Interactive Text Generation for Information Retrieval

Luis Rodr

ıguez

, Alejandro Revuelta

, Ismael Garc

ıa-Varea

and Enrique Vidal

Departamento de Sistemas Inform

aticos, Universidad de Castilla La Mancha, Albacete, Spain

Departamento de Sistemas Inform

aticos y Computaci

Universidad Polit

ecnica de Valencia, Valencia, Spain

Abstract. Interactive text generation is aimed at facilitating text generation in

those situations where text typing is somehow constrained. This approach achieves

a signiﬁcant amount of typing effort reduction in most tasks. Natural language

based interfaces for information retrieval constitute a good scenario to include

this kind of assistance in order to improve the system usability and provide con-

siderable help in constrained input-interfaces. An initial proposal is presented

here along with an experimental framework to assess its appropriateness.

1 Introduction to Interactive Text Generation

Interactive Text Generation is an application focused on developing automatic assis-

tance in generation of text documents. It is motivated by the fact that the time spent in

typing (including, as well, thinking about what is going to be typed) can be quite long

sometimes. A system able to predict, with some degree of accuracy, what someone is

going to type will be utterly helpful and could save a considerable amount of effort.

In addition, in some situations, typing becomes a slow and uncomfortable task. For

example, in some devices, such as mobile phones, no suitable input mechanisms are

available. Moreover, some disabled people are not able to achieve a fast enough typing

speed and, unfortunately, in some cases, this is the only way for them to communicate.

Previous approaches to this topic can be found in the literature. Most of them just

attempt to predict the next single word and/or to complete the characters of each new

word being typed by the user [9]. Other systems just focus on measuring the accuracy

of off-line text predictions [1]. The proposal presented in this paper considers a more

general scenario where a whole natural language query is predicted according to the

text previously typed. The rationale behind this is to reduce the effort needed to obtain

a satisfactory response from a database accepting natural language input queries.

2 Information Retrieval and ITG

In the last decades, Information Retrieval (IR) systems have gained a lot of impor-

tance in daily life. Querying databases is now a usual task and, therefore, appropriate

Work supported by the EC (FEDER, FSE), the Spanish Government (MICINN, MITyC, ”Plan

E”, under grants MIPRCV ”Consolider Ingenio 2010” CSD2007-00018, iTrans2 TIN20 and

Junta de Comunidades de Castilla La Mancha under PIB08-0210-7127

RodrÃ guez L., Revuelta A., GarcÃ a-Varea I. and Vidal E.

Interactive Text Generation for Information Retrieval.

DOI: 10.5220/0003026900620071

In Proceedings of the 10th International Workshop on Pattern Recognition in Information Systems (ICEIS 2010), page

ISBN: 978-989-8425-14-0

interfaces are crucial to guarantee a real beneﬁt from the huge amount of data cur-

rently available. In this sense, interfaces based on natural language have drawn a lot

of attention in the last years since they constitute the most natural way for a user to

communicate with a system. In the case of accessing to a database this is even more

important since the way in which the information is structured can be so complex that

other communication alternatives are often useless. Nevertheless, these interfaces are

far from being perfect and they present some drawbacks. On the one hand, in spite

of allowing the use of natural language, these interfaces are usually constrained to a

speciﬁc vocabulary or grammatical structure. When the input is not constructed fol-

lowing these constraints (and usually the typical user is not aware of them) the system

response is useless and the user normally feels frustrated. On the other hand, typing text

can be complicated in some situations (mobile devices, disabled people, etc.) and this

fact can weaken the beneﬁt that a natural language based communication can achieve.

This issue is becoming more and more important since nowadays a lot of information is

worldwide available and portable devices are becoming the main communication tool

for a signiﬁcant amount of people.

To overcome these two problems, ITG can be really useful. In the ﬁrst place, regard-

ing the second drawback, ITG can signiﬁcantly reduce the effort in terms of interactions

(that is key strokes) to generate text in very different tasks. In the second place, con-

cerning the ﬁrst question, ITG can boost the correct use of a natural language based

interface since it can be seen as an interactive user guide to the IR system. This way,

ITG can be used to lead the input text to the kind of constructions expected by the sys-

tem and therefore to improve the ﬁnal results obtained. The point here is that the ITG

system could help the user, in the short term, by providing a quick way to obtain an

acceptable result for the query currently carried out and, on the other hand, in the long

term by showing the kind of queries that the system is more likely to accept.

The aim of this paper is to roughly explore the possibilities that this proposal could

offer on a simple system and to discuss an initial experimental framework for this kind

of applications. To this end, a database (AMSABEL) containing information about train

routes will be used in the experiments.

3 ITG Theoretical Background

The task proposed in this work naturally ﬁts into the Interactive Pattern Recognition

(IPR) framework presented in [10]. The basic process consists in, as was commented

before, predicting some portion of text based on the one previously typed. In IPR, we

have an input pattern and the system proposes a possible decoding result. The user,

based on the input and this proposal sends some feedback to the system. The point here

is to take advantage of this feedback to improve the following decoding proposals.

Using the terminology adopted in [10], the feedback is essentially a preﬁx, com-

posed of the sequence of words typed, or predicted by the system so far and validated

by the user, and the system has to ﬁnd a suitable continuation, or sufﬁx, for this preﬁx

(the difference is that here, no input pattern is available and the system suggestion is

based only on the user-validated preﬁx).

The usual strategy to predict a multi-word sufﬁx

s would be to maximize the prob-

ability of the sufﬁx s given a preﬁx p [7], that is:

s = argmax

P r(s|p) (1)

which is aimed at obtaining the best possible sufﬁx. This is perfectly reasonable in a

classical pattern recognition task where we are trying to minimize the number of classi-

ﬁcation errors and the system is actually a completely automatic system. Nevertheless,

under a general interactive text generation approach, the system works as follows. Given

the text typed so far, the system produces a prediction that the user reads until a mistake

is found. Next, the mistake is corrected and the system provides a new continuation

taking this correction into account (as can be seen in Fig. 1). Here, we are interested

in minimizing the number of user interactions (i.e, to save user effort) and, under this

criterion, the approach showed in Eq. (1), which is usually solved by using a dynamic

programming approach, is not necessarily optimal. In fact, a simple greedy strategy

consisting in suggesting the most probable word given the text typed (preﬁx) so far

turns out to be the optimal strategy for this scenario (as it is proved in [6]). It is worth

noticing that this can be easily extended to multi-word predictions by considering each

predicted word as part of the current preﬁx and, repeating this process until reaching

the desired amount of predicted words.

Iteration 1

Prediction: which are the classes of train 1093.

Preﬁx: which

Amendment: which c

Iteration 2

Prediction: which cities can you go from Madrid.

Preﬁx: which cities can you go from

Amendment: which cities can you go from V

Iteration 3

Prediction: which cities can you go from Valencia.

RESULT: which cities can you go from Valencia.

KSR =

= 0.09 → 9%

Fig. 1. Example of an editing session and the corresponding Key Stroke Ratio computation. The

system generates an initial prediction. Then, the user validates a correct preﬁx (boldfaced) and

introduces an amendment (shown in italics). The system, taking into account this information,

generates a new prediction. The process is iterated until a correct, full sentence is achieved. In the

ﬁnal result, the user only had to type the two characters shown in italics plus a ﬁnal conﬁrmation

stroke. The KSR measure is obtained by dividing the number of user amendments between the

overall number of characters.

3.1 Language Modelling using n-grams

In order to predict sufﬁxes, a (language) model for P r(s|p) is needed. Nowadays, under

the statistical framework, n-grams [3] are the most widely used language models in

natural language processing applications. In general, an n-gram model computes the

probability of a whole sentence, or sequence of words, w = w

as:

P r(w) ≈

i=1

P (w

| w

i−1

i−n+1

) (2)

where P r(·) denotes the real probability distribution and P (·) the estimated-model (ap-

proximate) distribution

In the problem addressed here, this model has to be slightly modiﬁed since we are

not dealing with whole sentences but with sufﬁxes that complete a given preﬁx.

Basically, the idea, when adopting this kind of models, is to take advantage from

the last n − 1 words in the preﬁx to predict an appropriate continuation. Clearly, these

models fail in taking advantage from the total information available in the whole preﬁx.

However, no other types of (longer-dependence) language models are commonly ac-

knowledged to overcome the capabilities of n-grams in natural language applications.

Therefore, for the time being, the system is completely based on n-grams.

Let p = w

be the given user preﬁx and let s = w

k+1

be a possible sufﬁx hypoth-

esis. The system computes P r(s | p) as is shown in Eq. (3).

P r(s | p) = P r(p, s)/P r(p)

≈

i=1

P (w

| w

i−1

i−n+1

)

i=1

P (w

| w

i−1

i−n+1

)

i=k+1

P (w

| w

i−1

i−n+1

) (3)

Here, the user feedback is reﬂected in the terms from k + 1 to k + n − 1 of this

factorization, where we have additional information coming from the already known

words w

k−n+2

. Hence, this expression can be further factorized as:

P r(s | p) ≈

k+n−1

i=k+1

P (w

| w

i−1

i−n+1

) ·

i=k+n

P (w

| w

i−1

i−n+1

)

n−1

j=1

Pr(s

k−n+1

, s

j−1

) ·

l−k

j=n

Pr(s

j−1

j−n+1

) (4)

The ﬁrst term accounts for the probability of the n − 1 words of the sufﬁx, whose

probability is conditioned by words from the validated preﬁx, and the second one is the

usual n-gram probability for the rest of the words in the sufﬁx.

3.2 Searching for a Sufﬁx

The maximization in Eq. (1) is intended to minimize the number of classiﬁcation errors

(i.e, the number of whole sufﬁxes correctly predicted). However, the goal here is to

As in [11], we assume that for any string z, the substring z

denotes the empty string λ if

j < i. In addition, we assume that P r(z|λ) ≡ P (z)

minimize the user effort and, in this case, the optimal strategy to achieve this is based

on a greedy algorithm [6]. On account of this, using n-gram models, at step i and having

the preﬁx p = w

i−1

, the next predicted word will be:

∗

= argmax

v ∈V

P (v|w

i−1

i−n+1

) (5)

where V is the vocabulary considered. This leads to the simple Algorithm 1.

minimize the user effort and, in this case, the optimal strategy to achieve this is based

on a greedy algorithm [6]. On accountof this, using n-gram models,at step i and having

the preﬁx p = w

i−1

, the next predicted word will be:

∗

= argmax

v∈V

P (v|w

i−1

i−n+1

) (5)

where V is the vocabulary considered. This leads to the simple Algorithm 1.

Algorithm 1: Greedy strategy to complete a user-validated preﬁx. Note that the greedy

solutions shorter than maxLen are just the preﬁxes of the resulting w. Given a preﬁx, the

algorithm iterates over all the words in the vocabulary to obtain the one with the highest

probability.

user validated preﬁx (p), vocabulary (V ), maximum prediction length (maxLen),

n-gram size (n) whole sentence prediction (w) begin

w = p; i = |p| + 1;

while i < maxLen do

∗

= λ; g

∗

= 0;

forall v ∈ V do

if g

∗

< P (v|w

i−1

i−n+1

) then

∗

= P (v|w

i−1

i−n+1

);

∗

= v;

w = w · v

∗

;

i = i + 1;

return w;

end

The previous description assumes that the system works at word-level and the user

has to type a whole word before getting a prediction. Nevertheless, the system can

also work at character-level (and this is, indeed, the normal operation mode) which

means that as soon as the user introduces a new character the sytem will make a new

prediction.To deal with this situation, whenthe ﬁnal characters in the preﬁx do not form

a word but a word-preﬁx, the system will apply Eq. (5) but considering only the words

“compatible” with this word-preﬁx (for example, in the second iteration of the example

shown in Fig. 1 only those words beginning with the letter ‘f’ are actually considered

in the search).

4 Integrating ITG into a Natural Language based Information

Retrieval System

Different approaches can be taken when including an ITG system into an information

retrieval application. Perhaps, the most simple one is based on a completely decoupled

architecture where the ITG is used basically as a tool to construct a query hypothesis. In

this case, the user interacts with the ITG system as it is shown in Fig. 1, that is, typing

text that is simply auto-completed by the ITG engine. Once the user validates the whole

sentence, it is used to query the database.

The previous description assumes that the system works at word-level and the user

has to type a whole word before getting a prediction. Nevertheless, the system can

also work at character-level (and this is, indeed, the normal operation mode) which

means that as soon as the user introduces a new character the sytem will make a new

prediction. To deal with this situation, when the ﬁnal characters in the preﬁx do not form

a word but a word-preﬁx, the system will apply Eq. (5) but considering only the words

“compatible” with this word-preﬁx (for example, in the second iteration of the example

shown in Fig. 1 only those words beginning with the letter ‘f’ are actually considered

in the search).

4 Integrating ITG into a Natural Language based Information

Retrieval System

Different approaches can be taken when including an ITG system into an information

retrieval application. Perhaps, the most simple one is based on a completely decoupled

architecture where the ITG is used basically as a tool to construct a query hypothesis. In

this case, the user interacts with the ITG system as it is shown in Fig. 1, that is, typing

text that is simply auto-completed by the ITG engine. Once the user validates the whole

sentence, it is used to query the database.

A second alternative can be considered based on a loosely-coupled approach. In

this case, an ITG system is used as in the previous case but, instead of waiting for the

user validation of the whole natural language query, the different text predictions will

be used to build a new query in order to retrieve information from the database. As a

consequence, what the user obtains in each interaction is not merely a text completion

but an answer to the query being constructed.

Other (and more complex) alternatives can be also explored. For instance, a strongly

coupled approach, where the ITG system could be fed with some feedback from the

information retrieval process in order to decide which prediction is more convenient in

the current iteration.

4.1 Brief Description of the AMSABEL System

In order to assess this initial proposal, a simple information retrieval system called

AMSABEL [8] will be used. AMSABEL is based on the use of statistical machine

translation (SMT) techniques to translate from a natural language into a structured

query language (SQL). Currently, AMSABEL is able to accept queries both in Spanish

and English. The resulting SQL sentences are used to access a railway database where

information about train routes is stored (speciﬁcally, for each route, ﬁelds as departure

and arrival cities, starting and ending dates, starting and arrival times, ticket prices, etc.

can be queried).

The translation of the Spanish or English input into SQL is performed by using sta-

tistical phrase-based models [5]. These models perform the translation in three steps.

Firstly, the input sentence is segmented into phrases (which are sequences of consec-

utive words). Then, each segment is translated into the corresponding segments in the

target language and, ﬁnally, the target phrases are properly ordered to achieve the ﬁnal

translation. Formally, in statistical machine translation we are given a source sentence

f, and we try to ﬁnd the optimal target sentence e as:

argmax

P r(e|f) = argmax

P r(f|e) · P r(e) (6)

where P r(e) is the language model probability (usually n-grams, see section 3.1) and

P r(f|e) is the translation model probability. In the case of phrase models, this proba-

bility is expressed as it is stated in Eq. (7):

P r(f|e) = P r(

)

i=1

φ(

)d(a

− b

i−1

) (7)

where

is the i-th phrase in f ,

is the i-th phrase in e, φ(

) is the probability of

being

a translation of

and d(a

− b

i−1

) is the distortion model used for reordering

target phrases. The order of a target phrase

depends on a probability distribution

based on its start position (a

) and the end position of

i−1

Phrase models are obtained from word to word alignments ([2]). The search for the

most likely translation is performed by using the Moses beam-search decoder [4].

A set of semi-automatically generated input queries was used to assess the system

performance (752 English and 748 Spanish sentences were employed) along with the

information that the user expects to obtain for each query (see Table 1) . We think that

using this synthetic corpus can be justiﬁed in this ﬁrst evaluation stage, considering all

the implications of experiments involving real users. On the other hand, the produced

sentences can be, in our opinion, considered as plausible queries for a user interacting

with a natural language based IR system. In Fig. 2 some examples of these test queries

are shown.

please , I would like to know which destinations are there from Guadalajara.

which are the classes of train 1047 ?

what times can you go from Toledo to Alicante the 2011-06-03 ?

which days of the week can you go to Guadalajara from Ciudad Real ?

Fig. 2. Examples of test sentences.

The evaluation procedure was aimed at directly testing the system usefulness from a

potential user point of view. To this end, the results of the input natural language queries

were classiﬁed based on the outcome obtained (the point here is to measure the system

accuracy according to the correctness of the information retrieved). The following query

categories were established:

Q1 Exact Information: The system provides the user with the exact information re-

quired.

Q2 More Fields: The system returns the information required but more ﬁelds are also

provided.

Q3 More Rows: The system provides the information required but more rows from the

database tables are also shown.

Q4 Incorrect: The query does not include the expected information.

Categories 1 and 2 are completely useful since they provide the user with the infor-

mation that he or she requested (adding in the case of Q2 type more ﬁelds). Q3 type can

be also considered useful since the information requested is provided although some

useless additional information is also included in the result (causing, maybe, some an-

noyance to the user). In the case of the Spanish test corpus, about 81% of system results

were classiﬁed as type Q1, less than 0.3% as type 2, about 1.3% as type 3 and, ﬁnally,

about 17% as type 4 (that is, quite useless).

4.2 ITG Experiments

Once the information retrieval system used has been described, a framework to estimate

the possible usefulness of the ITG proposal when included into a IRS will be discussed.

Firstly, regarding the metric employed to estimate the effort that the system can save,

the Key Stroke Ratio (KSR) measure was adopted. This measure is simply computed

by dividing the number of key strokes performed by the user by the overall characters

in the test set (see Fig. 1).

Initially, the KSR of a pure ITG approach on AMSABEL corpus was computed

and it is shown in the ﬁrst row of Table 2. The idea is to measure the effort required

to generate the exact text queries (without involving database accessing) in the test

set. This can be seen, to some extent, as the effort of using a completely decoupled

approach in which the system waits for a completely validated text construction and,

based on this, a ﬁnal single access to the database is performed for each query.

As was described in section 4, ITG can be incorporated into an IR system in differ-

ent ways. In this work, we will focus on a loosely-coupled architecture. The idea is that,

each time the ITG system makes a text prediction, this prediction will become into a

query to the database. Once the query has been performed the user will directly validate

the database response in the case it is correct or, otherwise, the part of the text prediction

that he or she considers error-free (as it is shown in Fig. 3). Then, a simple correction

will be made on this text prediction and the process will be repeated until the user con-

siders the information retrieved as satisfactory. In the experiments performed here, the

user was simulated by the test sets shown in Table 1. The effort will be measured in

KSR terms.

Table 1. Test sets used in ITG for information retrieval.

Spanish English

Number of sentences 748 752

Running words 9413 9763

Vocabulary size 447 484

Perplexity (3-grams) 5.2 4.9

In the ﬁrst row of Table 2 the results of using ITG on the whole AMSABEL system

are shown. These experiments are aimed at measuring the KSR required to obtain one

of the three useful query types described in section 4.1. This way, the KSR needed to

obtain all the queries classiﬁed as type Q1 was computed and the same procedure was

used for Q2 and Q3 queries (Q4 queries were not considered since they are useless from

the information retrieved point of view). As can be observed, the Q1 numbers shows

that it is not necessary to generate the exact input natural language query to get a perfect

result and that some effort can be saved with respect to replicate the input sentence with

ITG (as numbers in Table 2 shown) and, what is more important with a small effort in

terms of key strokes, useful Q3 queries can be achieved.

Table 2. ITG and information retrieval results on the AMSABEL corpus.

Spanish English

Query type KSR improvement KSR improvement

Pure ITG 15.6 – 14.7 –

Perfect queries (Q1) 14.2 16 % 13.0 11%

More columns (Q2) 14.2 16 % 12.9 12%

More rows (Q3) 10.7 36 % 9.5 35%

Iteration 1

Prediction: which days can you go to Madrid from Toledo

SQL: SELECT DISTINCT Dias FROM Tren JOIN Viaje ON

Viaje.Tren=Tren.Id tren WHERE Destino=‘madrid’ AND Origen=‘toledo’

Data: Train 1012 → Monday, Tuesday, Friday

Preﬁx: which

Amendment: which c

Iteration 2

Prediction: which classes can you buy for train number 1040 ?

SQL: SELECT DISTINCT Clase FROM Tren JOIN Billetes ON

Billetes.Tren = Tren.Id tren WHERE N tren = ‘1040’

Data: Train 1040 → Tourist, First class

Preﬁx: which classes can you buy for train number 10

Amendment: which classes can you buy for train number 102

Iteration 3

Prediction: which classes can you buy for train number 1028

SQL: SELECT DISTINCT Clase FROM Tren JOIN Billetes ON

Billetes.Tren = Tren.Id tren WHERE N tren = ‘1028’

Data: Train 1028 → Tourist

Preﬁx: which classes can you buy for train number 102

Amendment: which classes can you buy for train number 1029

Iteration 4

Prediction: which classes can you buy for train number 1029 ?

SQL: SELECT DISTINCT Clase FROM Tren JOIN Billetes ON

Billetes.Tren = Tren.Id tren WHERE N tren = ‘1029’

Data: Train 1029 → Business, First class

KSR =

= 0.061 → 6.1%

Fig. 3. Example of information retrieval using ITG. In this example, the user tries to obtain in-

formation about the different ticket classes for train number 1029. Each time the user makes a

key stroke, the system provides a text completion (Prediction) which is translated into SQL and

the corresponding information retrieved is shown (Data). In the ﬁrst three iterations, the informa-

tion retrieved is not correct and, therefore, the user interacts with the ITG engine correcting the

text prediction mistakes. Finally, at iteration 4, the information provided is fully correct and the

process ends successfully.

5 Conclusions and Future Work

In this paper a completely new approach based on combining an interactive text gener-

ation system with a natural language based interface for information retrieval has been

presented. Different approaches along with a proposal of an experimental framework

have been also discussed. The results achieved are very promising since they suggest a

signiﬁcant effort reduction in this scenario.

Finally, as a future work, experiments involving real users should be considered,

especially to evaluate the capabilities of this kind of systems to provide a more complete

assistance apart from reducing typing effort.

References

1. S. Bickel and P. Haider T. Scheffer. Predicting sentences using n-gram language models.

In HLT ’05: Proceedings of the conference on Human Language Technology and Empirical

Methods in Natural Language Processing, pages 193–200, Morristown, NJ, USA, October

2005. Association for Computational Linguistics.

2. P. F. Brown, J. Cocke, S. A. Della Pietra, V. J. Della Pietra, F. Jelinek, J. D. Lafferty, R. L.

Mercer, and P. S. Roosin. A statistical approach to machine translation. Computational

Linguistics, 16(2):79–85, 1990.

3. F. Jelinek. Statistical Methods for Speech Recognition. The MIT Press, Cambridge, Mas-

sachusetts, USA, 1998.

4. P. Koehn, H. Hoang, A. Birch, C. Callison-Burch, M. Federico, N. Bertoldi, B. Cowan,

W. Shen, C. Moran, R. Zens, C. Dyer, O. Bojar, A. Constantin, and E. Herbst. Moses:

Open source toolkit for statistical machine translation. In Annual Meeting of the Association

for Computational Linguistics, June 2007.

5. P. Koehn, F. J. Och, and D. Marcu. Statistical phrase-based translation. In Proceedings

of the Human Language Technology and North American Association for Computational

Linguistics Conference (HLT/NAACL), pages 48–54, Edmonton, Canada, May 2003.

6. J. Oncina. Optimum algorithm to minimize human interactions in sequential computer as-

sisted pattern recognition. Pattern Recognition Letters, 30(5):558–563, April 2009.

7. Duda R, P.E. Hart, and D.G. Stork. Pattern Classiﬁcation. John Wiley and Sons, New York,

NY, 2nd edition, 2000.

8. A. Revuelta-Mart

ınez, L. Rodr

ıguez, and I. Garc

ıa-Varea. Multilingual access to online help

systems and databases. Procesamiento del Lenguaje Natural, 44, 2010.

9. H. Trost, J. Matiasek, and M. Baroni. The language component of the fasty text prediction

system. Applied Artiﬁcial Intelligence, 19(8):743–781, September 2005.

10. E. Vidal, L. Rodr

ıguez, F. Casacuberta, and I. Garc

ıa-Varea. Interactive pattern recognition.

In Proceedings of the 4th Joint Workshop on Multimodal Interaction and Related Machine

Learning Algorithms, Volume 4892 of LNCS, pages 60–71, Brno, Czech Republic, 28–30

June 2007.

11. E. Vidal, F. Thollard, C. de la Higuera, F. Casacuberta, and R. Carrasco. Probabilistic ﬁnite-

state machines - part II. IEEE Transactions on Pattern Analysis and Machine Intelligence,

27(7):1025–1039, 2005.
