A CASE STUDY OF DISTRIBUTED AND EVOLVING

APPLICATIONS USING SEPARATION OF CONCERNS

Hamid Mcheick

Department of Computer Science and Mathematics, University of Québec at Chicoutimi, 555 Boul Université

G7H 2B1 Chicoutimi, Canada

Hafedh Mili

Department of Computer Science, University of Québec at Montréal, Case postale 8888 succursale Centre-ville

H3C 3P8 Montréal, Canada

Rakan Mcheik

Department of Computer Science, Institut des sciences appliquées, Beirut, Lebanon

Keywords: Distributed applications, sep

aration of concerns.

Abstract: Researchers and practitioners have noted that the most difficult task is not development software in the first

place but rather changing it afterwards because the software’s requirements change, the software needs to

execute more efficiently, etc. For instance, changing the architecture of an application from a stand-alone

application, to a distributed one is still an issue. Generally speaking, we should encapsulate distribution

logic in components through the borders of aspects oriented techniques (separation of concerns) in which

we define an aspect as a software artefact that addresses a concern. Although, theses aspects can be offered

by the same object that changes its behaviour during lifetime. We investigate through a case study the

following ideas. Firstly, what we need like modifications to transform local application to distributed one,

using a number of target platforms (RMI, EJBs, etc.)? Secondly, we analyze aspects oriented development

techniques to detect what is the best technique that corresponds for changes requested to integrate a new

requirements such as distribution.

1 INTRODUCTION

Separation of concerns are attractive because they

exhibit long advocated software characteristics like

modularity and cohesion, and their impact on

software development has been described as another

computing revolution on a par with those of stored

programs and programming languages (Kiczales et

al., 1997), (Mili et al., 2002), (Constantinides and

Skotiniotis 2004). In the context of a distributed

application, different sites, and different users may

see different concerns/aspects of the same objects,

including different functionalities, different access

rights and privileges, different quality of service

parameters, and so forth. Addressing these concerns

means adding and changing code that crosscuts

normal modularization boundaries, i.e. typically

objects and methods.

The distribution has been considered by many

researc

hers and practices as a technical aspect that

can be handled independently of functional aspects

(e.g. (Soueid et al., 2005) and (Mcheick et al., 2007).

Consequently, we should encapsulate distribution

logic in components through the borders of aspects

oriented techniques. Firstly, the difference caused by

the distribution has to be showed in OO program,

i.e. what we need like modifications to transform

local application to distributed one? Secondly, we

should analyse aspects oriented techniques to detect

which the best technique corresponds for changes

requested to integrate the distribution.

Transform a stand-alon

e application to

distributed one is, in the most cases, a solved

problem. Indeed, existent distributed platforms use a

variation of patterns (for example, stubs proxy) and

various compilers provide automatically the majority

of code used in distributed objects (for example, IDL

393

Mcheick H., Mili H. and Mcheik R. (2007).

A CASE STUDY OF DISTRIBUTED AND EVOLVING APPLICATIONS USING SEPARATION OF CONCERNS.

In Proceedings of the Second International Conference on Software and Data Technologies - SE, pages 393-400

DOI: 10.5220/0001340803930400

 SciTePress

compiler of Corba). Previously, researchers have

suggested the use of middleware approach to

distribute an application. Although, this middleware

(like pattern proxy) resolves the most of

circumstances, it stills some changes that need to be

integrated: i) Object lifecycle: remote object creation

is still different from local object creation. The

researchers propose to use object factory, which is

accessible using naming service, ii) The objects, that

become distributed, should implement the interface

needed by clients. Thus, the objects that should be

translated between clients and servers should

implement serializable interface, for example in the

case of RMI, and iii) the invocation to remote

methods can throw exceptions, which are linked to

remote objects of clients.

These changes imply modifications in clients

programs and in implementations classes programs

at server side. We will investigate theses

modifications using aspect oriented software

development techniques. Each technique was

developed with a set of problems in mind. Subject-

oriented programming (Harrison and Ossher, 1993),

and its incarnations (Tarr and Ossher, 2000), are

purported to support feature-oriented programming

and integration, favouring the separation of

functional concerns. Aspect-oriented programming

(AOP, (Kiczales et al., 1997) was built with

architectural, non-functional concerns in mind. Our

own view-oriented programming (VOP, (Mili et al.,

2002)) was developed to handle functional concerns.

Beyond the original intents of their designers, what

kinds of problems are these methods best suited for?

The case study consists of taking a sample

application, and submitting it to one maintenance

scenario, consisting of adding a new architectural

requirement, namely, distributing (or “remoting”)

some objects. Through this experiment, we would

like to, 1) gain some insights into the classes of

problems that each method is best suited for, and 2)

to explore whether distribution is a separable

concern that can be added to an existing application

after it has been built, using one of the three aspect-

oriented development techniques.

The next section includes a brief overview of the

aforementioned techniques and describes a

distributed view-based model. Sections 3 and 4

describe the case study aimed at comparing three

aspect methods where a distributed software

requirement is investigated.

2 BACKGROUNG

We describe the various methods of separation of

concerns and then distribution issues with aspects.

2.1 Aspect-oriented Techniques

Subject-oriented Programming. It views object

oriented applications as the composition of several

application slices representing separate functional

domains or add-ons (features) to existing functional

domains. Such a slice is called a subject and consists

of a self-contained, declaration-wise, object-oriented

program, with its own class hierarchy.

Subject-oriented programming enables us to

compose these two hierarchies (subjects) into one

that, generally speaking, consists of, i) the union of

the interfaces (signatures) emanating from the two

subjects, and i) the composition of the

implementations of the methods that are defined in

more than one subject (Ossher et al., 1995). A major

limitation of SOP is the compile-time binding of the

various subjects. Also, because the granularity of

composition is the method, composability requires

some pre-planning (Mili et al., 1996).

Aspect-oriented programming. It recognizes

that the programming languages that we use do not

support all of the abstraction boundaries in our

domain models and design processes. Aspect-

oriented programming requires three ingredients: i)

general purpose programming language for defining

the core functionalities of software components, ii)

An aspect language for writing aspects, i.e. code

modules that address a specific concern and that

cross-cut various components in the general-purpose

language, and iii) An aspect weaver, which is a pre-

processor that “weaves” or “injects” aspects into the

base software components to yield vanilla flavour

components, coded in the general purpose

programming language. The output of the aspect

weaver is next fed into regular programming toolkit

(compiler, linker, etc.) to yield the application.

View-oriented programming. We view each

object of an application as a set of core

functionalities that are available, directly or

indirectly, to all the users of the object, and a set of

interfaces that are specific to particular uses, and

which may be added or removed during run-time.

The interfaces may correspond to different types of

users with similar functional interests or to different

users with different functional interests. We set out

to provide support for the following: i) enable client

programs to access several functional areas or views

simultaneously, ii) support the addition and removal

of views (functional slices) during run-time, making

ICSOFT 2007 - International Conference on Software and Data Technologies

394

objects support different interfaces during run-time,

and iii) have a consistent and unencumbered

protocol to address objects that support views.

Accordingly, our implementation is based on: i)

providing an API for manipulating views during run-

time (adding and removing, activating and

deactivation), ii) transforming code that uses views

by replacing simple (core object) references by

references to the wrapper, when needed.

2.2 Distribution Objects with Aspect

The combination of aspects and distribution is

interesting for three reasons: i) distribution (garbage

collector) is, itself, one of those design aspects that

crosscut implementation classes, and that clutter the

code without bringing in any new user-defined

functionality. It would thus seem to be a perfect fit

for a technique such as aspect-oriented

programming, which appears to be particularly well

suited for separating design-level concerns, ii)

depending on the separation of concerns technique,

objects that embody several concern may be

fragmented, which may raise a number of issues for

distribution, and iii) considering that different

functional areas usually imply different data

ownership and use privileges, to what extent can

aspect, role, or view boundaries can be used as units

for distribution—and possibly for duplication—in a

distributed application context (see more details in

Mili et al., 2006).

View-oriented programming deals with the

distribution of object views mainly for two reasons:

i) different clients need to share various

combinations of different core object views, ii)

object views can change behaviours during lifetime

(see for example, (Mcheick, 2006)). Figure 1 depicts

the case where an object implementation consisting

of a core object and its views residing on the same

server and where several clients have access to

different sub-sets of the core object views. For

instance, clients can have access to a combination of

views (V1, V2 and V3). Client1 has access to views

V1 and V2 when client2 has access to V2 and V3. It

is important to note that the functionalities of V1 and

V2 are not always available to client1 and similarly

for V2 and V3 with respect to client2. In fact, the

availability of the functionalities of theses views to

their respective clients depends on the attachment

operations invoked on the core object from the

respective client. In this respect, the following

requirements have to be satisfied: the core object

must provide the implementation of the different

view combinations required by clients.

Figure 1: Architecture of distributed object with views:

One server and many clients.

Two issues need to be addressed: i) how to make

the same server object implement two or more client

interfaces, and ii) where to handle the dispatch of

multiply implemented methods (methods

implemented by several views or by the core class

and one or more views). Distributed platforms such

as (CORBA, RMI, and EJB) typically ensure

location transparency by providing proxy objects for

the current objects residing on remote servers. These

platforms use stub and skeleton classes, which are

automatically generated to support the

communication and the transparency. In this respect,

a server object can offer different interfaces to

several clients. We use the delegation approach

which defines a tie subclass of the skeleton class.

These classes (stub, skeleton, etc.) are modified to

support view programming and include object

lifecycle that is not standardized by CORBA (OMG,

2005). To offer multiply-implemented methods, we

have the option of simply forwarding method calls

to the server, and let the server side dispatch method

calls or raise exceptions if a method is not currently

supported. Alternatively, we could handle the

dispatch on the client side, and then ensure that any

call that goes to the server will get answered (see

(Mcheick, 2006) or (Mili et al., 2002)). In terms of

code transformations, this means: i) client side view

management, ii) client side dispatching, and iii) a

call is made locally or remotely.

3 A CASE STUDY OF

DISTRIBUTED AND

EVOLVING APPLICATION

WITH ASPECT TECHNIQUES

3.1 Issues

The three methods described in sections 2.1 propose

different modularisation boundaries for aspects:

A CASE STUDY OF DISTRIBUTED AND EVOLVING APPLICATIONS USING SEPARATION OF CONCERNS

395

 With subject-oriented programming, a subject

is a class hierarchy which is definitionally

self-sufficient, i.e. all the methods and

attributes that are referenced are either locally

defined or declared.

 With view oriented programming, a view is an

object fragment, which is also definitionally

self-sufficient, but that needs the core object

to execute.

 With AspectJ™, the original “aspect-oriented

programming” language (for example,

AspectJ), an aspect is an amorphous construct

that can take many forms, but essentially, an

aspect is meant to implement cross-cutting

concerns, i.e. concerns that pertain to several

objects in a collaboration.

Generally speaking, the aspect-oriented software

development (AOSD) community associates

subject-oriented programming—and its descendant,

HyperJ™—with functional concerns, whereas

AspectJ™ is associated with non-functional ones,

including architectural aspects, error handling,

security, etc. That may have been the original intent

of its developers, but as these methods are being

appropriated by their users, new unanticipated uses

are being found regularly.

This raises a number of related questions. First,

can we use HyperJ™ to implement non-functional

concerns, and conversely, can we use AspectJ™ to

implement functional concerns? Second, assuming

that HyperJ™ is more appropriate for functional

concerns and AspectJ™ is more appropriate for non-

functional concerns, what is it about these concerns

that would make them require different

modularisation boundaries. Tarr et al. hinted at the

answer by noting that developers usually use a

dominant decomposition to handle a first set of

concerns, and then try to « slap » the other concerns

on top of that (Tarr, Ossher, 2000). If that is the

case, then the dominant decomposition is likely to be

functional, which could explain why non-functional

concerns tend to be cross-cutting. A more

fundamental question is, are all concerns separable

(see (Mili et al., 2006))? Aspect-oriented software

development methods have been able to separate and

package concerns that were thought non-separable

with the object paradigm, but are all aspects

separable, theoretically, and it is just a matter of

finding the right packaging, or are some aspects

inherently non-separable? In (Mili et al., 2006), Mili

et al. have attempted to lay the foundations for

answering such a question.

For our purposes, a subsidiary question is

whether distribution is separable concern?

Distribution is an architectural concern, not a

functional one, and one is led to wonder whether it

can be isolated into an “aspect”, be it an AspectJ™

aspect, or a HyperJ™ subject, or a JavaViews view?

The answer to this question is not only theoretical: if

we are able to separate distribution, as a concern,

into an aspect, that means that we can take a simple

single-process or single-virtual machine application,

and make it distributed by composing it with

distribution aspects (or subjects or views). This has

important practical implications, both from the point

of view of application development, as well as from

the point of view of re-engineering or scaling up

existing applications.

Accordingly, we devised a case study that would

enable us to gain some understanding into these

issues. This case study consists of a simple

computerized sales application that manages

customers, orders, products, and inventory. To

compare the three methods described in section 2,

we consider an evolution scenario for the

application, which is consisting of adding a non-

functional requirement.

3.2 A simple Application

Our application supports a range of behaviours,

including: 1) managing customers: this includes

CRUD (Create, Read, Update, Delete) operations on

customers, as well as account management 2)

managing orders: this includes CRUD operations on

orders, as well as order follow-up (e.g., figuring

which fraction of an order has been processing), and

invoicing, 3) managing deliveries, and 4) managing

inventory: CRUD operations on products, as well as

ordering more products from suppliers.

As mentioned above, we considered two

evolution scenarios, one adding a functional

requirement, and the other dealing with an

architectural requirement.

As for the non-functional requirement, we

initially thought of reproducing a variant of the

architectural requirement implemented in the case of

the ATLAS case study reported by Kersten &

Murphy (Kersten & Murphy, 1999). However, those

requirements did not apply to our case. Accordingly,

we looked at the problem of turning a simple

application into a distributed one.

4 ASPECTIZING DISTRIBUTION

4.1 Issues

As we mentioned before, turning a regular

application into a distributed one is, for the most

ICSOFT 2007 - International Conference on Software and Data Technologies

396

part, a solved problem. Existing distribution

frameworks all use a variant of the proxy pattern,

and various compilers will automatically generate

most of the code involved in “distributing” objects.

However, this code is typically generated before the

application domain code is written. The sequence

generates then edits works for forward engineering

development but not for re-engineering or

distributing existing applications.

With existing applications, the classes that

represent objects that are to be distributed need to

undergo some changes, and we will explore what

those changes are. More problematic changes need

to occur within programs that use those classes.

Those concerns are i) Creation of remote objects

(lifecycle) is different from that of local objects, and

ii) Handling remote exceptions: remote method

invocations may raise a number of exceptions that

may either be related directly to the remoteness of

objects, or that may be remote re-castings of user-

defined exceptions. These can occur anywhere

within a method in the client program.

Both subject-oriented programming and view-

oriented programming allow composition only at the

method level. Only aspect-oriented programming

supports composition at sub-method levels, with

some restrictions (entry and return points,

exceptions, etc.). Thus, aspect-oriented

programming seems to be, a-priori, the best fit for

handling these kinds of aspects, on demand.

In the next section, we discuss the required

changes that we need to make to an existing program

to distribute some of its objects. We will discuss

these changes in the context of specific technologies:

Java RMI, and the EJB architecture. The CORBA

distribution framework shares many characteristics

with Java RMI and EJB, and will not be discussed.

4.2 Required Changes

If we want to distribute objects, we need to make

changes to both the classes that implement the

objects, and the code that uses them. To get a grasp

on the kinds of changes that need to happen to client

code, we show excerpts of a program that creates an

object, and invokes methods on it (figure 2):

1. public class Main {

2. public static void

main(String[] args) {

3. Company retailer = new

Company("Home Depot");

…

4. Order newOrder = new

Order(aCustomer);

5. // fill up the order

…

6. retailer.processOrder(newOrder

);

7. …}}

Figure 2: A program that creates an object and invokes

processOrder() method.

We considered the changes that needed to be

made for three distribution frameworks: Java RMI,

CORBA, and EJB. The EJB framework is the most

complete—also, the most complex—and the most

widely used. Thus, we will look at the changes

required to deploy an existing class as an EJB.

4.2.1 Domain Classes

For illustration purposes, we look at what needs to

be done for an entity bean, and we don’t distinguish

between local and remote interfaces. Thus, given a

java class that we want to distribute, we need to

make the following changes:

 Extract an interface (Remote) containing all of

the application domain methods of the class,

and make sure that all of the methods raise

either RemoteException or EJBException.

Also, make sure that all of the arguments are

either serializable, or are themselves

references to other distributed objects

 Create a class that represents a unique identifier

for objects of this EJB: this is the primary key

class. It can be any java class, as long as it is

serializable.

 Extract an interface (Home) containing one

create method for each public constructor the

class has. This interface also needs to support

a findByPrimaryKey(…) method that takes an

argument that is an instance of the primary

key class just mentioned.

Modify the existing java class to: i) make the

class implements EntityBean, ii) add the appropriate

exceptions to method signatures, iii) add lifecycle

management callback methods (ejbPassivate(),

ejbActivate(), ejbPostCreate(), etc.), iv) Implement

the methods of the home interface (modulo some

renaming), and v) in case of bean managed

persistence, implement the load and save methods.

A CASE STUDY OF DISTRIBUTED AND EVOLVING APPLICATIONS USING SEPARATION OF CONCERNS

397

4.2.2 The Code that Uses Domain Classes

Remotely

In the context of distributed objects, a client program

cannot create an instance of the remote object using

the traditional “new”: it needs an object “creator”

that it can ask to create a remote object on its behalf.

That object creator is often also a distributed object,

and we either need a way to create it remotely, or to

locate it on the remote server. With EJBs, it is the

“Home” object that has a global identifier (JNDI

name). For CompanyHome, that name is

ejb/HomeImprovementRetailers (figure 3):

1. public class Main {

2. public static void main(String[]

args) {

// Company retailer = new

Company(“Home Deport”);

3. Context initial = new

InitialContext();

4. Object ref =

initial.lookup("ejb/HomeImproveme

ntRetailers");

5. CompanyHome companyHome =

(CompanyHome)PortableRemoteObject

.narrow(ref,<home interface

class>);

6. Company retailer =

companyHome.findByPrimaryKey(“Hom

eDepot");

…

//Order newOrder=new

Order(aCustomer)

7. Order newOrder =

retailer.createOrder(aCustomer);

8. // fill up the order

…

9. retailer.processOrder(newOrder);

10. … }}

Figure 3: An object creator that creates a remote object

using EJB Home.

4.3 Implementing the Changes

4.3.1 Changes to the Domain Classes

The changes that need to be made to the domain

classes are of two kinds:

Creating new interfaces (and a class) based on

the existing one. This operation can be done by

parsing the domain classes and getting the important

information out, or by using the Java reflection

package to extract the desired information. We are

not really extending the behaviour of the base

classes here, and we should not interpret the aspect-

oriented programming techniques as code

manipulation tools: they are first and foremost

techniques for changing the behaviour of programs

regardless of how that modification takes place.

Modifying the existing class. As we saw in

section 4.2.1, those changes consisted of changing

some of the type information of the class, and

adding methods. The added methods are of two

kinds: i) lifecycle callback methods which are added

as-is to all domain classes, and ii) class specific

methods, which implement the methods of the home

interface.

Adding the type EntityBean to domain classes

(with the statement “implements EntityBean”) can

be done in both AspectJ™ and HyperJ™. In

HyperJ™ all we need to do is to combine the

existing subject with another one that defines the

domain class as implementing the interface

EntityBean. If we merge the two subjects by name,

we get the desired behaviour. However, HyperJ™

creates a new subject to combine both subjects. This

implies that we should modify the code clients that

use the existing subject if this code needs to use the

new composition subject. With AspectJ™, we can

get the desired behaviour by using the so-called

inter-type declarations. This is not possible in

JavaViews. With JavaViews, we can add the desired

behaviour (EntityBean) as a view, if we wish, but it

does not change the static type of the domain class.

With regard to the addition of the lifecycle

management callback methods, all three methods

support it. The most elegant solution is, in our

opinion, the HyperJ™ solution because it involves

merging the existing domain class with a class

definition that includes the lifecycle management

methods. AspectJ™, again using inter-type

declarations, can do the same thing.

The following shows an aspect that uses inter-

type declarations to add the “implements

EntityBean” directive, and (some of) the new

lifecycle management methods (figure 4).

1. public aspect

ejbCompanyEntityBean {

2. declare parents : Company

implements EntityBean;

3. …

4. public void

Company.ejbActivate()throws

RemoteException,EJBException{

5. }

6. public void

Company.ejbPassivate()throws

RemoteException,EJBException{

7. }

8. public void

Company.ejbPostCreate()throws

RemoteException,EJBException{

9. }

…}

Figure 4: An aspect shows how we can add a directive and

methods.

ICSOFT 2007 - International Conference on Software and Data Technologies

398

The issue of adding exceptions to method

signatures is a tricky one. First of all, note that none

of the aspect-oriented techniques enables us to

modify the signature of existing methods to add

exceptions. However, all methods can help us extend

the behaviour of a method with a given signature,

and that can include throwing an exception.

To understand how we deal with these

exceptions, we need to understand the rationale

behind EJBException and RemoteException. First,

the RemoteException signals to the client that an

exception occurred on the server side, but the client

does not necessarily has access to the details of the

exception that occurred on the server side: the server

side exception class may not even be in the client’s

class path. An EJBException is an exception that

occurs within the EJB container. Because it is an

unchecked exception, developers need not include it

in the methods Home and Remote interfaces: if one

such method raises the exception, the container will

catch it, wrap it inside a RemoteException and sends

it over to the client. The container will not wrap a

business/application exception: it will be raised on

the client side as is. This means that if containers

weren’t sticklers about types ☺, we could emulate

the effect of having the exceptions in the signatures

by actually throwing them in wrappers put around

the bean class methods using what AspectJ™ and

JavaViews calls before and after advices/methods,

and what HyperJ™ calls brackets.

4.3.2 Title Changes to the Code that Uses

Domain Classes

The client code shown in previous section shows the

kind of changes that we need to make to the classes

that use the application classes that I wish to

distribute. Method invocation on remote objects

works exactly the same way as with local objects,

and that is the beauty of the proxy model. However,

getting a handle on the first remote object, either

through creation or through look-up, is different.

Code excerpts such as the following lines taken

from previous section can occur anywhere within a

client program. HyperJ™ and JavaViews perform

behavioural composition at the method level.

Therefore, there is no way that we can redefine

object creation or access within client programs to

use the remote model. AspectJ™ can extend

behaviour at many join points: method call (from the

outside), method invocation (inside, upon entry),

method return (inside, before exiting), when we raise

exceptions, when we reference an instance variable,

etc. However, all of these joints have some meaning

for the virtual machine, i.e. they correspond to

specific operations of the virtual machine. We can

not extend a program at any instruction.

1. …

2. Context initial = new

InitialContext();

3. Object ref =

initial.lookup("ejb/HomeImprov

ementRetailers");

4. CompanyHome companyHome =

(CompanyHome)

5. PortableRemoteObject.narrow(re

f,<home interface class>);

6. Company retailer =

companyHome.findByPrimaryKey(“

HomeDepot");

7. …

If developers use factory patterns to create and

look for objects as a general practice, remoting

objects becomes much simpler because we localize

the changes to the methods of a single (or a handful

of) factory(ies). But for general-purpose

programming, we cannot “remote” the manipulation

of objects systematically using any of the aspect-

oriented techniques.

5 CONCLUSION

In wide-enterprise information systems, changing

the architecture of the application from a stand-alone

application, to a distributed application has been

investigated in this paper. Generally speaking, we

tried to encapsulate distribution logic in components

through the borders of aspects oriented techniques in

which we define an aspect as a software artefact that

addresses a concern. A number of techniques

collectively referred to as aspect-oriented

development techniques, have been proposed that

offer new artefacts (beyond method, class, or

package) that can separate new kinds of concerns

that tend to be amalgamated in object-oriented

programs. As users adopted and appropriated these

methods, new unanticipated uses appeared and

raised the question: which method is best suited for

which class of problems?

In this paper, we reported on a case study that

submitted an application to evolution scenarios: 1)

adding functional features to the base application,

and 2) changing the architecture of the application

from a stand-alone application, to a distributed

application. In that scenario, we evaluated the

impact of the change, and explored ways to

implement it using each one of the techniques. This

experiment has important practical applications for

distribution: if we are able to encapsulate the act of

A CASE STUDY OF DISTRIBUTED AND EVOLVING APPLICATIONS USING SEPARATION OF CONCERNS

399

remoting an object, into a separate software

component (or aspect) that we can compose or

weave into simple Java object, we would have

solved an important (re)engineering problem. We

argue that if there are many object types that need to

be modified, AOP allows to gather the modification,

in a modular way, into a unique entity (aspect). That

is not always easy to do it with SOP that changes the

name of existing class and the client code.

We studied the Enterprise Java Beans

distribution pattern, because of its popularity and

complexity and not surprisingly, we found that some

changes cannot be modularized into a separate

aspect. Is this a problem with the distribution

solution (the EJB architecture) or with the

distribution problem? This, again, is not an idle

theoretical question. One of the premises of Model-

Driven Engineering is that architectural design and

the coding of business logic are fairly independent

activities, enabling us to “code once” and “deploy

everywhere”. The transition from platform-

independent model (PIM) to platform-specific model

(PSM) applies an architectural mould (e.g. the EJB

pattern) to a bunch of domain class. If we could

write the business logic in a way that is entirely

independent of the deployment infrastructure, we

can write it once in the PIM, and deploy it to

different platforms. In transformational systems

jargon, this is equivalent to saying that architectural

design and business logic elaboration (coding) are

two commutative activities (Baxter, 1992). This

experiment seems to suggest that they aren’t where

the biggest hurdle is lifecycle management. By

abstracting object lifecycle management, we will

probably succeed.

REFERENCES

Baxter, I., 1992. Design Maintenance Systems. CACM,

vol .35 no. 4, pp. 73-89.

Büchi, M., Weck, W., 2000. Generic Wrappers. In

ECOOP’00. LNCS 1850, pp. 201–225.

Constantinides, C., Skotiniotis, T., 2004. Providing

Multidimensional Decomposition in Object-Oriented

Analysis and Design. Proceedings of the IASTED

International Conference. Innsbruck, Austria, Fub.17-

19.

Harrison, W., Ossher, H., 1993. Subject-oriented

programming: a critique of pure objects. In Proc. of

OOPSLA’93. pp. 411-428.

Kersten, M., Murphy, G.C., 1999. Atlas: A Case Study in

Building a Web-Based Learning Environment using

Aspect-Oriented Programming. OOSPLA’99. Denver,

CO, USA.

Kiczales, G., Lamping, J., Mendekar, A., Maeda, C.,

Lopes, C.V., Loingtier, J.M., Irvin, J., 1997. Aspect-

Oriented Programming. Proceedings of the European

Conference on Object-Oriented Programming

(ECOOP07). Springer-Verlag, Finland, pp. 220-242.

Mcheick, H., Mili, H., Msheik, H., Sioud A., and

Bouzouane, A., 2007. ASPECTGC: Aspect Garbage

Collection for Object lifecycle management.

Proceedings of ACM (ICICIS’07). Cairo, Egypt.

Mcheick, H., 2006. Distribution d’objets en utilisant les

techniques de développement orientées aspect :

programmation orientée aspect, programmation

orientée sujet et programmation orientée vue. Thèse de

doctorat, 273 pages, Université de Montréal, Québec,

Canada.

Mili, H., Harrison, W., Ossher, H., 1996. SubjectTalk :

Implementing Subject-Oriented Programming in

Smalltalk. In proceedings of TOOLS USA 1996. Santa

Barbara, CA, July 29 - August 2nd, 1996, Prentice-

Hall.

Mili, H., Mcheick, H., Dargham, J., 2002. CorbaViews:

Distribting objects with several functional aspects.

Journal of Object Technology. USA.

Mili, H., Sahraoui, H., Lounis, H., Mcheick, H., Elkharraz,

A., 2006. Understanding separation of Concerns.

Fundamental Approsches to Software Engineering,

FASE’06. Vienna (Austria), March 27-29.

OMG:www.omg.org, 2005.

Ossher H., et al., Subject-oriented composition rules. In

Proc. OOPSLA ’95. Austin, TX, Oct. 15-19, pp. 235-

250.

Soueid, T., Yahiaoui, N., Seinturier, L., Traverson, B.,

2005. Techniques d’aspect pour la gestion de la

mémoire répartie dans un environnement CORBA-

C++. In Proceeding of NOTERE’05. Gatineau

(Québec), Canada.

Tarr, P., Ossher, H., 2000. HyperJ User and Installation

Manual. IBM Corporation.

http://www.research.ibm.com/hyperspace, USA, 2000.

ICSOFT 2007 - International Conference on Software and Data Technologies

400
