SHIBBOLETH WEB-PROXY FOR SINGLE SIGN-ON OF CLOUD

SERVICES

Thomas R

ubsamen and Christoph Reich

Cloud Resarch Lab, Hochschule Furtwangen University, Furtwangen, Germany

Keywords:

Cloud Computing, Shibboleth, Single Sign-on, Reverse Web Proxy.

Abstract:

Single Sign-On (SSO) allows users to access services, for which they possess sufﬁcient access rights, without

re-authentication once they are authenticated successfully. Shibboleth supports SSO of web services and

allows building federations.

In this paper a Shibboleth web proxy is described, which integrates a Shibboleth service provider to manage

authentication and extends Cloud management systems by enabling SSO of multiple cloud services. It is

shown how this approach can be used for highly dynamic Cloud environments, where services are often added

and removed. The Shibboleth web proxy implementation has been contributed to the Open Source Community

and is made available in the OpenNebula EcoSystem.

1 INTRODUCTION

Single sign-on solutions are more and more widely

deployed in today’s Internet environment. The main

reason for this is the rapidly growing number of cre-

dentials (e.g. usernames and passwords) a user has to

manage. Single sign-on allows the reduction of user

credentials while offering a uniform access mecha-

nism to web services.

Shibboleth(shi, 2011) is an open source single

sign-on system which is commonly used in academic

service infrastructures like the ”Authentication and

Authorization Infrastructure” provided by the Ger-

man Research Network (”Deutsches Forschungsnetz,

DFN-AAI”)(DFN-AAI, 2011). This infrastructure

forms a federation of research facilities like uni-

versities or institutes but also commercial and non-

commercial entities in Germany. So far there are 68

identity providers organized in the DFN-AAI, includ-

ing the identity provider of the University of Applied

Science Furtwangen. In a federation, Shibboleth-

enabled web services can be used by all members of a

federation according to the access policies of the ser-

vices, based on common agreed Shibboleth attributes.

Another important technology in today’s IT in-

frastructures is cloud computing. One of its main

characteristics is a highly dynamic service environ-

ment. The University of Applied Science Furtwan-

gen is actively developing a private cloud infrastruc-

ture, which offers services to its employees and stu-

dents (Sulistio et al., 2009) and is based on Open-

Nebula (OpenNebula, 2011). The integration of this

private cloud infrastructure and the services hosted

in this environment into the university’s user man-

agement and especially into the existing Shibboleth-

based single sign-on system is the focus of this paper.

To keep an overview of existing bindings between

services (and their service providers) and the identity

provider it is quite common to hard-code this rela-

tionship. This leads to manageability problems when

Shibboleth needs to be used in very dynamic environ-

ments where services are often added and removed.

Static conﬁguration also means a lot of administrative

overhead. In this scenario the identity providers need

to be reconﬁgured every time a service (and its service

provider entity) gets added or removed. The result-

ing downtimes are unacceptable because of the major

importance of this system component for other, non-

cloud-based services. In cloud-based environments

the integration of services into a shibboleth-based au-

thentication and authorization infrastructure need to

be automatic and as dynamical as possible.

In this paper a system is described, which was

developed to allow usage of Shibboleth-based Sin-

gle Sign-On for cloud-based services in a dynamic

way. With this system it is also possible to host

web services in a private network, as deﬁned by RFC

1918 (rfc, a) to overcome the limited availability of

public IPv4 addresses.

This paper is structured in the following way. In

Reich C. and Rübsamen T..

SHIBBOLETH WEB-PROXY FOR SINGLE SIGN-ON OF CLOUD SERVICES.

DOI: 10.5220/0003926000890095

In Proceedings of the 2nd International Conference on Cloud Computing and Services Science (CLOSER-2012), pages 89-95

ISBN: 978-989-8565-05-1

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

this section the necessity and the goals of the devel-

oped system were described. In section 2 follows

a short introduction to the Shibboleth single sign-on

system and a classiﬁcation of different web proxy sce-

narios which are relevant for the developed system. In

section 3 follows a description of the proposed solu-

tion with its associated advantages and disadvantages.

Section 4 describes the OpenNebula integration, fol-

lowed by section 5, which presents the results of an

internal evaluation of the performance of the Shibbo-

leth web proxy system. Related work is presented in

section 6 followed by a conclusion and possible future

development tasks in section 7.

2 SHIBBOLETH AND HTTP

PROXY

First, in this section, an overview about the Shibboleth

SSO systems (shi, 2011) is given. Second the differ-

ences between the used reverse proxy concept and the

commonly used forward proxy concept is described.

2.1 Shibboleth

The two main components in a Shibboleth infrastruc-

ture are the Identity Provider (IdP) and the Service

Provider (SP). The Identity Provider is usually con-

nected to an organization’s user management system

and takes control over user authentication. Addition-

ally the IdP provides information about users in form

of attributes which are stored in the user management

backend (e.g. a LDAP backend). These attributes

(e.g. username, role etc.) can be used to make autho-

rization decisions whether a user can access certain

resources or not. The Service Provider (SP) is the sec-

ond important component of Shibboleth. It is usually

run as a plugin on the web server hosting the resource

which needs to be protected. The SP authorizes re-

source access requests and also takes control of the

user authentication process if no authentication token

exists in the session context. These processes are usu-

ally completely independent of the resource which is

to be protected. This means a resource (e.g. a web ap-

plication) does not necessarily have to be customized

for use in combination with Shibboleth.

If multiple resources are located on one web

server it is also possible to protect those with one SP

running on that host. One important thing to con-

sider is that there always has to be a binding between

a SP and its IdPs. This can be done by adding the

SP’s metadata to an IdP’s conﬁguration, which can

either be done manually or automatically by request-

ing current metadata information from the SP (Shib-

boleth 2 Documentation, 2011a). Another way to cre-

ate this binding is to register the SP in a federation

which propagates the metadata information to the IdP.

A Shibboleth Federation is an agreement between ser-

vice providers and IdPs wishing to access those re-

sources. All parties need to agree on a common set of

acceptable authorization attributes for their users, and

a schema to describe them.

2.2 HTTP Proxy

The classic web proxying differentiates two distinct

communication directions: Forward Proxy, a clas-

sic web cache is also called a forward proxy and is

usually located near the client. Reverse Proxy, a re-

verse proxy is near the requested resource and used

for server performance optimization. Many of today’s

HTTP daemons provide reverse proxying functional-

ity, such as the Apache HTTP Daemon which has been

used for developing our approach described in this pa-

per.

3 SHIBBOLETH WEB-PROXY

In this section the concept of a Shibboleth web proxy

and the developed prototype will be described. A re-

verse proxy in combination with a Shibboleth service

provider (SP) on the same host will be used to provide

authentication and authorization to resources hosted

in the cloud (PaaS and SaaS services). Any HTTP

requests to resources or services will be forwarded

through the proxy server. Figure 1 displays the archi-

tecture of the developed system. The client is a classic

browser session where a protected resource has been

requested. The IdP acts like in the classic scenario.

One major difference to the classic Shibboleth sce-

nario is that the web servers hosting the resource do

not act as SPs anymore. The SP functionality has been

moved to a single host, the reverse proxy, in the mid-

dle of ﬁgure 1. There is only one SP which is bound

to the home organization’s IdP. Obviously in the de-

scribed architecture the reverse proxy is a single point

of failure and could be a single point of attack also as

all trafﬁc must be routed over it. We are aware of this,

but see solving this problem as part of future research

as it is not in the scope of this paper.

The reverse proxy is responsible for forwarding

requests to the web servers. One problem that arises

is how to identify which resource has to be contacted.

To solve this, there are a couple of different possi-

ble identiﬁcation schemes which can used. These

schemes will be discussed in the following. One thing

to keep in mind is that all requests are sent to the re-

CLOSER2012-2ndInternationalConferenceonCloudComputingandServicesScience

verse proxy. Information about the actual resource

that is to be contacted must be encoded into the re-

quest URL in some way. There are two possible ways

to do this. First a part of the the request URL path

can be used. Second the DNS domain name part of

the request URL, especially the hostname part, can

be used. This way Apache’s virtual host functionality

can be used to identify which resource to contact.

Figure 1: Shibboleth web proxy scenario.

3.1 Resource Identiﬁcation using URL

Path

Request are always sent directly to the proxy (e.g.

”http://proxy.example.com”). To identify the ac-

tual requested resource, the path portion of the re-

quest URL is used (e.g. ”http://proxy.example.org/

servicea”). The proxy analyzes the path component

and forwards requests to the according web server.

This way different path values result in requests to

different resources, and usually different web servers,

behind the proxy. Figure 2 illustrates this scenario. A

client requests access to the resource ”servicea”. The

request is sent to the reverse proxy which acts as a

Shibboleth SP. After authenticating the user and au-

thorizing the access to the resource, the request is for-

warded to web server 1 which hosts the requested re-

source. The authentication and authorization process

works as previously described. Of course it is possible

to use different authentication and authorization con-

ﬁgurations for each resource (each conﬁgured path on

the proxy) or no Shibboleth at all. If the authenti-

cation or authorization process fails, requests are not

forwarded to the web server and access is denied.

This architecture allows relatively easy integration

of a single SP into a classic reverse proxy. However

there are some major downsides to this approach. Re-

quest URLs can quickly become overly complex. An-

other downside is that SSL cannot be used effectively.

In fact there can be no end-to-end encryption using

SSL. It is possible to use SSL between the client and

the reverse proxy and it is also possible to use SSL

between the reverse proxy and the web server hosting

the resources, but the proxy server will always (tem-

porarily) terminate the SSL connection and therefore

see unencrypted data.

Figure 2: Proxy scenario with service identiﬁcation using

paths.

3.1.1 Extension: HTTP-redirect to HTTPS

As previously stated relying on paths for resource

identiﬁcation can become very complex very quickly

and lead to unhandy URLs. A simple extension to

this approach can reduce complexity by using HTTP

redirects and virtual hosting capabilities on the re-

verse proxy. A name-based virtual host can be cre-

ated on the proxy for every resource hosted behind

it. Clients can now access URLs of a name-based

virtual host. Those virtual hosts are combined with

DNS alias records pointing to the proxy server. The

proxy can now process the virtual hostname and cre-

ate a request to the more complex path-based identi-

ﬁcation scheme and redirect the client to this URL.

This method can also be used to force all requests to

use HTTPS. The resulting less complex URLs makes

it more easy for the user to handle them. Neverthe-

less this approach does not solve the SSL end-to-end

encryption problem.

3.2 Service Identiﬁcation using Virtual

Hosts

Another way to identify resources behind the reverse

proxy is the use of virtual hosting capabilities of the

HTTP daemon (in our case Apache HTTPD). Virtual

hosting was initially developed to allow more web

services to be hosted on a single web server using

multiple DNS aliases. There are two different types

of virtual hosting:

SHIBBOLETHWEB-PROXYFORSINGLESIGN-ONOFCLOUDSERVICES

• IP-based Virtual Hosting. When IP-based vir-

tual hosting is used the web server listens for

incoming connections on multiple IP addresses.

These addresses can be aliases on the same net-

work interface or addresses on different inter-

faces. For each address the web server is now able

to host different virtual hosts (e.g. different web

sites). To the client this seems like there are differ-

ent web servers hosting each of those sites when

there is in fact only one web server hosting them.

• Name-based Virtual Hosting. The second type

is name-based virtual hosting. The web server

listens on only one IP address. Using the fully-

qualiﬁed DNS name it is also possible to host mul-

tiple sites on one web server. For this mechanism

to work all DNS names point to one web server.

This can be done using DNS aliases (CNAME re-

source records). When a resource is requested

the web server now analyzes the HTTP request

header. According to the hostname which is found

the request is forwarded to a different virtual host.

Name-based virtual hosting is the more commonly

used variant, when it is required to separate resources

logically and hosting them on the same web server

because it is usually easier to manage DNS aliases

and there is no need for additional IP addresses.

A system which uses a Shibboleth proxy and vir-

tual hosting for resource identiﬁcation has to do ac-

cess authentication and authorization on the basis of

virtual hosts. Figure 3 displays this scenario. In the

ﬁrst step a client has to resolve a DNS alias (CNAME)

like ”http://servicea.example.com”. The result will be

the IP address of the proxy server. Now the client will

send the resource request to the proxy server which

extracts the hostname of the target resource from the

request header. According to this hostname a virtual

host is chosen and the request is forwarded to the right

web server. During this process Shibboleth authenti-

cation and authorization is performed.

At ﬁrst this seems like the more elegant solution to

the problem of resource identiﬁcation. But there are

also some major downsides to this approach. For in-

stance the usage of SSL or TLS between the client

and the proxy is very complicated. The main rea-

son for this is in the nature of the SSL/TLS proto-

col. The identiﬁcation of the virtual host to which

the HTTP request has to be sent is included in the

HTTP request header. However, this information is

not available on the proxy right away. In fact the re-

quest has to be decrypted ﬁrst. The target of the re-

quest is a virtual host (e.g. ”servicea.example.com”)

but the SSL connection was established to the proxy

(e.g. ”proxy.example.com”). This results in a host-

name mismatch error. The most simple solution to

this would be using a wildcard certiﬁcate (e.g. for

*.example.com) on the proxy, but this is a generally

discouraged approach. A better solution would be us-

ing a TLS protocol extension which tries to solve this

problem.

Figure 3: Proxy scenario with service identiﬁcation using

virtual hosts.

3.2.1 Extension: Server Name Indication

Server Name Indication (SNI) is an extension for the

Transport Layer Security (TLS) (rfc, b) protocol. It

allows the client to send the server name of the request

URL during establishment of the the encrypted con-

nection. The server name is usually the fully qualiﬁed

DNS hostname of the requested resource. This way it

is possible for the web server to choose the right cer-

tiﬁcate (e.g. the certiﬁcate matching the hostname of

the virtual host).

A major problem in current browser implementa-

tions of TLS is the support for SNI. Despite the wide

support of SNI on all major platforms (Microsoft

Windows, Linux, Mac OS) and Browsers in their cur-

rent releases it gets problematic if not the most cur-

rent browser versions are used. For best compatibility

it is still best to not rely on SNI support (TLS SNI

Test Site: *.sni.velox.ch, 2011). The most problem-

atic combination would be Windows XP, which is still

widely used, and Internet Explorer.

4 IMPLEMENTATION OF

SHIBBOLETH WEB-PROXY IN

THE CLOUDIA PROJECT

The University of Applied Science Furtwangen is ac-

tively researching Cloud Computing technology. The

Cloud Research Lab’s project ”Cloud Infrastructure

CLOSER2012-2ndInternationalConferenceonCloudComputingandServicesScience

Figure 4: Cloud management system of CloudIA.

and Applications” (CloudIA) (Cloud Research Lab -

Department of Computer Science, 2011) has devel-

oped a private cloud infrastructure based on Open-

Nebula (OpenNebula, 2011) and cloud based services

to enhance this platform.

CloudIA leverages various virtualization tech-

nologies, such as Xen and KVM, and supports

Service-Level Agreements (SLAs) in IaaS and SaaS

models, as shown in Figure 4. In this Figure, the

Cloud Management System (CMS) of CloudIA is di-

vided into several layers (User Interface, Business,

System, Resource Interface) as well as two compo-

nents (Monitoring & Management, Security) for ex-

tensibility and maintainability.

Services in this cloud system are hosted on dy-

namically created virtual machines. That means the

ﬂuctuation of VMs (creation and deletion) is very

high. As previously stated it is one of the major goals

to integrate the cloud infrastructure with the user man-

agement system of the university. Therefore it was

necessary to ﬁnd a solution which integrates services

hosted in the cloud with our Shibboleth infrastructure

while maintaining the dynamic character of cloud en-

vironments. As a result of the research conducted by

the Cloud Research Team, a Shibboleth web proxy

was developed as shown in Figure 1. The proxy itself

is running on a virtual machine hosted in the cloud.

Because of the large number of VMs which can

be hosted in the cloud it became a requirement to be

able to use private IP addresses. By passing all trafﬁc

through the publicly available reverse proxy it is very

simple to run services in a private subnet while still

being able to access them publicly through the proxy.

Resource identiﬁcation in our private cloud is

done using the previously described path-based iden-

tiﬁcation mechanism. The main reason for this was

the better support for SSL without relying on SNI.

Although, it would also be possible to use the vir-

tual host mechanism in our architecture. In fact, both

the path- and virtual host based approaches are imple-

mented in our private cloud system.

Users who run services in the cloud can activate

Shibboleth for protecting those services via a web-

based management console. It is also possible to con-

ﬁgure authorization rules using this console. This

concept of a Shibboleth web proxy has been imple-

mented and provided as Open Source under the name

StudiCloud (Cloud Research Lab HFU, ) as an exten-

tion of Opennebula (OpenNebula, 2011).

5 EVALUATION

To demonstrate whether the reverse proxy based ap-

proach to shibboleth authentication is feasible in prac-

tice or not, an evaluation was performed on the HFU

Cloud Research infrastructure.

The evaluation scenario is composed of one re-

verse proxy and one target web server which hosts

a simple HTML page approximately 10KB in size.

Both servers are using the Apache 2.2 Web Server

on Debian 5.0 and are hosted as virtual machines on

the HFU cloud. To eliminate any interference be-

tween virtual machines, these two have been deployed

on separate cloud hosts, interconnected with GBit-

Ethernet.

Three different evaluation scenarios for accessing

the target web server via the proxy have been devel-

oped:

• Shibboleth Authentication. In this scenario a shib-

boleth authentication workﬂow using the reverse

proxy is performed before access to the target web

server is granted.

• Basic Authentication. Apache supports a simple

way of authenticating users. This mechanism is

used to compare the complexity against the shib-

boleth scenario.

• No Authentication. The direct access scenario

without any authentication needed is used as a ref-

erence to compare to.

JMeter is a well-known and well established tool

for stress testing and performance testing of web sites

and web applications. It provides enough ﬂexibility

and customizability options to perform benchmarks

on the above mentioned scenarios.

During the evaluation, test plans for shibboleth,

basic and no authentication workﬂows have been de-

veloped using JMeter. The primary focus of the evalu-

ation is to show whether shibboleth in a reverse proxy

scenario performs well enough to be used in high

load, high trafﬁc setups, as using it as a primary gate-

way in PaaS and SaaS scenarios would be. To elim-

inate any interferences, like load ﬂuctuations on the

cloud hosts, KVM process scheduling, these separate

test plans have been merged into a single test plan and

run in parallel. For each of the scenarios a setup of

10 threads requesting the same page sequentially 500

SHIBBOLETHWEB-PROXYFORSINGLESIGN-ONOFCLOUDSERVICES

Table 1: JMeter evaluation.

Average request time (ms)

No authentication 51

Basic authentication 52

Shibboleth authentication 54

times, which results in 5000 requests per scenario and

15000 requests overall, has been implemented.

Table 1 shows average request/response times of

the tested scenarios. Obviously and expectedly using

a reverse proxy which is forwarding requests to other

web servers without any authentication performs best.

Also using basic authentication which does no more

than sending additional login credentials in the HTTP

request header is only insigniﬁcantly slower. In the

shibboleth scenario a slightly worse result could have

been expected because of the complexity of shibbo-

leth authentication. For instance there is additional

communication between the apache mod shib mod-

ule and the service provider daemon shibd, which

holds session information. But obviously this over-

head does not pose much of a negative impact on the

overall performance of this setup.

These results make the aforementioned integra-

tion of Shibboleth authentication into cloud comput-

ing infrastructures using a reverse proxy, an attractive

way to maintain manageability and security.

Things to consider when integrating a Shibboleth

reverse proxy are proxy resources, bandwidth and

failover. Scaling up is the most common way to en-

hance the performance of a reverse proxy, when de-

mands are rising. Scaling out (e.g. distributing load

on multiple reverse proxies) can be a bit problem-

atic because Shibboleth SPs store session informa-

tion, which in this case need to be distributed among

multiple reverse proxies. Shibboleth supports some

mechanisms to cluster SPs. One way is to choose a

master SP which stores session information and let

other SPs communicate via TCP to it in case they

need additional information. Another way would be

to store session data in a central database and connect

SPs to it. Either way those approaches add a lot of

complexity and it needs to be seen, whether or not

they are feasible performancewise. Another approach

is to only protect the web application’s login script

and let the application itself handle authentication and

authorization in its session management. This way

the SP is only needed for initial authentication and

attribute exchange at the very beginning of a session

with the web application. Adding session stickiness

to this timeframe solves a lot of problems, but requires

the application to have session management and a lo-

gin script has to be developed, which handles session

creation. (see (Shibboleth 2 Documentation, 2011b)

for further information on SP clustering)

The approach described in this paper suffers from

one major problem. Requiring all requests to be han-

dled by the reverse proxy makes it a single point of

failure. This can be solved by applying common fail-

over strategies. In fact deploying the proxy as a vir-

tual machine has the advantage of hot migratability of

the VM in case the hosting cloud node fails. Further

research has to be conducted in this area.

6 RELATED WORK

Guanxi (Jie et al., 2008) is an open source implemen-

tation of the Shibboleth protocol and architecture for

e-social science. Guanxi Shibboleth is integrated into

the Sakai collaborative and learning environment and

PERMIS technology is enabling a policy-driven, role-

based, ﬁne-grained access control. Our approach es-

pecially enables the OpenNebula Cloud Management

System with Shibboleth but enhances the access to

Cloud services by policies.

The national grid service (NGS) provides access

to compute and data resources for UK academics. The

work from Xiao Dong Wang et.al. (Wang et al., 2009)

describes an architecture by which users are authen-

ticated by the UK access management federation to

acquire low assurance credentials to access Grid re-

sources on the NGS. Technically it is integrated into a

portal, whereas our approach is a proxy which can be

integrated in other portals.

The work from Takaaki, K. et.al. (Takaaki et al.,

2011) developed a web forward proxy server with

authentication method using Shibboleth. This proxy

solves problems in basic access authentication and di-

gest access authentication supported by existing web

forward proxy servers. Here the user already has to

use a proxy and it is not supporting federations.

The approach discussed in this paper is exclu-

sively based on open source technologies which

makes it particularly interesting in an academic en-

vironment. For example TU Munich also uses Shib-

boleth as a single sign-on system (Hommel, 2010).

This proxy solution could also be interesting for such

infrastructures outside of cloud environments if use

cases exist where additional ﬂexibility is needed.

7 CONCLUSIONS AND FUTURE

WORK

In this paper a solution to reduce the number of ser-

CLOSER2012-2ndInternationalConferenceonCloudComputingandServicesScience

service provider instances in a dynamic cloud en-

vironment using a Shibboleth reverse proxy is pre-

sented. This reduction results in a more ﬂexible,

easily automatable and simpler administration of ser-

vices while using Shibboleth-based single sign-on,

authentication and authorization.

Two mechanisms for identifying services using

URLs have been presented. The path-based mecha-

nism has proven to be more ﬂexible while providing

best compatibility even to non-current web browsers.

Additionally, an evaluation has been conducted

which has shown, that using a shibboleth service

provider on a reverse proxy is insigniﬁcantly slower

than directly accessing web sites and services. Com-

pared to the gains in manageability, ﬂexibility and se-

curity these performance drops are very acceptable.

The presented solution obviously suffers from a

single point of failure, the proxy. Future work will

analyze a clustered architecture to overcome perfor-

mance and single point of failure problems.

REFERENCES

RFC1918 - Address Allocation for Private Internets.

Transport Layer Security (TLS) Extensions.

(2011). Shibboleth. http://shibboleth.internet2.edu/.

Cloud Research Lab - Department of Computer Science

(2011). http://www.wolke.hs-furtwangen.de/.

Cloud Research Lab HFU. StudiCloud. http://

opennebula.org/software:ecosystem:studicloud.

DFN-AAI (2011). https://www.aai.dfn.de/.

Hommel, W. (2010). Campus single sign-on und

hochschul

ubergreifendes identity management. In

Bode, A. and Borgeest, R., editors, Informationsman-

agement in Hochschulen, pages 221–232. Springer

Berlin Heidelberg. 10.1007/978-3-642-04720-6 19.

Jie, W., Young, A., Arshad, J., Finch, J., Procter, R., and

Turner, A. (2008). A guanxi shibboleth based security

infrastructure. In Enterprise Distributed Object Com-

puting Conference Workshops, 2008 12th, pages 151

–158.

OpenNebula (2011). http://www.opennebula.org/.

Shibboleth 2 Documentation (2011a). Communicating

with a Service Provider. https://spaces.internet2.edu/

display/SHIB2/IdPSPCommunicate.

Shibboleth 2 Documentation (2011b). Shibboleth SP

clustering. https://wiki.shibboleth.net/conﬂuence/

display/SHIB2/NativeSPClustering.

Sulistio, A., Reich, C., and Doelitzscher, F. (2009). Cloud

infrastructure & applications – cloudia. In Jaatun,

M., Zhao, G., and Rong, C., editors, Cloud Comput-

ing, volume 5931 of Lecture Notes in Computer Sci-

ence, pages 583–588. Springer Berlin / Heidelberg.

10.1007/978-3-642-10665-1 56.

Takaaki, K., Hiroaki, S., Noritoshi, D., and Ken, M. (2011).

Design and implementation of web forward proxy

with shibboleth authentication. In Applications and

the Internet (SAINT), 2011 IEEE/IPSJ 11th Interna-

tional Symposium on, pages 321 –326.

TLS SNI Test Site: *.sni.velox.ch (2011). https://

sni.velox.ch/.

Wang, X. D., Jones, M., Jensen, J., Richards, A., Wallom,

D., Ma, T., Frank, R., Spence, D., Young, S., Dev-

ereux, C., and Geddes, N. (2009). Shibboleth access

for resources on the national grid service (sarongs). In

Information Assurance and Security, 2009. IAS ’09.

Fifth International Conference on, volume 2, pages

338 –341.

SHIBBOLETHWEB-PROXYFORSINGLESIGN-ONOFCLOUDSERVICES
