 discusses the disadvantage of the LE de-

scriptor and presents the main details of our approach.

In Section 5, extensive experiments are conducted and

the experimental results are given. Finally, Section 6

concludes our work and ﬁgures out some possible fu-

ture work.

2 RELATED WORK

Several local appearance descriptors have been used

in face recognition task. Among all of them, LBP

and its extensions are the most widely used. Here,

we constrain our discussion within the LBP based ex-

tension descriptors. (Tan and Triggs, 2010) proposed

local ternary pattern(LTP), instead of directly compar-

ing the neighbour pixel’s value with the center value,

LTP compares the neighbour pixel’s value with the

center value with a certain threshold. By doing so, it

can remove some noise in the image, but the improve-

ment is very limited. (Ahonen and Pietikainen, 2007)

proposed High order derived LBP, which calculates

the LBP value based on the previous LBP coded im-

age, in literature, it showed that the third derivative

LBP has the best performance, but its performance is

not stable, i.e., in some databases, it has good perfor-

mance, in some databases, the performance improve-

ment is not so signiﬁcant. (Liao and Lei, 2007) pro-

posed Multi Scale LBP(MS-LBP), in this approach,

they compare the neighbour blocks’ mean gray value

instead of compare the pixel level’s gray value, it has

been demonstrated better performance when used for

classiﬁcation problem, as for face recognition, the

performance is worse than original LBP. (Wolf and

Taigman, 2008) proposed patch based LBP, specif-

ically, three patch LBP and four patch LBP, com-

pared with LBP, it’s efﬁcient to compute but the per-

formance improvement is not so signiﬁcant, in some

cases, even a little worse. (Marr and Hildreth, 2005)

proposed soft LBP, instead of assign each value a cer-

tain binary value, they assign each pixel with a range

of values, and each value with some probability, due

to the comparison is not direct between pixels, so this

method is not robust to illumination, and also, due to

for each pixel, it has different probability assigned to

it with certain values, it’s computation complicated.

(Zhang and Zhang, 2005) and (Xie and Gao, 2008)

proposed LBP on Gabor magnitude images, it showed

better performance and has been widely used, but to

calculate Gabor image, we need to convolve the im-

age with Gabor ﬁlters, which is expensive, so this

method is not suitable for the face recognition which

requires high speed. (Solar and Correa, 2009) pro-

posed Decision Tree based LBP, by combining the

LBP with the supervised learning, it has showed good

performance, but the performance is not stable, also,

the feature size is extremely large to put it into practi-

cal usage.

3 LEARNING BASED

DESCRIPTOR

Learning based descriptor is a novel feature extrac-

tion method for face recognition. Compared with Lo-

cal Binary Pattern, it corporates the feature extraction

with the unsupervised learning method, and it’s more

robust to pose and facial expression variation. The

speciﬁc steps of LE descriptor can be brieﬂy summa-

rized as follows:

• DoG Filter

To remove the noise and illumination difference

in the image, each face image is feed to the DoG

ﬁlter(Hartigan and Wong, 1979) ﬁrst. The con-

tinued face image processing are based on the ﬁl-

tered image.

• Sampling and Normalization

At each pixel, sample its neighboring pixels in the

ring based pattern to form a low level feature vec-

tor. We sample r×8 pixels at even intervals on

the ring of radius r. In each sampling pattern, it

has three different parameters, i.e., ring number,

ring radius, sampling number of each ring. After

sampling, we normalize the sampled feature vec-

tor into unit length with L1 norm.

• Learning based Encoding

An encoding method is applied to encode the nor-

malized feature vector into discrete codes. Unlike

many handcrafted encoders, in LE approach, the

encoder is speciﬁcally trained for the face in an

unsupervised manner from a set of training face

images. In the paper, they recommend three unsu-

pervised learning methods: K-means(McNames,

2001), PCA tree(Dasgupta and Freund, 2007),

and random projection tree(Bentley, 1975). Af-

ter the encoding, the input image is turned into a

coded image.

• Histogram Representation

After the image has been encoded into coded im-

age, following the method described in Ahone et

als work, the encoded image can be divided into

a grid of patches. A histogram of the LE codes is

computed in each patch and the patch histogram is

SpeedUpLearningbasedDescriptorforFaceVerification

763

Figure 1: Pipeline of LE descriptor.

concatenated to form the descriptor of the whole

face image.

The overall procedure of the LE descriptor

pipeline is shown as following Figure 1:

In the paper, although the performance difference

of different coding methods is very small as they

stated within 1% difference, random projection tree

encoding method shows the best performance among

the three coding methods, in the following section, we

use the random projection tree as the LE descriptor’s

default encoding method.

4 SPEED UP LEARNING BASED

DESCRIPTOR

4.1 Discussion on Learning based

Descriptor

From previous description of the LE descriptor, we

can ﬁnd that the key lies in the learning based coder,

one of the most important characteristics of the learn-

ing approach is that they should partition the normal-

ized feature vector space into the same size, so that

in the discrete feature space, each discrete bin can be

hit by the same frequency. But in all the three coding

methods, it’s expensive to calculate the correspond-

ing bin number. For example, for one pixel, if we

use 2 rings, and assume the vector size for each pixel

is 25, and suppose the bin size is 64, then if we use

K means to encode the pattern, to assign a pixel dis-

crete value, we need to ﬁnd the nearest cluster center,

this operation needs 64×25 multiplications and a cer-

tain number of additions to calculate the Euclidean

distance. If we use random projection tree or PCA

tree, then we need 6×25 multiplications and certain

number of additions. Compared with LBP, it’s too ex-

pensive. In addition, the multiplication is performed

between two fractions, if we consider its implementa-

tion on the embedding system, due to most of the em-

bedding system doesn’t have the Floating Point Unit

(FPU), these ﬂoating point multiplications will take

certain time and constrain the practical usage of LE

descriptor.

From this point, it’s necessary for us to ﬁnd some

alternatives which can code the normalized unit fea-

Figure 2: Partition the space.

ture without using too many multiplications while can

keep the high discrimination power of the LE descrip-

tor. By analysis the procedure of LE descriptor, we

can ﬁnd the key is to partition the normalized unit

feature space into the different same size partitions,

not the partition method itself is critical to the perfor-

mance. In addition, we notice that the performance

difference caused by different partition methods is not

signiﬁcant. From this point, we can use some other

much simpler method such as K-d tree to partition the

feature space, and the details can be found in the fol-

lowing section.

4.2 Kd Tree based Learning Descriptor

K-d tree is a d dimension binary tree, it can be used to

fast ﬁnd the nearest neighbor in the d dimension vec-

tor space, or to partition the vector space, it’s a kind

of extension of the 1 dimension binary tree. Given

some data points, we can build a corresponding K-d

tree as the manner of building a one dimension binary

tree, the only difference is that in K-d tree, each time

when we pick one dimension data as the pivot, and

then compare all data points with the pivot using the

corresponding picked one dimension value. By such

a manner, we can divide the space into smaller spaces

recursively. When used for nearest neighbor search,

we ﬁrst need to build K-d tree using the gallery data

points, then given some query points, according to

the tree we build, we can ﬁnd the nearest neighbor

in O(NlogN). When used for partition the space, we

can ﬁrst decide the tree level n, then the space can be

partitioned to 2

n−1

sub spaces, and each space has the

same number of data points. An illustration diagram

of K-d tree is shown in Figure 2.

Figure 2 gives the space partition result. Notice

in this case, the K-d tree is balanced, in our K-d tree

based learning based descriptor, we use the balanced

K-d tree.

If we use K-d tree to partition the spaces, we can

partition the current space to two sub spaces each

time, by recursively partition the spaces, ﬁnally we

VISAPP2013-InternationalConferenceonComputerVisionTheoryandApplications

764

can partition the space into several sub spaces. Ran-

dom projection tree and PCA tree also can partition

the space into several subspaces, but the partition ap-

proach is different, in random projection or PCA tree,

for one time partition, we need to multiply the feature

vector with the coefﬁcients, if we recursively partition

the space, we need multiply it with the coefﬁcients

consecutively. In K-d tree, for each time partition,

we just need compare the corresponding coordinate

with the pivot, if we recursively partition the space,

we just need compare it with the corresponding coor-

dinate consecutively.

5 EXPERIMENT

To demonstrate our proposed approach, in this sec-

tion, we compare the performance of our proposed

SULE with the original LE descriptor in terms of face

veriﬁcation task.

To evaluate our approach with the original LE

descriptor fairly, all the experiment settings for LE

descriptor and our SULE descriptor are exactly the

same, the only difference is the coding method. In our

experiment, we use the face image from LFW(Huang

and Miller, 2007) for unsupervised learning. LFW

database is a very challenging data set with 13,233

face images of 5,749 persons collected from the web.

It has two views for its own data. View 1 partitions

the 5,749 persons into training and testing set for de-

velopment purposes such as model selection and pa-

rameter tuning. View 2 divides them into ten disjoint

folds and speciﬁes 300 positive pairs and 300 nega-

tive pairs within each fold: positive pairs are instances

of the same person while negative pairs are those of

different persons. We follow the LFW conﬁguration

that allows us to use the face data on View 1 to train

the SULE and LE data. Also, we normalize the LFW

database by two eye positions which can be detected

by our eye detector. As suggested from the LE pa-

per, more images used for training cannot guarantee a

better performance, here we choose 100 images with

size 250×250 to train, we believe our training sample

is enough. After training, we then use the View 2 face

data to evaluate our SULE and LE descriptor.

To demonstrate our approach, we don’t use any

other advanced face veriﬁcation or face recognition

techniques, i.e., we just crop the face image to

150×80, then extract features for the cropped face

image and then directly use Chi-Square matching to

calculate the distance of two feature vectors.

Figure 3: Performance comparison vs. Learning method.

Table 1: Performance Evaluation.

Approach SULE(%) LE(%) ULBP(%)

Performance 74.23 74.81 70.36

5.1 Experimental Results

First, we give the performance comparison result with

different bin numbers in each histogram.

From Figure 3, we can see that with different bin

numbers (partition the spaces into different number

subspaces), the performance difference between our

SULE descriptor and the LE descriptor is very small,

which coincide our early assumption that that the cod-

ing method is not critical for the ﬁnal performance.

Also, we can ﬁnd that with large bin number, we can

get a better performance. In the continuous experi-

ment, we use 64 bins. Here, we give the speciﬁc per-

formance using 64 bins in Table I.

Second, in the LE paper, they suggest after feature

extraction, we can use PCA to lower the dimension

of the feature, combined with the cosine similarity, it

can improve the performance. Here, we also follow

the rules, the performance is shown in Figure 4. Due

to large code number cause large feature size, and this

make PCA intractable, here, we just show the perfor-

mance of using 64 code number using Random Pro-

jection tree and Kd tree.

From Figure 4, we can ﬁnd that in this experiment

settings, our SULE descriptor can achieve almost the

same performance compared with LE descriptor.

In addition, we give the ROC curve using different

descriptors in Figure 5.

We also give the computation complexity for cal-

culating the SULE and LE descriptor in Table II. The

result is under the 64 code number settings, notice that

this doesn’t include the preprocessing time in case of

LE descriptor and SULE descriptor due to the prepro-

cessing time just takes up a small part of total pro-

cessing time in these two descriptors.

In table II, C means comparison operation, M

SpeedUpLearningbasedDescriptorforFaceVerification

765

Figure 4: Principal Component Dimension.

Figure 5: ROC curve of descriptors with different coding

methods.

Table 2: Computation Time.

Approach SULE(C) LE(M) ULBP(C)

Operation 6 25*64 8

means the multiplication operation. From Table II,

we can ﬁnd that our SULE is much simpler than LE

and more efﬁcient to compute, especially when we

implement the algorithm on embedding system. If we

don’t consider the preprocessing time, compared with

ULBP, our approach is still has a slightly advantage in

terms of feature extraction time, consider the prepro-

cessing step, the overall computation time of SULE is

a little larger than ULBP. But to the best of our knowl-

edge, this is a good trade off between the computation

time and recognition performance among several LBP

based extensions.

5.2 Results Discussion

From the experimental results from face veriﬁcation,

we can see that our proposed Speed Up Learning De-

scriptor can keep the high discrimination feature of

face images as that for Learning Descriptor, mean-

while, our SULE is much simple and efﬁcient to com-

pute. In the task of face veriﬁcation, our SULE can

achieve comparable performance with LE descriptor

in all the different experiment settings, all these re-

sults demonstrate that our SULE is a good alterna-

tive of LE descriptor. In addition, we ﬁrmly believe

that the simpliﬁcation of our SULE can inspire some

other extensions of LE descriptor. The ﬁrst one is

that our method is efﬁcient to calculate, if we don’t

care the feature size, we can extract features using

large bin number without signiﬁcantly increasing the

computation time, as we know, large bin number al-

ways guarantees a better performance. The second

point is that our method doesn’t need multiplication,

this makes our method is especially suitable for face

recognition application on embedding system, and the

performance of our SULE is also quite competitive

compared with other face recognition method on em-

bedding system. In addition, high speed face recog-

nition on embedding system still remains a difﬁcult

problem, we think that our approach can be good so-

lution to this problem. The next point is that, instead

of training our encoder with the holistic face images,

we can train our encoder with different face patches,

each patch has a encoder which can capture the struc-

ture details of each face patch better, and we believe

that patch based SULE can further improve the ver-

iﬁcation accuracy. The ﬁnal point is that we think

our SULE can extend to some other task such as hu-

man/car classiﬁcation, eye detection and object detec-

tion.

6 CONCLUSIONS

In this paper, we proposed a novel method that uses

training pattern to create discriminative LE descriptor

by using K-d tree. The algorithm obtains encourag-

ing results on standard database while signiﬁcantly re-

duce the computation complexity. In particular, with

respect to a face recognizer based on the widely used

LBP, our approach also presents a considerable in-

creasing in recognition accuracy, demonstrating the

advantages of using K-d tree to train the feature pat-

tern.

As future work, our current implementation does

not use different face patches to train different en-

coders, also we don’t consider weights to different

face patches. Incorporating weights has been shown

to be an effective strategy in various similar works,

such as (Solar and Correa, 2009). Finally, although

our SULE and LE use DoG ﬁlter to make our ap-

proach robust to illumination, but compared with

ULBP, the DoG ﬁlter’s effect is still not enough, to

VISAPP2013-InternationalConferenceonComputerVisionTheoryandApplications

766

make SULE and LE descriptor more robust to illu-

mination, we need explore some other simple prepro-

cessing technique to solve the illumination problem.

ACKNOWLEDGEMENTS

This research was supported by the Implementation

of Technologies for Identiﬁcation, Behavior, and Lo-

cation of Human based on Sensor Network Fusion

Program through the Ministry of Knowledge Econ-

omy (Grant Number: 10041629) and also this re-

search was supported by the Basic Science Research

Program through the National Research Foundation

of Korea(NRF) funded by the Ministry of Education,

Science and Technology(2012-0008835).

REFERENCES

Ahonen, T. and Pietikainen, M. (2007). Soft histograms for

local binary patterns. In Finnish Signal Processing

Symposium. SciTePress.

Ahonen, T. and Pietikinen, M. (2006). Face description with

local binary patterns: Application to face recognition.

IEEE Transaction on Pattern Analysis And Machine

Intelligence, pages 2037–2041.

Alps, I. and Montbonnot (2005). Histograms of oriented

gradients for human detection. In IEEE Computer

Society Conference on Computer Vision and Pattern

Recognition. SciTePress.

Bartlett, M. (2002). Face recognition by independent com-

ponent analysis. IEEE Trans. on Neural Networks,

pages 1450–1464.

Bay, H. (2008). Surf: Speeded up robust features. Computer

Vision and Image Understanding, pages 346–359.

Bentley, J. (1975). Multidimensional binary search trees

used for associative searching. Communications of the

ACM, pages 509–517.

Cao, Z. and Yin, Q. (2010). Face recognition with learning-

based descriptor. In IEEE Computer Society Con-

ference on Computer Vision and Pattern Recogni-

tion(CVPR). SciTePress.

Dasgupta, S. and Freund, Y. (2007). Random projection

trees and low-dimensional manifolds. UCSD Techni-

cal Report CS2007-0890, pages 1615–1630.

Hartigan, J. and Wong, M. (1979). Algorithm as 136: A

k-means clustering algorithm. Journal of the Royal

Statistical Society. Series C (Applied Statistics), pages

100–108.

Huang, G. and Miller, E. (2007). Labeled faces in the wild:

A database for studying face recognition in uncon-

strained environments.

Liao, S. and Lei, Z. (2007). Learning multi-scale block lo-

cal binary patterns for face recognition. Advances in

Biometrics, pages 828–837.

Lowe, D. (2004). Distinctive image features from scale-

invariant keypoints. International Journal Computer

Vision, pages 91–110.

Marr, D. and Hildreth, E. (2005). Theory of edge detec-

tion. Proceedings of the Royal Society of London,

pages 1615–1630.

McNames, J. (2001). A fast nearest neighbor algorithm

based on a principal axis search tree. IEEE Trans-

actions on Pattern Analysis and Machine Intelligence,

pages 964–976.

Mikolajczyk, K. and Schmid, C. (2005). Performance eval-

uation of local descriptors. IEEE Transactions on Pat-

tern Analysis and Machine Intelligence, pages 1615–

1630.

Solar, R. and Correa, M. (2009). Recognition of faces

in unconstrained environments: A comparative study.

EURASIP Journal on Advances in Signal Processing,

pages 1–20.

Tan, X. and Triggs, B. (2010). Enhanced local texture fea-

ture sets for face recognition under difﬁcult lighting

conditions. IEEE Transactions on Image Processing,

pages 1635–1650.

Turk, M. and Pentland, A. (1991). Eigenfaces for recogni-

tion. Journal of Cognitive Neurosicence, pages 71–86.

Wolf, L. and Taigman, Y. (2008). Descriptor based methods

in the wild. In Real-Life Images Workshop at ECCV.

SciTePress.

Xie, S. and Gao, W. (2008). V-lgbp: Volume based lo-

cal gabor binary patterns for face representation and

recognition. In IEEE Conference on Pattern Recogni-

tion(ICPR). SciTePress.

Zhang, W. and Zhang, H. (2005). Local gabor binary

pattern histogram sequence (lgbphs): A novel non-

statistical model for face representation and recogni-

tion. In IEEE Conference on Computer Vision(ICCV).

SciTePress.

Zheng, Z. (2007). Gabor feature-based face recognition us-

ing supervised locality preserving projection. Signal

Processing, pages 2473–2483.

SpeedUpLearningbasedDescriptorforFaceVerification

767
