AUTOMATIC GENERATION OF SEMANTIC ANNOTATIONS

FOR SUPPORTING TECHNOLOGY MONITORING

ON THE WEB

Tuan-Dung Cao, Rose Dieng-Kuntz

INRIA, Edelweiss Project-Team, 2004 route des Lucioles – B.P.93, 06902 Sophia Antipolis, France

Marc Bourdeau, Bruno Fiès

CSTB, 290 route des Lucioles – B.P.209, 06904 Sophia Antipolis, France

Keywords: Semantic Web Technologies, Semantic Annotation, Semantic Search, Ontology, Technology Monitoring.

Abstract: Automatic generation of semantic annotations of Web document can be useful to support technology

monitoring on the Web. In this article, we present the main components of the OntoWatch technology

monitoring system relying on a semantic Web approach: the O’Watch ontology dedicated to watch and an

ontology-based algorithm for automatic search and annotation of Web documents.

1 INTRODUCTION

At CSTB, Technology Monitoring (TM) task is

carried out by the archivists using classic

information search tools, which sometimes do not

give the expected results as they do not take into

account context and semantics of information.

OntoWatch system aims at supporting TM task by

relying on semantic Web approach (Berners-Lee et

al, 2001). When a document is needed, OntoWatch

first tries to perform a semantic search relying on its

local annotation base. It also tries to discover other

Web resources relevant for the watch target but not

yet annotated, so as to generate and store annotations

on these Web resources in a local annotation base so

that they become available for later queries of users.

In this paper, after presenting lessons learnt from the

building of the O’Watch ontology, we detail and

evaluate the OntoWatch new algorithm for searching

and annotating Web documents.

2 BUILDING THE O’WATCH

ONTOLOGY

The O’Watch ontology aims at offering the

vocabularies enabling to make the formulation of the

watcher’s query more accurate, and annotate the

Web documents and information sources with watch

topics. Therefore, O’Watch comprises: (a) a

vocabulary dedicated to the corporate watch domain:

building, water recycling, security…, (b) a

vocabulary dedicated to the description of watch

task: TM actors, monitoring phases, information

sources and some document types.

For building O’Watch, we reused the

O’CoMMA ontology since a part of O’CoMMA was

related to the field of building and construction. It

remained to add the concepts more specialized in the

fields interesting for TM as well as concepts and

relations dedicated for TM task: TM actors,

monitoring phases, information sources and

document types. Therefore, knowledge modeling

work was required to add the vocabulary from the

CSTB corporate thesauri (on “security and fire”,

“carcassing and second work”, “water reuse”).

Indeed, even though these thesauri are hierarchical,

they are not ontologies since the hierarchical link in

a thesaurus can be interpreted as “If we search a

document talking about topic

, a document talking

about topic

is useful”. But it does not mean that

topic

is necessarily a subconcept of topic

. This

hierarchical link is not always a subsumption link:

for example, in the thesaurus of “security and fire”,

a hierarchical link directly connects the term “flame

234

Cao T., Dieng-Kuntz R., Bourdeau M. and Fiès B. (2008).

AUTOMATIC GENERATION OF SEMANTIC ANNOTATIONS FOR SUPPORTING TECHNOLOGY MONITORING ON THE WEB.

In Proceedings of the Tenth International Conference on Enterprise Information Systems - SAIC, pages 234-238

DOI: 10.5220/0001698802340238

 SciTePress

zone” with “emissivity of flame”, “height of flame”

and “temperature of flame”. Therefore, a direct and

automatic translation of terms of a corporate

thesaurus into O’Watch concepts was impossible

and a manual transformation was needed. The

possible relations between thesaurus terms are:

hierarchical relation, equivalence relation and

association relation. Let us summarize the steps for

integrating vocabularies from a thesaurus into an

existing ontology. For each thesaurus descriptor

term T, to be included in the ontology:

 Determine the location in the ontology for the

new concept – called c(T) -corresponding to T

(i.e. find its parent concept).

 Add in the ontology a concept c(T) having T as

label.

 Examine all the relations of the descriptor T

with the other terms in the thesaurus.

 If the relation rel between the thesaurus terms T

and T’ is the equivalence relation, T’ is added

in the ontology as a label of the concept c(T).

It plays the role of a synonym for query

formulation.

 If rel is the association relation: a new concept

c(T’) is added in the ontology with T’ as label,

if such a concept did not exist. A «relatedTo»

relation between the concepts c(T) and c(T’) is

added in the ontology.

 If rel is the hierarchical relation :

 If rel is interpreted as subsumption

link, add a concept c(T’) in the ontology

if such a concept did not exist. Make

c(T’) child concept of c(T).

 Otherwise, if rel is interpreted as a

subpart relation, add a concept c(T’) in

the ontology and a «subPartOf» relation

between c(T’) and c(T).

 Continue the same steps for the term T’.

For example for the term « bathtub» appearing in

the thesaurus « carcassing and second work » as

follows:

TS Level 2 SANITARY EQUIPMENT

TS Level 3 BATHTUB

TS Level 3 BIDET

TS Level 3 SHOWER

TS Level 3 WASHBASIN

the following concept is added in the ontology

O’Watch:

<rdfs:Class rdf:ID="BathTubTopic">

<rdfs:subClassOf

rdf:resource="#SanitaryEquipmentTopic"/

<rdfs:label

xml:lang="en">bathtub</rdfs:label>

<rdfs:label

xml:lang="fr">baignoire</rdfs:label>

</rdfs:Class>

The resulting ontology, O’Watch, is bilingual (in

French and English). It comprises 586 concepts and

86 relations and is represented in RDF(S). It is

structured in three layers:

 A high layer stemming from the O’CoMMA

ontology, and comprising abstract, generic

concepts, useful for organizing the ontology

but not aimed at the end-user.

 A middle layer comprising concepts related to

documents, information sources, actors, and

watch domain, and reusable by any company

interested in TM.

 A specific layer, including corporate-specific

concepts related to documents, information

sources, actors and watch domain. This layer

is very usable for the end-user but in general,

not reusable by other companies.

Figure 1: Structure of the O’Watch ontology.

O’Watch building shows how to reuse and

extend an existing ontology by integrating

vocabularies from existing corporate thesauri.

3 ONTOLOGY-BASED

ALGORITHM FOR WEB

DOCUMENT SEARCH AND

ANNOTATION

When the OntoWatch system searches for new

documents to annotate, the use of the O’Watch

ontology is essential. Instead of keywords, concepts

of O’Watch will be selected to form a query. As

advantage, the child concepts of the initial concepts

in the ontology can be used to constitute the request,

so it helps to reduce some lacks in the search results

obtained from a classic search engine. For example,

when we search for documents about "Sanitary

equipment problem", it is useful to be able to find

High layer

Middle layer

pecific layer

Aspects

Aspects Aspects

Document

Information

Source

Actors

Watch

AUTOMATIC GENERATION OF SEMANTIC ANNOTATIONS FOR SUPPORTING TECHNOLOGY MONITORING

ON THE WEB

235

documents evoking "Bathtub overflow", "Bidet

plugging", "Shower too-low-flow" or "Wash basin

fissure”. Thus the query should be able to include all

these alternatives more precise than "Sanitary

equipment problem". The problem is how to form

the query and send it to the search engine.

The best case of the algorithm is that a user’s

query, considered as a list of concepts in ontology,

could be replaced by a system query. This query

generated by the system contains all descendant

concepts of all initial concepts in the user’s query.

But Google limits the number of keywords of a

query and unfortunately, in most real situations the

number of descendant concepts exceeds this limit.

Thus, in our previous work (Cao et al, 2004),

besides implementing the algorithm for ideal

situation above, we developed two algorithms

enabling to overcome this Google limit by using the

branches of the domain ontology. Our evaluation on

those previous algorithms shows that they are more

appropriate for obtaining specialized documents than

general documents. However they have the

drawback to risk to privilege some branches and to

sometimes retrieve documents not related to all the

concepts of the user query. Therefore we needed

another solution that would better ensure that the

documents retrieved by Google are related to all the

concepts of the user’s query. More precisely, the

system queries generated, which consist of a list of

descendant concepts, should not privilege any initial

concept of the user’s query.

3.1 Balanced Concept Selection

Our new algorithm of the OntoWatch system allows

us to retrieve and to annotate documents as much as

possible related to initial concepts from user’s query.

As we mentioned before, while using the ontology

for searching and annotating document, the major

difficulty is the great number of descendant

concepts. So our solution is not to take as much as

possible descendant concepts of each initial concept,

but rather take into account a balanced distribution

between descendant concepts selected from different

initial concepts in user query. As the number of

concepts permitted in a Google query is too small in

comparison with the number the descendant

concepts possible to select, our algorithm will have

to make multiple choices. In other words several

queries corresponding to various selections of

concepts will be generated.

To ensure the balanced distribution between

descendant concepts selected, we rely on a criterion:

the number of descendant concepts permitted

depends on the weight of their initial concept in

comparison with other concepts in user query.

Let Total_Desc (C) be the number of all

descendant concepts of all initial concepts in the

user query, and Local_Desc be the number of

descendant concepts of an initial concept C.

The weight of C is the value of

Local_Desc/Total_Desc (C).

The presence in the generated query of at least

one descendant concept corresponding to each

concept in user query avoids the drawbacks of the

two previous algorithms. For each initial concept,

we have a limit number of concepts to select in order

to contribute to final query. The problem is the

strategy of descendant concept selection. Contrary to

our previous algorithms, which select concepts in

the depth direction, for a initial concept we select its

descendant concepts in the breadth direction. The

result of this process is a set of partial queries,

corresponding to each initial concept. The

combination of these partial queries gives us the

final set of system queries.

3.2 Detailed Description

BalancedOntologySearchAnnotation is the main

module in charge of searching documents on the

Internet by Google search engine with a set of

queries generated by the algorithm. Then, in each

document belonging to the results, the terms

corresponding to the concepts in the ontology are

extracted and stored in a hash table the key of which

is the document URL, in order to generate an RDF

annotation about this document. Based on the

comparison of the URL of each document, all the

redundancies are eliminated and the system

aggregates the concept list when a same document

was found by different queries. The module takes

the user’s query Request

(which is in fact a list of

concepts) as input and produces annotations

represented in RDF, as output.

Algorithm

BalancedOntologySearchAnnotation(Request

)

Q = GenerateQueries (Request

)

// Ann = hashtable the key of which is

the URL of each document retrieved.

Ann Å ∅

for each query q

∈

Q do

Send q to Google

for each document D in Google results do

K Å ExtractConcept(D)

if D.URL was not in Ann

Add K and URL of D to Ann

ICEIS 2008 - International Conference on Enterprise Information Systems

236

else Update the set of concepts to

annotate with D.URL

endif

endfor

Annotate all documents D in Ann with its

URL and set of concepts attached.

End

The most important part is the algorithm to

generate system queries from a user’s query using

ontology. First, to ensure that a system query

generated does not privilege only one or two

branches of ontology, the algorithm calculates, for

each concept in the original user’s query, the limit

number of descendant concepts to appear in the

system query. This limit is based on the ratio

between the number of descendant concepts of an

original concept in the user’s query and the number

of descendant concepts of all original concepts in the

user’s query.

Algorithm NumberConceptLimited(Request

)

Desc = Set of all descendant concepts of

all concepts from Request

S ← Card(Desc)

for each Ci ∈ Request

if Card (Descendants (C

)) ≤ 2

then Limit

← Card (Descendants (C

))

else Limit

← Card(Descendants(C

))/S)

*Google_limit

endfor

End

Notice that this algorithm takes into account the

fact that if a concept has only one or two child

concepts, these subconcepts often play a role as

important as their parent, and they are very close

semantically to the initial concept. So they should

appear in the system query generated.

In this algorithm, the system query is composed

of some partial queries. Each partial query is

represented by a list of descendant concepts of an

original concept in the user’s query. For each

original concept, there are several possible

corresponding partial queries to be selected by an

algorithm described in the module

SetofPartialConcepts. Thus the result of module

GenerateQueries is a set of all possible

combinations of all partial queries of each concept in

user’s query.

Algorithm GenerateQueries(Request

)

for each concept C

∈

Request

Get the set of all partial queries

generated from Ci. Each partial query is

a set of concepts selected from

descendant concepts of C

Å SelectPartialConcepts(C

, Limit

)

endfor

Q = Combine each partial query in all Q

to generate global set of queries using

combination algorithm.

End

As the number of descendant concepts of each

concept often exceeds the limit permitted, how to

select, among these concepts, the Limit best

concepts to form the partial queries? The principle

of algorithm

SelectPartialConcepts is:

Calculate the maximum depth level of the initial

concept in ontology. If the ontology is a graph, we

define maximum depth level of concept C as the

number of concepts (except C) in the path from C to

its deepest descendant concept C

. So we can say all

the direct child concepts of C are at depth level of 1.

And so on. So let K

the maximum depth level of

the initial concept Ci in the user’s query; the number

of generated queries is:

∏

= ni

..1

At each level of depth from C, we choose a

number of Limit concepts from its descendant

concepts, to make a partial query. The inputs of this

module are the original concept C in the user’s query

and the number of descendant concepts permitted to

select. The output is the set of partial queries

generated.

The module SelectConceptFromLevel is

responsible for selecting a predefined number of

concepts from a certain depth level of a concept. The

algorithm starts by taking all concepts in the current

depth level. If the number of concepts at that level is

smaller than the limit specified, the algorithm steps

to the next depth level and so on.

Algorithm SelectConceptFromLevel(C, level,

Limit)

Begin

SetC Å GetAllConceptAtLevel(C,level)

SelectConceptFromLevel(SetC,level,Limit)

End

Algorithm SelectConceptFromLevel(SetC,

level, Limit)

Begin

Let k Å Card(SetC)

if k ≥ Limit then

Add a number of first Limit concepts in

SetC to OutC. Exit

else if k < Limit then

Add all concepts of SetC to OutC.

NextSetÅ GetAllConceptsNextLevel(SetC)

SelectConceptFromLevel(NextSet,level+1,Limit

– k)

AUTOMATIC GENERATION OF SEMANTIC ANNOTATIONS FOR SUPPORTING TECHNOLOGY MONITORING

ON THE WEB

237

endif

End

The balanced concept selection algorithm was

implemented in Java, using Google API for

searching Internet.

4 EVALUATION

The comparison of manual search by the CSTB

archivist and automatic search by the OntoWatch

system on the same watch target, enables to

determine several evaluation measures:

 M the number of relevant documents (among

the Max first ones retrieved by the watchers)

obtained by manual search.

 A the number of documents retrieved by

automatic search (among the Max first ones),

and evaluated as relevant by the watchers.

 I the number of relevant documents found by

both automatic and manual searches.

In order to carry out the evaluation, we interacted

with an archivist (that usually performs TM for the

company) and with corporate domain experts. We

relied on the queries used in the watch process

concerning a specific topic: water reuse (resp.

climate change). Through these queries, we tested

the algorithm using the O’Watch ontology to search

and annotate Web documents. Table 1 shows the

results of the evaluation for both queries.

Table 1: Evaluation results for the two queries.

Evaluation

measure

Measure

definition

Results for

“Water

reuse”

Results for

“Climate

change”

Relevance

A / Max 86% 60%

Relevance

M/ Max 38% 36,66%

Covering

A/M

I / M 94/7% 90,9%

Covering

M/A

I / A 41,86% 55,55%

Newness

A/M

A-I / A 58,13% 44,44%

Newness

M/A

M-I / M 5,26% 9,09%

So automatic search offered by OntoWatch,

leads to better results than a manual search.

5 CONCLUSIONS

The main contributions of the OntoWatch system

are: (a) the building of the O’Watch ontology (in

particular, our original generic method for

integrating vocabularies from existing thesauri in an

existing ontology) and (b) an original algorithm for

automatic searching and annotating Web document;

while selecting concept from ontology to generate a

query, this algorithm takes into account the balance

in the distribution of descendant concept. The

evaluation shows the interest of the automatic search

w.r.t to the manual search by the watcher.

Few works based on semantic web tackle the TM

problem: in (Maynard et al, 2005), the authors

present the h-TechSight system that offers ontology-

based information extraction used in the context of

applications such as market monitoring and

technology watch. OntoWatch search and annotation

algorithm can also be compared to automatic

annotation systems analyzed in (Uren et al, 2006).

But such tools generally rely on Natural Language

Processing, machine learning or information

extraction techniques. OntoWatch algorithm relies

on quite different principles in comparison with all

these annotation tools.

Our work is generic: with an adaptation of the

O’Watch ontology to the corporate watch

characteristics (corporate watch process, corporate

watch domain) in case of need, OntoWatch can be

reused for TM task in any company in any domain.

REFERENCES

Berners-Lee, T, Hendler, J and Lassila, O., 2001. The

Semantic Web. Scientific American. May, p. 29-37.

Cao, D., Dieng-Kuntz, R., Fiès, B., 2004. An Ontology-

Guided Annotation System for Technology

Monitoring, IADIS Int. WWW/Internet 2004 Conf.

Maynard, D., Yankova, M., Kourakis, A., Kokossis, A.,

2005. Ontology-based information extraction for

market monitoring and technology watch.

ESWC’2005 Workshop on End User Aspects of the

Semantic Web.

Uren, V., Cimiano, P., Iria J., Handschuh, S., Vargas-

Vera, M., Motta, E. and Ciravegna, F., 2006. Semantic

annotation for knowledge management: Requirements

and a survey of the state of the art. In Web Semantics,

Volume 4, Issue 1, 14-28.

ICEIS 2008 - International Conference on Enterprise Information Systems

238
